OMEGA

HH507

Digital Thermometer

OMEGAnetSM On-Line Service

http://www.omega.com

Internet e-mail

[email protected]

Servicing North America:

USA: ISO 9001 Certified Canada:

One Omega Drive, Box 4047 976 Bergar

Stamford, CT 06907-0047 Laval (Quebec) H7L5A1

Tel: (203) 359-1660 Tel: (514) 856-6928

FAX: (203)359-7700 FAX: (514) 856-6886

e-mail: [email protected] e-mail: [email protected]

omega.com

For immediate technical or application assistance:

USA and Canada: Mexico and Latin America:

Sales Service: 1-800-826-6342 / 1-800-TC-OMEGASM Tel: (95) 800-TC-OMEGASM

Customer Service: 1-800-622-2378 / 1-800-622-BESTSM FAX: (95) 203-359-7807

Engineering Service: 1-800-872-9436 / 1-800-USA-WHENSM En Español: (203) 359-7803

TELEX: 996404 EASYLINK: 62968934 CABLE: OMEGA e-mail: [email protected]

Servicing Europe:

Benelux: Germany/Austria:

Postbus 8034, 1180 LA Amstelveen, Daimlerstrasse 26, D-75392

The Netherlands Deckenpfronn, Germany

Tel: (31) 20 6418405 FAX: (31) 20 6434643 Tel: 49 (07056) 3017 FAX: 49 (07056) 8540

Toll Free in Benelux: 06 0993344 Toll Free in Germany: 0800 82 66342

e-mail: [email protected] e-mail: [email protected]

Czech Republic: United Kingdom: ISO 9002 Certified

ul. Rude armady 1868, 733 01 Karvina- One Omega Drive

Hranice, Czech Repubic Riverbend Technology Centre Northbank, Irlam,

Tel: 420 (69) 6311627 FAX: 420 (69) 6311114 Manchester, M44 5EX, England

e-mail: [email protected] Tel: 44 (161) 777-6611 FAX: 44 (161) 777-6622

France:

9, rue Denis Papin, 78190 Trappes Toll Free in England: 0800-488-488

Tel: (33) 130-621-400 FAX: (33)130-699-120 e-mail: [email protected]

Toll Free in France: 0800-4-06342

e-mail: [email protected]

It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification

of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.

The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no liability for any errors it contains,

and reserves the right to alter specifications without notice.

WARNING: These products are not designed for use in, and should not be used for, patient connected application.

The symbol on the instrument indicates that the operator must refer to an

explanation in this manual.

WARNING

To avoid electrical shock, do not use this instrument when working

voltages at the measurement surface over 24V AC or DC.

WARNING

To avoid damage or burns, do not make temperature

measurement in microwave ovens.

CAUTION

Repeated sharp flexing can break the thermocouple leads. To prolong

lead life, avoid sharp bends in the leads, especially near the connector.

INTRODUCTION

This instrument is a 4½ digit, compact-sized portable digital thermometer

designed to use external K/J/T/E/R/S/N-type thermocouples as temperature

sensor.TemperatureindicationfollowsReferenceTemperature/VoltageTables

(N.I.S.T. Monograph 175 Revised to ITS-90) for K/J/T/E/R/S/N-type thermo-

couples. One K-type thermocouple are supplied with the thermometer.

SAFETY INFORMATION

Itisrecommendedthatyoureadthesafetyandoperationinstructionsbefore

using the thermometer.

SPECIFICATIONS

ELECTRICAL

Temperature Scale: Celsius or Fahrenheit user-selectable

Measurement Range:

Thermocouple Range

K-TYPE -200°C to 1372°C, -328°F to 2501°F

J-TYPE -210°C to 1050°C, -346°F to 1922°F

T-TYPE -200°C to 400°C, -328°F to 752°F

E-TYPE -210°C to 790°C, -346°F to 1454°F

R-TYPE 0°C to 1767°C, 32°F to 3212°F

S-TYPE 0°C to 1767°C, 32°F to 3212°F

N-TYPE -50°C to 1300°C, -58°F to 2372°F

Resolution:

K-TYPE 0.1°C, 0.1°F (0°F to 700°F)

0.2°F on other range

J-TYPE 0.1°C, 0.1°F (0°F to 500°F)

0.2°F on other range

T-TYPE 0.1°C, 0.1°F (0°F to 600°F)

0.2°F on other range

E-TYPE 0.1°C, 0.1°F (0°F to 450°F)

0.2°F on other range

R-TYPE 1°C , 1°F

S-TYPE 1°C , 1°F

N-TYPE 0.1°C , 0.2°F

Accuracy:Accuracyisspecifiedforoperatingtemperaturesovertherangeof

18°C to 28°C (64°F to 82°F), for 1 year, not including thermocouple error.

K/J/T/E-TYPE ±(0.05% rdg + 0.3°C) -50°C to 1370°C

±(0.05% rdg + 0.7°C) -50°C to -210°C

±(0.05% rdg + 0.6°F) -58°F to 2498°F

±(0.05% rdg + 1.4°F) -58°F to -346°F

N-TYPE ±(0.05% rdg + 0.7°C) -50°C to 0°C

±(0.05% rdg + 0.3°C) 0°C to 1300°C

±(0.05% rdg + 1.4°F) -58°F to 32°F

±(0.05% rdg + 0.6°F) 32°F to 2372°F

R/S-TYPE ±(0.05% rdg + 2°C) 0°C to 1767°C

±(0.05% rdg + 4°F) 32°F to 3212°F

Temperature Coefficient: 0.1 times the applicable accuracy specification

per°Cfrom0°Cto18°Cand28°Cto50°C(32°Fto64°Fand82°Fto122°F).

Input Protection: 24V dc or 24V ac rms maximum input voltage on any

combination of input pins.

Reading Rate: one time per second.

InputConnector:Acceptsstandardminiaturethermocoupleconnectors(flat

blades spaced 7.9mm, center to center).

ENVIRONMENTAL

Ambient Operating Ranges: 0°C to 50°C (32°F to 122°F) <80% R.H.

Storage Temperature: -20°C to 60°C (-4°F to 140°F) <70% R.H.

GENERAL

Display:4½digitliquidcrystaldisplay(LCD)withmaximumreadingof9999.9.

Overload: "----.-" is display.

Battery: Standard 9V battery.

Battery Life: 100 hours typical with carbon zinc battery.

Auto power off: The meter key switch inactive for more than 30 minutes,

press power key to resume operation.

Dimensions: 192mm(H) x 91mm(W) x 52.5mm(D).

Weight: 365g.

OPERATING INSTRUCTIONS

Power Switch

The key turns the thermometer on or off. In the MIN MAX record mode

can not power off, must leave MIN MAX record mode then power off.

°C/°F Selecting the Temperature Scale

Readings are dual displayed in either degrees Celsius(°C) or degrees

Fahrenheit(°F). When the thermometer is turned on, it is set to the

temperature scale that was in use when the thermometer was last turned

off. To change the temperature scale, press the °C/°F key.

HOLD Mode (only Main display)

Pressing the HOLD key to enter the Data Hold mode, the "HOLD" annun-

ciator is displayed. When HOLD mode is selected, the thermometer held

the present readings and stops all further measurements.

PressingtheHOLDkeyagaintocancelHOLDmodecausing thermometer

to resume taking measurements.

In the MIN/MAX recording mode, press HOLD key to stop the recording.

Press HOLD key again to resume recording. (Previously recorded reading

are not erased).

TIMER STOP-WATCH Mode

Press TIMER STOP-W key to enter stop-watch mode stop-watch is

displayedinseconddisplay.Pressstart/stopkeytotogglestop-watchstarts

and stops (Time goes up to 99 minutes & 59.9 seconds). In the this mode

the automatic power-off feature is disabled.

Pess Clear key to zero the stop-watch.

Press TIMER STOP-W key again to exit the stop-watch mode.

K/J/T/E/R/S/N T1 Input Thermocouple Type Select (Main

display)

The TYPE key circulating selects the K/J/T/E/R/S/N type thermocouple as

input.

When the thermometer is turned on, it is set to the type selected that was

in use when the thermometer was last turned off.

MIN MAX with Time record Mode (only Main display)

Press MIN MAX key to enter the MIN MAX Recording mode, (displays the

Maximum reading with time, Minimum reading with time and Average

reading stored in record mode). In the this mode the automatic power-off

feature is disabled and key, °C/°F key, REL key, SET key, Hi/Lo Limits

key and TYPE key are disabled.

The beeper emits a tone when a new minimum or maximum value is

recorded.

Push MIN MAX key to cycle through the Max/Min/Avg/Present readings.

If an overload is recorded, the averaging function is stopped and average

value display"----.-".

The true average of all the reading taken over at least 22 hours preiod can

be displayed. If 22 hours is exceeded, new averages are no longer

calculated.Thelastcalcalatedvalueisretainedastheaveragereading,but

the actual minimum and maximum reading will continue to be captured.

In the this mode, press HOLD key to stop the recording of readings, all

values are frozen, press again to restart recording.

TopreventaccidentallossofMIN,MAXandAVGdata,inthismodecanonly

becancelledbypressingand holddowntheMINMAXkeyfor2secondsto

exit and erased recorded readings.

REL Relative mode (only Main display)

Pressing REL key to enter the Relative mode, zero the display, and store

the displayed Reading as a reference value and annunciator REL is

displayed. Press REL key again to exit the relative mode.

The relative value can also be entered by the user. (See "SET mode" later

in this manual.)

WhenthedesiredRelativevaluehasbeenentered,pressRELkeytoenter

the Relative mode, press SET key use set Relative value as a reference

value. Press REL key again to exit the relative mode.

In the Relative mode, the value (can not >±3000.0 counts) shown on the

LCDisalwaysthedifferencebetweenthestoredreferenceandthepresent

reading.

Hi/Lo LIMITS mode (only Main display)

Press Hi/Lo LIMITS key to enter the Hi/Lo Limits comparative mode,

"LIMIT" is displayed. In the this mode the automatic power-off feature is

disabled and REL key, HOLD key, MAX/MIN key are disabled, when input

temperaturevalueexceedHi.Thebeeperemitsacontinuitypulsetoneand

"Hi" is displayed, and when input temperature value exceed Lo value. The

beeperemitsadiscontinuouspulsetoneand"Lo"isdisplayed.PressHi/Lo

LIMIT key again to exit the Hi/Lo LIMIT mode.

SET mode (Relative value set, Time set and Hi/Lo Limits value

set and Time set)

1. Press SET key to enter Relative valuse SET mode (Press ENTER key can

escape relative valuse set mode), REL set mode. = = = =.= is displayed in

maindisplay.Relativevalueisenteredviaoverlaynumbers,whenyouwant

togetnegativevaluespush(-0)keyforendofnumbers,thenpressoverlay

ENTER key, stored the relative value, enter Hi/Lo Limits value set mode.

2. Hi Limit value set mode, (Press ENTER key can escape Hi Limit value set

mode), = = = =.= is displayed in main display, Hi Limit value is entered via

overlay numbers, when you want to get negative values push (- 0) key for

endofnumbers,then press overlay ENTER key, storedthe HiLimitvalue,

enterLoLimitvaluesetmode(Press ENTERkeycanescapeLoLimitvalue

set mode), = = = =.= is displayed in main display, Lo Limit value is entered

via overlay numbers, when you want to get negative values push (- 0) key

for end of numbers, then press overlay ENTER key, stored the Lo Limit

value, enter Time set mode.
