INSTRUCTIONS

CODED FUNCTION SYSTEM

This instruction manual is for the Olympus Coded Function System. To ensure the safety, obtain optimum

performance and to familiarize yourself fully with the use of this system, we recommend that you

study this manual and the manuals of units used in combination with this system thoroughly before

operating the system.

Retain this instruction manual in an easily accessible place near the work desk for future reference.

U-D7RES

BX3-RFAS

U-HSEXP

U-CBS

A X 7 8 7 7

This device complies with the requirements of both directive 2004/108/EC concerning

electromagnetic compatibility and directive 2006/95/EC concerning low voltage. The CE marking

indicates compliance with the above directives.

In accordance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment,

this symbol indicates that the product must not be disposed of as unsorted municipal waste, but

should be collected separately.

Refer to your local Olympus distributor in EU for return and/or collection systems available in your

country.

IMPORTANT — Be sure to read this section for safe use of the equipment. — 1,2

1 CONNECTOR NOMENCLATURE 3

2 SYSTEM CHART 4,5

3 CABLE DISTRIBUTIONS 6-9

4 READOUT/EXTERNAL TRANSMISSION OF CODED INFORMATION 10

Page

CONTENTS

1BX43 (System with LED Lamp Housing)............................................................................................................................................................... 7

2BX43 (System with Halogen Lamp Socket)...................................................................................................................................................... 8

3BX53 System................................................................................................................................................................................................................................................. 9

CODED FUNCTION SYSTEM

IMPORTANT

SAFETY PRECAUTIONS

This system is capable of reading coded information from the BX3-RFAS Fluorescence Illuminator and the

U-D7RES 7-Position Revolving Nosepiece and transmitting the information externally.

1. Before connecting the cables, make sure that the POWER switch of the U-CBS control box is set to OFF (out position).

2. For safety, always use the provided AC adapter to power the system.

3. Keep the cables away from the lamp housing and the surroundings. Otherwise, the cables may melt and cause an electric

shock hazard.

Safety Symbol

The following symbol is found on the system. Study the meaning of the symbol and always use the equipment in the

safest possible manner.

Symbol Explanation

Indicates a non-specific general hazard. Follow the description given after this symbol or in

instruction manual.

Indicates that the main switch is ON.

Indicates that the main switch is OFF.

CODED FUNCTION SYSTEM

1Getting Ready

2Caution

1. This system is composed of precision instruments. Handle it with care and connect cables gently to avoid subjecting it

to sudden or severe impact.

2. Do not use the system where it is subjected to direct sunlight, high temperature and humidity, dust or vibrations.

3. To avoid malfunction, never connect or disconnect a cable while the POWER switch of the control box is set to ON

(depressed position). Otherwise, malfunction may result.

4. To avoid malfunction, never attempt to open, disassemble or modify any part of the system.

5. Before disposing of this product, be sure to follow the regulations and rules of your local government.

If the system is used in a manner not specified by this manual, the safety of the user may be imperiled. In addition, the

system equipment may also be damaged. Always use the system as outlined in this instruction manual.

The following symbols are used to set off text in this instruction manual.

: Indicates a potentially hazardous situation which, if not avoided, may result in minor

or moderate injury or damage to the equipment or other property. It may also be used

to alert against unsafe practices.

} : Indicates commentary (for ease of operation and maintenance).

CAUTION

1CONNECTOR NOMENCLATURE

Control Box for Coded Function

U-CBS

U-D7RES connector

BX3-RFAS connector

POWER switch

ON: Depressed position.

OFF: Out position.

Microscope frame hangers (top/bottom)

RS-232C connector

Option connector

The U-CBM can be connected.

U-HSEXP connector

For the external DP21 exposure button.

AC adapter input connector

CODED FUNCTION SYSTEM

2SYSTEM CHART

· Entrust the assembly and adjustments of the modules marked*to Olympus.

The connectors of the U-CBS are sealed with dust covers. Remove the dust covers only from the connectors

you want to connect cables.

· Be sure to connect the module designated by Olympus to each connector. If a non-designated module is

connected, the performance of the entire system cannot be guaranteed.

· Before connecting the cables, make sure that the POWER switch of the U-CBS control box is set to OFF (out

position).

Hold each connector in the appropriate orientation and insert it all the way into the connector. If a connector

is provided with clamping screws, be sure to tighten them.

· Do not insert a non-designated connector. Otherwise, the connector may be damaged.

CAUTION

Coded Fluorescence

Illuminator *

BX3-RFAS

Microscope Frame

BX43F

BX53F

Control Box for Coded Units Note 3)

U-CBS

U-D7RES connector Note 2)

BX3-RFAS connector *Note 2)

Microscope

Digital Camera

DP21

RS-232C cable Note 1)

Option connector

AC adapter

U-HSEXP connector

Note 4)

Fig. 2

Fig. 1

Note 1)

RS-232C cable specifications

D-sub 9-pin (female) D-sub 9-pin (female)

Note 2)

When connecting a cable to the BX3-RFAS or U-D7RES connector, align

the tmarkings @ on the connectors of the cable and the U-CBS (Fig. 1).

Note 3)

Hang the U-CBS control box 2on the hangers 3on the rear of the

microscope frame (Fig. 2).

Note 4)

When this system is used with the DP21 microscope digital camera, set

the power switches to ON in the order of: @ U-CBS and 2DP21-CB.

Otherwise, the DP21 will not recognize the U-CBS. Also if the U-D7RES is

not connected to the U-CBS, the DP21 will not recognize it either. So be

careful.

CODED FUNCTION SYSTEM

3CABLE DISTRIBUTIONS

}The cables can be laid properly by attaching the cable holders provided with each module (6 cable holders are provided

with the U-CBS control box, 2 with the U-D7RES revolving nosepiece and 1 with the U-LS30AD adapter) on the rear panel

of the microscope frame.

· In the subsequent pages, the positions for attaching the cable holders and the method of cable distribution will be

described for each microscope system.

· The number of the cable holders used vary depending on the modules used in the system.

· If the cable holders are attached in widely deviated positions, the cable may become unable to reach the connector. Be

sure to attach the cable holders while confirming that their positions allow the cable to reach the connector

· Be sure to remove cable slacks before closing the cable holders.

POWER



1BX43 (System with LED Lamp Housing U-LHLEDC)

Use 6 cable holders.

Align with the top left

corner of the label.

Align with the height of

line drawn on the label.

Align with the top right

corner of the label.

Banding band

(Provided with U-HSEXP)

*Only either cable should be used.

U-D7RES cable BX3-RFAS cable

RS-232C cable

AC adapter cable

U-HSEXP cable for

right side installation

*U-HSEXP cable for

left side installation
