Olympus Stylus Manual de usuario

INSTRUCTIONS

Description of controls

LCD panel

Shutter release button

Flash reflector

Autofocus windows

Lens barrier

Rewind button

Light sensor

Self-timer button

Flash mode button

Self-timer signal

Viewfinder

Autofocus indicator

Flash indicator

Strap Eyelet

Back cover release

Film window

Tripod socket

Battery compartment cover

Exposure counter

Flash OFF

AUTO/AUTO-S flash

Battery remaining indicator

Fill-in flash

LCD panel

Autofocus frame

Close-up

correction marks

Viewfinder indicators

Table of contents

Description of controls.................................... 1

Beforeyou begin...........................................5

Loading the battery........................................ 5

Simple point & shoot photography .................... 7

Loading the film............................................ 7

Unloading the film........................................ 11

How to take pictures..................................... 13

Auto flash photography

(1) Taking pictures in low light......................... 18

Auto flash photography

(2)

Taking

backlighted

subjects

........................

Camera functions and controls........................ 21

Close-up (Macro) photography........................ 21

Focus lock.................................................. 22

Self-timer photography.................................. 24

Flash AUTO-S mode.................................... 25

Flash OFF mode.......................................... 27

FILL-IN

flash

mode

....................................

Attaching the strap/How to use the soft case..... 29

Troubleshooting...........................................31

Care and storage.......................................... 33

Specifications..............................................34

Thank you for purchasing the Olympus

Please read this instruction manual carefully before using the camera.

This camera will not operate unless the lens barrier is opened.

We also recommend that you shoot at least one roll of film to familiarize yourself

with the camera's features.

Symbols used in this manual

Correct

Incorrect

Operation

Order of operation

Automatic operation

Operating sound

Lamp on

Lamp blinking

Attention

Press lightly

Loading the

battery

Before you

begin

Open the battery compartment cover.

*Remove the battery if you do not plan to

use the camera for an extended period of

time.

Insert the new battery correctly as

indicated below and close the bat-

tery compartment cover tightly.

*Use a 3V lithium battery

(Duracell DL123A, Panasonic CR123A,

or equivalent.)

*Open the battery compartment cover

and remove the battery, as illustrated

below, when replacing the battery.

*Be sure to close the lens barrier when

replacing the battery.

Open the lens barrier as shown

below until you hear a "Click"

and check the battery power

remaining.

When is displayed (Approx. 12

sec.), battery is OK.

If flashes, battery is low, have spare

handy.

If is displayed continuously, battery

should be replaced immediately.

*When closing the lens barrier, slide

gently to allow the lens to retract as the

barrier is being closed.

Open the back cover by sliding

the back cover release toward the

top of the camera.

The camera back will open.

Simple point

and shoot

photography

the film

This camera is

designed to use DX

coded 35 mm film to

automatically set film

speed. If DX-coded

film is unavailable,

use ISO 100 film.

Prepare a "DX" film cartridge.

The camera will set itself auto-

matically for DX-coded film

speeds from ISO 50 to 3200.

*When using non-DX film, the film

speed is automatically set to ISO 100.

Insert the film cartridge into the

camera.

Avoid direct sunlight when load-

ing the film.

Be sure the film is lying flat.

Align the film leader with the red film loading indicator.

Adjust the length of the film leader before loading so that it matches

with the red loading indicator.

Make sure the film leader tip is not bent and the film perforations are

properly aligned and engaged as shown.

Close the camera back firmly.

(Make sure the back cover lock

snaps down.)
