Olympus 200 Manual de usuario

INSTRUCTIONS

Table of contents

Preparationsbefore takingpictures

Loading the batteries

.................

Simple operating procedures

the

film

....................

Taking pictures

.....................

Unloading

the

film

..................

Automatic flash activation

(1)

Taking pictures

in low light

..........

(2)

Taking backlighted subjects

..........

Advanced shooting techniques

Spot metering

......................

Auto-zoom photography

..............

Taking

continuous scries

shots

.......

Using

the

self-timer

..................

AUTO-S flash mode

.................

Flash OFF mode

....................

FILL-IN

flash

mode

.................

MULTI

flash

mode

.................

Using

the

remote control

..............

Use

fillers

.......................

Mounting

the

strap

..................

Use ofthe

optionalOlympuscase

........

Care

and

storage

......................

Questions

and

answers

..................

Description

controls

..................

Viewfinder

display

and LCD

panel

..........

Specifications

........................

•Please read this instruction manual carefully before using yourcamera. •Thiscamera will not operate unless the barrier is opened.

•Before takingimportant pictures suchasontravels, itisrecommended that youtaketrial pictures.

Remove the battery cover on the

side of the grip.

Insert the batteries in the correct

directions and replace the cover.

Preparations

before taking

pictures

Loading the batteries

Be sure to the correct

batteries, and do not mix

new and old batteries at the

same time.

Remove the batteries and

keep them in a safe place if

you are not likely to use the

camera for long time.

Two 3V lithium batteries

(DL123A/CR123A)

Note: After inserting the batteries the

camera may activate electronically

without having set the power switch

to the ON position In this switch-

ON status, the barrier opens and the

LCD panel is indicated The LCD

panel will remain on for approximate-

ly4, 5 minutes.

Set the power switch to ON and

check the charge remaining in the

batteries.

Battery power will be displayed in

the LCD panel.

When is displayed for 12 sec.,

the batteries are OK.

When blinks, it indicates that

the battery power is low, and the

batteries should be replaced.

When lights, replace the

batteries immediately.

To open the back, slide the back

cover lock up.

The camera back will open.

Simple operating

procedures

Loading the film

Thiscamera isdesignedto

use 35mm film with "DX"

coding to automatically set

film speed.

If no "DX" film is available,

use ISO-100 film.

Prepare a "DX" film cartridge.

Your camera will automatically set

itself for DX-coded film speeds

ranging from ISO 50 — 3200. (Refer

toPage47.)

• In case of non DX film, film speed

is automatically set to ISO 100.

Insert the film cartridge into the

camera.

Always avoid direct sunlight when

loading the film.

Make sure the film lies flat.

Align the film leader with the red

mark.

Close the camera back.

Setting the powerswitch to ON,

check that the exposure counter

displays"1".

•If the film is not loaded properly, the

exposure counter will not show "1"

and a display as shown in the illus-

tration will appear in the LCD panel

In this case, reload the film correctly.

You can check the type of film in

usethrough the window inthe

back of the camera.

Taking pictures

When the power switch is on,

the LCD panel lights.

The LCD panel goes out

after 4.5 minutes.

Then the lens will zoom

to the wide-angle

position.

Set the power switch to ON, which

will open the lens barrier. When the

camera is not in use, always set the

power switch to OFF so that the

shutter cannot be activated by acci-

dent and the lens barrier will be

closed to protect the lens.

When the power switch is set to ON,

thebarrier opens and thelens shifts

out to the wide angle shooting

position.

While looking through the

viewfinder, aim the camera at the

subject you wanttoshoot.

Operate the zoom button to adjust

the lensuntil yousee theimageyou

want.

When the T side of the zoom button

is pressed, the lens will zoom to the

telephoto side.

(In the telephoto position. the maxi-

mum focal length ofthe lens is

80mm.)

When the W side of the zoom button

is pressed, the lens will zoom to the

wide-angleside.

(In the wide-angle position, the

minimum focal length of the lens is

38mm.)
