Olympus E-P5 1442 Kit Silver Manual de usuario

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

E-P5 1442 Kit Silver

• Ultra-fast autofocus system • 3-inch tilt LCD display ideal

for shooting from tricky

angles

• Intuitive touchscreen

operation

• Built-in WiFi

• Live MOS Sensor with high

dynamic range and low

signal-to-noise ratio

Retro-inspired, quality-driven

Inspired by the now-legendary PEN-F camera from 1963, the retro-style E-P5 has been given a thoroughly modern revamp that pushes

the frontiers of quality imaging in the 21st century. Take shots with the same pro-standard quality excellence as D-SLR cameras.

Harness the full potential of your lens with a mechanical shutter speed of up to 1/8000s, ultra-focus autofocus with Pinpoint AF, high-

speed release time lag mode, 5-axis image stabilisation with IS Auto, and so much more - for capturing shots with incredible precision

and clarity, whatever the lighting conditions and however fast your subject.

The E-P5 also excels in wireless connectivity: It lets you shoot remotely yet as fast as from your camera straight from your smartphone’s

touchscreen, or record your location by assign GPS data from your phone to each photo you take. Then share your hotshot images via

your phone with specific friends, while protecting your data.

Specifications

Type

Body material Metal

Lens mount Micro Four Thirds

Image Sensor

Type 4/3'' Live MOS sensor

Effective pixels 16.1 Megapixels

Filter array Primary colour filter (RGB)

Aspect ratio & area 4:3 / 17.3 x 13.0mm

Full resolution 17.2 Megapixels

Engine

Type TruePic VI

Filter

Dust reduction filter Supersonic Wave Filter

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Live View

Displayed information Aperture

Shutter speed

Auto bracket

AE lock

Focus mode

Shooting mode

Battery check

My Mode

IS activating mode

Internal temperature warning

Face / Eye detection mode

Record mode

ISO

Sequential shooting mode

White Balance

Metering mode

Exposure compensation

value

AF frame display

AF confirmation mark

Shooting information

Spot metering area

Super FP

Flash status

Touch Panel Condition

Focal length

Eye-Fi condition

Flash mode

Histogram

Custom

Face detection

AF type Contrast detection system

100% field of view Approx. 100%

Magnification levels 5 / 7 / 10 / 14x

Image Stabiliser

Type Sensor shift

Modes Five-dimensional, vertical

or horizontal activation,

automatic

Effective Compensation Range Up to 5 EV steps

Focusing System

Method Contrast Detection AF system

Focus areas 35 points / Automatic and

manual selection

/ Auto selection with Face

Detection ON

800 points / Manual selection

in Magnified View Mode

AF lock Yes , Locked by first position

of shutter release button in

single AF mode, AE/AF lock

button (customised)

Modes Manual focus

Single AF

Continuous AF

Single AF + MF

AF Tracking

Super Spot AF

AF illuminator Yes

Full time AF Yes

Manual focus Yes , With enlarged focusing

area or focus peaking

Face Detection extension Eye Detect AF: Off

Left side priority

Right side priority

Near side priority

Predictive AF Yes

AF tracking Yes , Available in continuous

AF mode

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Exposure System

Modes Programme automatic

Aperture priority

Shutter priority

Manual

Bulb

Time

i-Auto

Scene Modes

Art Filter

Photo Story

My Mode

Exposure compensation +/- 3EV ( 1, 1/2, 1/3 steps )

Exposure bracketing 2 / 3 / 5 frames ( +/- 1/3, 2/3,

1 EV steps )

7 frames ( +/- 1/3, 1/2, 2/3

EV steps )

HDR bracketing 3 / 5 frames ( +/- 2 / 3 EV

steps )

7 frames ( +/- 2 EV steps )

Note: HDR picture can not be

made by this function.

ISO bracketing 3 frames ( 1/3, 1/2, 1 EV

steps )

AE lock Yes (Fn1/Rec button)

My Mode 4 settings storable

Enhancement function Shadow Adjustment

Technology

Scene Modes

Number of scene modes 25

Modes Portrait

e-Portrait

Landscape

Landscape with Portrait

Macro

Sports

Night Scene

Night Scene with portrait

Children

High key

Low key

Digital Image Stabilisation

Nature Macro

Candle

Sunset

Documents

Panorama

Fireworks

Beach and Snow

Fisheye converter

Macro converter

Wide converter

Underwater Macro

Underwater Wide

Multi-Exposure

Max. number of frames 2 frames (shooting)

3 frames (editing)

Auto gain control Yes

Frame assistance Live View

Light Metering

Method TTL open aperture light

metering

Zones 324 zones Multi-pattern

Sensing System

Detection range 0 - 20 EV (17mm f2.8, ISO

100)

Modes ESP light metering

Spot metering

Centre weighted metering

Highlight

Shadow

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Art Filter

Modes Pop Art

Soft Focus

Pale & Light Colour

Light Tone

Grainy Film

Pin Hole

Diorama

Cross Process

Dramatic Tone

Gentle Sepia

Key Line

Water colour

Variation / Effect Available

Photo Story

Modes Standard

Fun Frame

Sensitivity

Auto ISO 200 - 25000

(customisable, default ISO

200 - 1600)

Manual ISO LOW - 25600 in 1/3 or 1

EV ISO steps

Shutter

Shutter type Computerised focal-plane

shutter

Self timer 2s / 12s

Custom (delay

1-30sec.,shooting interval

0.5/1/2/3sec.,number of

shots 1-10)

Anti Shock Yes release delay: 1/8 - 30s

Shutter Speeds

Shutter speed range 1/8000 - 60s (in 1/3, 1/2, 1

EV steps)

Bulb mode Up to 30 minutes (selectable

longest time in the menu,

default: 8 minutes)

Time Up to 30 minutes (selectable

longest time in the menu,

default: 8 minutes)

White Balance

AUTO WB system Advanced detection system

with Live MOS sensor

Manual White balance (One-

Touch)

Yes

White balance bracketing 3 frames / +/- 2, 4, 6mired

steps

One-touch white balance 2 custom settings can be

registered

Custom WB 1 setting can be registered at

Kelvin temperature (2000K -

14000K)

Preset values Tungsten

Flourescent 1

Sunlight

Flash

Overcast

Shade

Underwater

Auto Flash adjustment Off / Auto WB / Flash

Keep warm colour On / Off

Sequence Shooting

Speed (H) Approx. 9fps

Speed (L) 5.0fps (IS off), 4.5fps (IS on)

Max. number of frames 18 frames (RAW)

Up to card capacity (JPG /

Large Normal mode)

Conditions Memory card: Toshiba SDXC

UHS-I card R95 W80 model

Premiugate series �Class 10�

8GB

Note: Depending on shooting

conditions, the sequential

shooting speed may reduce

speed during shooting.

Interval shooting Interval: 1s - 24h

Max. number of frames: 99

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Image Processing

Colour space sRGB / AdobeRGB

Sharpness + Contrast 5 levels

Contrast 5 levels

Saturation 5 levels

Black & White filter Yellow, Orange, Red, Green

Black & White toning Sepia, Blue, Purple or Green

in Black & White mode

Picture mode i-Enhance, Vivid, Natural,

Portrait, Muted, Monotone,

Art Filter

Gradation 4levels (auto, high key,

normal, low key)

Engine TruePic VI

Art Filter bracketing Available

Tele converter effect 2x

Internal Flash

Modes AUTO

Manual

Manual (Full, 1/4, 1/16, 1/64)

Red-eye reduction

Slow synchronisation with

red-eye reduction

Slow synchronisation

Slow synchronisation 2nd

curtain

Fill-in

Off

Type Internal Flash

Flash compensation +/- 3 EV ( 1/3, 1/2, 1 EV

steps )

Guide number 10 (ISO 200)

X-sync speed 1/320s / 1/4000s (Super FP

Mode)

External Flash Control

X-sync speed 1/250s / 1/4000s (Super FP

Mode)

Type TTL AUTO, AUTO, MANUAL,

FP TTL AUTO, FP MANUAL

Modes Auto

Red-eye reduction

Slow synchronisation

2nd curtain and slow

synchronisation

Fill-in for exclusive flash

Manual

Intensity +/- 3 EV ( 1/3, 1/2, 1 EV

steps )

Note: Some functions are

only available if they are

supported by the external

flash.

Wireless Flash Control

Number of channels 4 channels

Compatible external flash FL-36R, FL-50R, FL-300R,

FL-600R

Control method Triggered and controlled by

built-in flash light

Group setting 4 groups

Monitor

Monitor type Tiltable LCD - Touch Panel

Monitor size 7.6cm / 3.0'' (3:2)

Resolution 1037000 dots

Brightness adjustment +/- 7 levels

Colour balance +/- 7 levels Vivid (default) /

Natural

Touch Control fucntions AF area enlargement

AF area selection

Enlargement

Enlargement playback

Frame forward/backward

Live Guide

Scene Modes

Shooting mode

Shutter release

Super Control Panel

Wifi connection

Level Gauge

Detection 2-axis

Display Rear display and viewfinder

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Super Control Panel

Displayed information Battery indicator

Record mode

Shutter speed

Aperture value

Exposure compensation

indicator

ISO

AE bracketing

AF frame

Focus mode

AEL notification

Face detection

Number of storable frames

Metering mode

Exposure mode

Exposure level view

Flash compensation value

Colour space

Gradation

Colour saturation

compensation value

Sharpness compensation

value

Contrast compensation value

White balance

White balance compensation

value

Noise reduction

Flash mode

Drive mode

Internal temperature warning

Histogram

Recording Formats

RAW 12bit

RAW & JPEG Yes parallel recording

JPEG Yes

Aspect ratio 4:3 / 3:2 / 16:9 / 6:6 / 3:4

MPO (3D) Yes

Image Size

RAW 4608 x 3456 compressed /

17MB / frame

4608 x 3456 Fine

(compression: 1/4) / 7.5MB /

frame

4608 x 3456 Normal

(compression: 1/8) / 3.5MB /

frame

2560 x 1920 Normal

(compression: 1/8) 1.1MB /

frame

1024 x 768 Normal

(compression: 1/8) / 0.3MB /

frame

Still Image Recording

EXIF 2.2

PIM III

DPOF Yes

DCF Yes

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Movie Recording System

Recording format MOV(MPEG-4AVC/H.264),

AVI(Motion JPEG)

Image Stabilisation Mode Yes Sensor shift (5-axis)

HD Movie quality Full HD 1920 x 1080 (16:9)

30p, 20Mbps (MOV)

Full HD 1920 x 1080 (16:9)

30p, 17Mbps (MOV)

HD 1280 x 720 (16:9) 30p,

13Mbps (MOV)

HD 1280 x 720 (16:9) 30p,

10Mbps (MOV)

HD 1280 x 720 (16:9) / 30fps

(AVI Motion JPEG®)

Movie quality 640 x 480 / 30fps (AVI Motion

JPEG®)

Time laps 1280 x 720 / 10fps (AVI

Motion JPEG®)

29min (17Mbps)

14min (SD) / 7min (HD) (AVI

Motion JPEG®)*

Max. file size 4GB (AVCHD)

2GB (Motion-JPEG)

Exposure Modes Aperture priority

Art Filter

Manual

Programme automatic

Shutter priority

* Some Art Filters are

excluded

Movie effects Multi shot echo

One shot echo

Art Filter

Sound Recording System

Internal microphone Stereo

Recording format Stereo PCM/16bit, 48kHz,

Wave Format Base

External microphone Optional

Image footage 30s

Speaker Yes

Microphone functions Wind Noise Reduction

Recording Volume

View Images

Modes Index

Calendar

Zoom

Slide show

Movie

Single

Light box Yes

Histogram in playback mode Yes

Shooting information Off / On

Erase / Protect / Copy Function

Erase modes Single, All, Selected

Image protect mode Single frame, Selected

frames, All Frames, Release

protect (Single/All selected)

Image Editing

RAW data edit Yes

Red-eye reduction Yes

Sepia Yes

Black & White Yes

Resize Yes

Correction of saturation Yes

Shadow Adjustment Yes

Trimming Yes

e-Portrait Yes

Gradation auto Yes

Menu languages in camera English, French, German,

Spanish, Italian, Russian,

Czech, Dutch, Danish,

Polish, Portuguese, Swedish,

Norwegian, Finnish, Croatian,

Slovenian, Hungarian,

Greek, Slovak, Turkish,

Latvian, Estonian, Lithuanian,

Ukrainian, Serbian

Customisation Options

Fn Button Yes

My Mode 4 settings storable

Factory reset Full / Standard

Programmable button Yes

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Interface

Media SD Memory Card (SDHC,

SDXC, UHS-I compatible)

Class 6 is recommended for

Movie shooting

HDMI™ Yes Micro connector (Type D)

USB 2.0 High Speed Yes

Combined V & USB output Yes NTSC or PAL selectable

Wireless connectivity WiFi

* �HDMI�, the HDMI logo and

�High-Definition Multimedia

Interface� are trademarks

or registered trademarks of

HDMI Licensing LLC.

Wi-Fi Functions

GPS info Available through

Smartphone GPS data

Wireless Shooting Live View

Rec View

Touch AF & Shutter

Self timer

Power off

Image Share File type: JPEG, MOV

Simultaneuosly connectable

devices: 4

Privacy function

Easy Connection QR code setting

Note: Shooting mode is fixed

on i-Auto

Power Supply

Battery BLN-1 Lithium-Ion Battery

Sleep mode 1, 3, 5, 10 min. and off

selectable.

Live View shooting Approx. 400images (50%

with Live View)

Environment

Temperature 0 - 40°C operating

temperature / -20 - 60°C

storage temperature

Humidity 30 - 90% operation humidity /

10 - 90% storage humidity

Size

Dimensions (W x H x D) 122.3 x 68.9 x 37.2mm

(without protrusions)

Weight 420g (including battery and

memory card)

378g (body only)

Exterior

Available Colours Black

Silver

White

Tabla de contenidos

Otros manuales de Cámara digital de Olympus

Olympus

Olympus X-560WP - Digital Camera - Compact Guía de inicio rápido

Olympus

Olympus SP-510 Manual de usuario

Olympus

Olympus E-PL3 Manual de usuario

Olympus

Olympus Super DLX IS-10 Manual de usuario

Olympus

Olympus Digital Vision D-220L Manual de usuario

Olympus

Olympus 225755 - Stylus 700 7.1MP Digital Camera Manual de usuario

Olympus

Olympus CAMEDIA C-470 Zoom Guía de instalación

Olympus

Olympus T-100 Manual de instrucciones

Olympus

Olympus SP-560 Manual de usuario

Olympus

Olympus OmniScan SX Manual de usuario

Olympus

Olympus FE-4050 Manual de usuario

Olympus

Olympus CAMEDIA D-400 Zoom Manual de usuario

Olympus

Olympus SP-620UZ Instrucciones de montaje

Olympus

Olympus E-450 Guía de configuración

Olympus

Olympus Stylus-7000 Manual de usuario

Olympus

Olympus FE-250/X-800 Manual de usuario

Olympus

Olympus CAMEDIA C-7070 Wide Zoom Instrucciones de funcionamiento

Olympus

Olympus CAMEDIA C-200 Zoom Manual de usuario

Olympus

Olympus 800 - Superzoom 800 Guía de configuración

Olympus

Olympus VG-170 Manual de usuario

Olympus

Olympus IS-50 Manual de usuario

Olympus

Olympus SP-600UZ Manual de usuario

Olympus

Olympus 7010 - Stylus Digital Camera Instrucciones de montaje

Olympus

Olympus FE 230 - Digital Camera - Compact Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
