Olympus E-400 Manual de usuario

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

E-400

• Ultra-light. Ultra-compact. • 10 Megapixels CCD sensor

• Strong dust reduction

(Supersonic Wave Filter)

• 6.4cm / 2.5'' HyperCrystal

LCD

• Built-in pop-up flash • User-friendly menu with

detailed and simplified

display modes

• 31 shooting modes for

trouble-free photography

• AF-lock functionality

The compact size and low weight of this latest Four Thirds Standard camera in the Olympus E-System grant photographers the

freedom to take it along nearly anywhere, while not having to do without the considerable benefits of SLR photography.

This model features a newly-developed CCD with 10.0 million pixels for incredible imaging performance and a large 2.5”/6.4cm LCD to

view results in comfort.

Specifications

Type

Lens mount Four Thirds mount

Body material Glassfibre reinforced plastics

Image Sensor

Effective pixels 10 Megapixels

Filter array Primary colour filter (RGB)

Full resolution 10.8 Megapixels

Type 4/3'' CCD sensor

Aspect ratio & area 4:3 / 17.3 x 13.0mm

Filter

LPF filter Fixed type

IR cut filter Hybrid type

Dust reduction filter Supersonic Wave Filter

Viewfinder

Viewfinder type Eye-level single-lens

viewfinder

Field of view Approx. 95%

Magnification Approx. 0.92x with a 50mm

lens set to infinity at -1

dioptre

Depth of field preview Yes

Eye point 14mm at -1 dioptre

Diopter adjustment -3.0 - +1.0 diopter / built-in

type

Focusing screen Fixed type (Neo Lumi-Micron

Mat Screen)

Mirror Quick return mirror

Displayed information

Eye piece shutter Eye-piece cap EP-4 supplied

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Focusing System

Method TTL phase difference

detection system

Focus areas 3 points / Automatic and

manual selection

AF illuminator Yes , Built-in flash (external

flash available)

AF lock Yes , Locked by first position

of shutter release button in

single AF mode, AE/AF lock

button (customised)

AF tracking Yes , Available in continuous

AF mode

Detection range 0 - 19 EV (ISO 100)

Exposure System

Exposure compensation +/- 5EV / 1/3 steps

Exposure bracketing 3 frames / +/- 1/3, 2/3, 1 EV

steps

Scene Modes

Number of scene modes 19

Light Metering

Method TTL open aperture light

metering

Zones 49 zones Multi-pattern

Sensing System

Detection range 1 - 20 EV (50mm, 1:2, ISO

100)

Sensitivity

Auto ISO 100 - 1600

Manual ISO 100 - 1600 (in each 1/3

EV steps possible). Warning

message at ISO 800-1600.

Shutter

Shutter type Electronically controlled focal

plane shutter

Shutter release Soft Touch Electromagnetic

Self timer 12s / 2s

Shutter Speeds

Shutter speed range 1/4000 - 60s (up to 8 min in

Bulb mode depends on ISO

speed)

Shutter speed P, Ps 1/4000 - 60s (depends on

settings)

Shutter speed A priority 1/4000 - 2s

Shutter speed S priority 1/4000 - 60s

Shutter speed Manual 1/4000 - 60s (up to 8 min in

Bulb mode depends on ISO

speed)

Shutter speed scene mode 1/4000 - 4s

White Balance

AUTO WB system Advanced detection system

with CCD imager

Manual White balance (One-

Touch)

Yes

Selectable steps in Kelvin 7 steps (3000 - 7500 K)

White balance adjustment +/- 7 in each R-B / G-M axis

(in Auto WB and preset WB

mode)

Sequence Shooting

Sequential shooting mode 3fps / 10 frames (approx.) in

HQ JPEG mode

3fps / 5 frames RAW & TIFF

Image Processing

Colour space sRGB / AdobeRGB

Sharpness + Contrast 5 levels

Saturation 5 levels

Contrast 5 levels

Black & White filter Yellow, Orange, Red, Green

Black & White toning Sepia, Blue, Purple or Green

in Black & White mode

Picture mode Vivid, Natural, Muted, Black &

White, Sepia.

Gradation 3levels

Engine TruePic TURBO

Internal Flash

Guide number 10

Flash compensation +/- 2 EV / 1/3 EV steps

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

External Flash Control

X-sync speed 1/180s / 1/4000s (Super FP

Mode)

Type TTL Auto for Olympus

dedicated flash, Auto or

Manual

Modes Auto

Manual

Red-eye reduction

Slow synchronisation with

red-eye reduction

Slow synchronisation

2nd curtain and slow

synchronisation

Fill-in for exclusive flash

Intensity +/- 2 EV / 1/3 EV steps

Monitor

Resolution 215000 dots

Monitor type HyperCrystal LCD

Monitor size 6.4cm / 2.5''

Brightness adjustment +/- 7 levels

Recording Formats

RAW 12bit

RAW & JPEG parallel recording

JPEG Yes

JPEG compression 1/2.7SHQ 1/8HQ 1/2.7, 1/4,

1/8, 1/12SQ

Image Size

SHQ 3648 x 2736

HQ 3648 x 2736

SQ 3200 x 2400

2560 x 1920

1600 x 1200

1280 x 960

1024 x 768

640 x 480

Still Image Recording

EXIF 2.2

PIM III

DPOF Yes

DCF Yes

View Images

Histogram in playback mode Yes

Zoom 2-14x

Index 4, 9, 16, 25 frames

Slide show Yes

Calendar Yes

Shooting information Exposure mode, metering

mode, shutter speed,

aperture value, exposure

compensation level, ISO,

colour space, white balance

mode, white balance

compensation level, focal

length, focus area, file type,

picture mode, file name,

image size, recorded card

type.

Exposure level view Histogram (R,G,B available),

High light point warning,

Shadow point warning.

Erase / Protect / Copy Function

Erase modes Single, All, Selected

Image protect mode Single, Selected

Copy mode Single, All, Selected

Image Editing

RAW data edit Yes

Red-eye reduction Yes

Sepia Yes

Black & White Yes

Resize Yes

Correction of saturation Yes

Menu languages in camera English, German, French,

Spanish, Italian, Russian,

Czech, Dutch, Danish, Polish

Menu languages by download Additional one language

from 15 further languages by

download via the internet.

Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer

Interface

Media Dual slot for CompactFlash

card (Type I and II), Microdrive

and xD picture card

USB 1.1 Yes

Combined V & USB output Yes NTSC or PAL selectable

Ethernet 10/100 Yes

Infrared Yes

Combined A/V & USB output Yes

USB 2.0 compatible Yes

USB 2.0 High Speed Yes

Video out Yes

Power Supply

Battery BLS-1 Li-Ion battery

(included)

Battery life Approx. 400 shots with

BLS-1 under CIPA testing

standard.

Sleep mode 1, 3, 5, 10 min. and off

selectable.

Environment

Temperature 0 - 40°C operating

temperature / -20 - 60°C

storage temperature

Humidity 30 - 90% operation humidity /

10 - 90% storage humidity

Size

Dimensions (W x H x D) 129.5 x 91 x 53mm (without

protrusions)

Weight 375g (body only)

***For kits contact your local Olympus representatives.
