Olympus CAMEDIA C-350ZOOM Manual de usuario

zThis manual contains guidelines for using Olympus D-560ZOOM/

C-350ZOOM.

zIn the interest of continually improving products, Olympus reserves the

right to update or modify information contained in this manual.

DIGITAL CAMERA

D-560ZOOM

C-350ZOOM

MANUAL FOR DIRECT PRINTING

Manual outlining new features added to the camera with firmware update.

About this manual

Update the camera’s firmware to enable PictBridge on your camera. This will

allow you to print pictures directly from the camera by connecting it to a printer

that supports PictBridge with the USB cable.

This manual explains additional functions, and different operations that are

available when the camera’s firmware has been updated. These functions

and operations are different than what is stated in the Reference Manual that

originally provided with your camera.

What is PictBridge? … It is the standard for connecting digital cameras and

printers of different makers and printing out pictures directly.

Indications used in this manual

Important information on factors which may lead to a

malfunction or operational problems. Also warns of operations that

should be absolutely avoided.

Useful information and hints that will help you get the most out of

your camera.

gReference pages describing details or associated information.

Reference pages describing details or associated information in

the CD reference manual. See the English reference manual for

details.

Note

Contents

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1 Functions changed by updating the

firmware 4

Connection to a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Direct printing function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Direct printing 6

Using the direct printing function . . . . . . . . . . . . . . . . . . . . . . . . 6

Connecting the camera to a printer . . . . . . . . . . . . . . . . . . . . . . 7

Printing pictures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

PRINT mode/MULTI PRINT mode . . . . . . . . . . . . . . . . . . . 8

ALL PRINT mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ALL INDEX mode/PRINT ORDER mode . . . . . . . . . . . . . 14

Exiting direct printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

If an error code is displayed . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Functions changed by updating the firmware

Connection to a computer

When the USB cable is used to connect the camera to a computer, follow

the procedure below to select PC in the camera settings.

1Insert the marked end of the provided USB cable into the

USB port on your computer as shown below.

• The location of the USB port varies depending on the computer.

For details, refer to your computer’s manual.

2Plug the other end of the USB cable

into the camera’s USB connector.

3Press qto turn the camera on.

• The monitor turns on and the selection

screen for the USB connection is

displayed.

Look for this mark.

USB port

Terminal

Note

Playback button (q)

Direct printing function

4Press ac to select PC and

press e.

5The computer recognizes the camera as a new device.

• When you connect the camera to the computer for the first time, the

computer automatically recognizes the camera. Click “OK” when the

message saying that the installation is completed appears.

• The computer recognizes the camera as a “Removable Disk”.

After updating the camera’s firmware to enable PictBridge, pictures can be

printed directly from the camera. By connecting the camera directly to a

printer that supports PictBridge with the USB cable, you can print pictures

stored on the card inside the camera without a need to use a computer.

For details of printing instructions, see “Direct printing” (gP.6).

SELECt

OK button

Arrow pad

Direct printing function

2 Direct printing

Using the direct printing function

By connecting the camera to a PictBridge-compatible printer with the USB

cable, you can print out recorded pictures directly without the use of a

computer. With the camera connected to the printer, use the camera’s

monitor to select the pictures you want to print, and the number of prints you

want to make. It is also possible to print out pictures using the print

reservation data. “Print setting” (P.108)

To find out if your printer is compatible with PictBridge, refer to the printer’s

instruction manual.

What is PictBridge? … It is the standard for connecting digital cameras and

printers of different makers and printing out pictures directly.

<STANDARD … All printers that support PictBridge have standard print

settings. Selecting <STANDARD on the settings screens (gP.9 to 14),

images are printed according to the default settings. See the instruction

manual for your printer for its standard settings or inquire with the printer

manufacturers.

TIPS

• For details of printing paper types, ink cassettes, etc., refer to the

printer’s instruction manual.

• You are recommended to use the optional AC adapter for the

camera when printing pictures directly. If you use the battery, make

sure that it is fully charged. If you are using alkaline batteries, make

sure that you use new batteries. If the camera stops operating

while communicating with the printer, the printer may malfunction

or image data may be lost.

• Images recorded in movie mode cannot be printed.

• The camera will not enter sleep mode when connected to the USB

cable.

Note

Connecting the camera to a printer

Use the USB cable provided with the camera to connect it to a PictBridge-

compatible printer.

1Turn the printer on and plug the

printer end of the USB cable into

the printer’s USB port.

• For details of how to turn the printer on

and the position of the USB port, refer to

the printer’s instruction manual.

2Plug the other end of the USB cable

into the camera’s USB connector.

3Press qto turn the camera on.

• The monitor turns on and the selection

screen for the USB connection is

displayed.

4Press ac to select PRINT, then

press e.

• ONE MOMENT is displayed and the

camera and printer are connected. The

PRINT MODE SELECT screen is

displayed on the monitor. Make the print

settings on the camera’s monitor.

gGo to “Printing pictures” (P.8).

• When the USB mode is set to PC, the PRINT MODE SELECT

screen is not displayed. Remove the USB cable, and repeat the

procedure from Step 1.

Playback button (q)

SELECt

Note

Printing pictures

When the camera is connected to a PictBridge-

compatible printer, the PRINT MODE SELECT

screen is displayed on the monitor. Use this

screen to select the print mode. You can choose

from the following print modes.

PRINT Prints the selected picture.

g“PRINT mode/MULTI PRINT mode” (P.8)

ALL PRINT Prints all the pictures stored on the card.

g“ALL PRINT mode” (P.12)

MULTI PRINT * Prints one picture in multiple layout format.

g“PRINT mode/MULTI PRINT mode” (P.8)

ALL INDEX * Prints an index of all the pictures stored on the card.

g“ALL INDEX mode/PRINT ORDER mode” (P.14)

PRINT ORDER * Prints the pictures according to the print reservation data

on the card. If no print reservations ( “Print setting”

(P.108)) have been made, this option is not available.

g“ALL INDEX mode/PRINT ORDER mode” (P.14)

* This option may not be available depending on the type of printer.

PRINT mode/MULTI PRINT mode

1In the PRINT MODE SELECT

screen, press ac to select

PRINT or MULTI PRINT, then press

• The print size settings screen is

displayed.

SELECt

EXIt

OK button

Arrow pad

Zoom lever

Printing pictures

2Press ac to select the paper

size, then press d.

•PRINT mode: Go to step 3.

•MULTI PRINT mode:Go to step 4.

• The available paper size settings vary

depending on the type of printer.

• When the PRINT PAPER screen is not

displayed, SIZE, BORDERLESS and

PICS/SHEET are set to <STANDARD. Go to step 5.

3Use ac to select framed or

unframed, then press e.

Go to step 5.

OFF ( ) The image is printed

inside a blank frame.

ON ( ) The image is printed filling

the entire page.

4Press ac to select PICS/SHEET,

then press e.

• PICS/SHEET depends on the paper size

set in step 2 and the capabilities of your

printer.

5Press bd to select the picture you

want to print.

• Turn the zoom lever toward to

display the pictures in index format. You

can then select the pictures you want to

print from the index.

6Select the print reservation method.

SINGLE PRINT Makes a single-frame print reservation for the

selected picture according to standard settings.

MORE Sets the number of prints of the selected picture in

the print reservation data. You can also add the date

or file name.

PRINt PAPER

SIZE

BORDERLESS

CANCEL

SELECt

StANDARD

PRINt PAPER

SIZE

BORDERLESS

StANDARD

SELECt

SIZE

PICS/SHEEt

StANDARD

SELECt

PRINt PAPER

SELECt

SINGLE

PRINT MODE screen

Printing pictures

zSet a SINGLE PRINT reservation

Press a.

•Pressawhen <is displayed to cancel

the reservation.

zSet MORE print reservations

cPress c.

• Print information setting screen is displayed.

dPress ac to select the item

you want to set, then press d.

• Press ac to select the item, then

press e.

• The available options vary depending

on the type of printer. Items outside

the capability of the printer are not

available.

<× Sets the number of prints.You can

select up to 10 prints.

DATE ( ) If you select WITH, pictures are printed

with the date and time.

FILE NAME ( ) If you select WITH, pictures are printed

with the file name.

• DATE and FILE NAME are not available in MULTI PRINT mode.

SELECt

CANCEL

Print reservation

mark is displayed.

SELECt

SEt

FILE NAME

WItHOUt

Otros manuales para CAMEDIA C-350ZOOM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Olympus

Olympus

Olympus D-390 - 2 MP Digital Camera Manual de usuario

Olympus

Olympus FE 200 Manual de instrucciones

Olympus

Olympus Stylus 730 Guía de inicio rápido

Olympus

Olympus CAMEDIA C-450 Zoom Manual de usuario

Olympus

Olympus FE 100 - 4MP Digital Camera Manual de usuario

Olympus

Olympus 226065 - Stylus 820 Digital Camera Manual de usuario

Olympus

Olympus Camedia C-750 Ultra Zoom Manual de usuario

Olympus

Olympus CAMEDIA C-200Zoom Guía de instalación

Olympus

Olympus FE220 - 7.1 MP Digital Camera Guía de instalación

Olympus

Olympus CAMEDIA C-740 Ultra Zoom Guía de instalación

Olympus

Olympus E420 - Evolt 10MP Digital SLR Camera Manual de usuario

Olympus

Olympus CAMEDIA C-100 Manual de usuario

Olympus

Olympus FE-5035 Manual de usuario

Olympus

Olympus FE 230 - Digital Camera - Compact Guía de instalación

Olympus

Olympus TG-835 Manual de usuario

Olympus

Olympus Stylus TG-Tracker Manual de usuario

Olympus

Olympus SP-550UZ Manual de usuario

Olympus

Olympus SH-1 Manual de usuario

Olympus

Olympus E420 - Evolt 10MP Digital SLR Camera Manual de usuario

Olympus

Olympus C 725 - CAMEDIA Ultra Zoom Digital Camera Guía de instalación

Olympus

Olympus X-840 Manual de usuario

Olympus

Olympus S701 - Pearlcorder Microcassette Dictaphone Guía de configuración

Olympus

Olympus 225905 - Stylus 760 Digital Camera Manual de usuario

Olympus

Olympus FE 300 - Digital Camera - Compact Guía de instalación

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
