Olympus C-315ZOOM Guía de instalación

DIGITAL CAMERA

APPAREIL PHOTO NUM

ÉRIQUE

DIGITALKAMERA

CÁMARA DIGITAL

C-315ZOOM

BASIC MANUAL

MANUEL DE BASE

EINFACHE ANLEITUNG

MANUAL BÁSICO ENGLISH

FRANÇAIS

DEUTSCH

ESPAÑOL

basic.book Page 1 Sunday, May 22, 2005 6:47 PM

2En

CONTENTS/TABLE DES MATIÉRES/INHALT/CONTENIDO

ENGLISH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

FRANÇAIS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

DEUTSCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

CONTENTS

GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

MENU FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

SHOOTING BASICS . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

ADVANCED SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 29

PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

PRINT RESERVATION /DIRECT PRINT . . . . . . . . . . . . 35

DOWNLOADING PICTURES TO A COMPUTER . . . . . 36

ERROR CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

These instructions are only for quick reference. For more details

on the functions described here, refer to the “Reference Manual”

on CD-ROM.

basic.book Page 2 Sunday, May 22, 2005 6:47 PM

En 3

JBefore using your camera, read this manual carefully to ensure correct use.

JWe recommend that you take test shots to get accustomed to your camera before

taking important photographs.

JThese instructions are only a basic manual. For more details on the functions described

here, refer to the Reference Manual on the CD-ROM.

For customers in Europe

IMAGELINK Print System compatible

Print directly from IMAGELINK Print System compatible products, Kodak Printer

Dock Series 3.

Trademarks

• IBM is a registered trademark of International Business Machines Corporation.

• Microsoft and Windows are registered trademarks of Microsoft Corporation.

• Macintosh is a trademark of Apple Computer Inc.

• ImageLink is trademarks of the Eastman Kodak Company.

• xD-Picture CardTM is a trademark.

• All other company and product names are registered trademarks and/or

trademarks of their respective owners.

• The standards for camera file systems referred to in this manual are the “Design

Rule for Camera File System/DCF” standards stipulated by the Japan Electronics

and Information Technology Industries Association (JEITA).

Camera insert

“CE” mark indicates that this product complies with the European

requirements for safety, health, environment and customer

protection. “CE” mark cameras are intended for sales in Europe.

This symbol [crossed-out wheeled bin WEEE Annex IV] indicates

separate collection of waste electrical and electronic equipment in

the EU countries.

Please do not throw the equipment into the domestic refuse.

Please use the return and collection systems available in your

country for the disposal of this product.

When camera is connected with the ImageLink compatible printer,

bundled camera insert is needed.

basic_e_p_7.fm Page 3 Monday, May 23, 2005 9:57 AM

4En

GETTING STARTED

JNAMES OF PARTS

Shutter button

Flash

Self-timer lamp

USB connector cover

DC-IN jack

USB connector

Lens

Extends automatically when

you set the shooting mode.

Zoom lever

(W/T• )

Card cover

Strap eyelet

DC-IN jack cover

Card slot

basic.book Page 4 Sunday, May 22, 2005 6:47 PM

En 5

Play back mode

Shooting mode

Lock button

QUICK VIEW button

Self-timer button ( )

Monitor

Macro button ( )

Viewfinder

Tripod socket

Flash mode button ( )

Arrow pad

()

Power switch

OK/Menu button (Z)

Battery compartment

cover

Arrow pad

Shooting mode button

(:VirtualDial)

Buttons on the arrow pad have their respective functions. They are also

used as direction buttons. , , and indicate which button to

be pressed.

Power switch

* This is the connector to connect the camera to the ImageLink printer.

Printer

connector*

basic.book Page 5 Sunday, May 22, 2005 6:47 PM

6En

JMONITOR INDICATIONS

Shooting mode

Items Indications

1 Shooting mode , , , , , ,

2 Battery check ,

3 Green lamp

4 Flash standby

Camera movement warning/Flash charge

(Lit)

(Blinks)

5 Macro mode ,

6 Flash mode , ,

7 Sequential shooting ,

8Self-timer

9 Record mode SHQ, HQ, SQ1, SQ2

10 Resolution 2592×1944, 1600×1200, 640×480, etc.

11 Exposure compensation

-2.0, -1.5, -1.0, -0.5, +0.5, +1.0, +1.5, +2.0

12 White balance , , ,

13 AF target mark [ ]

14 Memory gauge , , ,

15 Number of storable still pictures

Remaining recording time

00:36

12 5

Still picture Movie

basic.book Page 6 Sunday, May 22, 2005 6:47 PM

En 7

Playback mode

Screens when the information display is set to ON are shown below.

Items Indications

1 Print reservation,

Number of prints

×10

2 Battery check ,

3Protect

4 Record mode SHQ, HQ, SQ1, SQ2

5 Resolution

2592

1944, 1600

1200, 640

480, etc

6 Exposure compensation

-2.0, -1.5, -1.0, -0.5, +0.5, +1.0, +1.5, +2.0

7 White balance WB AUTO, , , ,

8 Date and time '05.09.01 12:30

9 File number (still picture),

Number of frames

Elapsed time

/Total recording time (movie)

100-0016,

00:00/00:15

10 Movie

Still picture Movie

basic.book Page 7 Sunday, May 22, 2005 6:47 PM

8En

Memory gauge

The memory gauge lights up when you take a still picture. While the gauge is

lit, the camera is storing the picture on the card.The memory gauge indication

changes as shown below depending on the shooting status.

The indication is not displayed during movie recording.

Battery check

If the remaining battery power is low, the battery check indication on the

monitor changes as follows while the camera is turned on.

Before shooting

(Gauge is off)

No more pictures can

be taken (Fully lit).

Wait until the gauge

returns to the status

on the left to take the

next shot.

One picture

taken

(Lit)

Two or more

taken

(Lit)

Shoot Shoot Shoot

Wait

* The memory gauge indication may not be displayed depending on the record mode

you selected.

Lit (Green) Blinks (Red)

"BATTERY EMPTY"

is displayed.

Remaining power level:

exhausted.

Replace with a new batteries.

Remaining power level: low.

Prepare new batteries.

(The indicator turns

off after a while.)

Remaining power

level: high.

basic.book Page 8 Sunday, May 22, 2005 6:47 PM

En 9

JATTACHING THE STRAP

1Thread the short end of the

strap through the strap eyelet.

2Thread the long end of the

strap through the loop that

has already gone through the

eyelet.

3Pull the strap tight, making

sure that it is securely

fastened and does not come

loose.

JLOADING THE BATTERIES

1Make sure that the power switch is located at OFF.

2Slide the battery compartment

cover in the direction of .

• The battery compartment cover is

unlocked and opened in the

direction of .

• Use the ball of your finger to slide

the cover. Do not use your fingernail

as this could result in injury.

Strap eyelet

Power switch

Battery

compartment cover

basic.book Page 9 Sunday, May 22, 2005 6:47 PM

10 En

3Insert the batteries, making sure that they are correctly

oriented as shown in the illustration.

The battery insertion direction mark is provided inside of the battery

compartment.

4Close the battery compartment

cover, then press it down

and slide it in the direction

shown .

• If the battery compartment cover

seems hard to close, do not force it.

With the battery compartment cover

shut, press the mark firmly and

push it in the direction indicated by

When using AA (R6) batteries When using a CR-V3 lithium battery

pack

When using a CR-V3 lithium

battery pack, insert it in the

direction as shown in the

illustration.

There is a mark showing the

correct way to insert the AA

batteries on the bottom of the

camera.

Battery insertion

direction mark

Important

• CR-V3 lithium battery cannot be recharged.

• Do not peel off the label from a CR-V3 lithium battery pack.

• Manganese (zinc-carbon) batteries cannot be used.

basic.book Page 10 Sunday, May 22, 2005 6:47 PM
