Title: Control Codes for the OL400e / OL410e / OL410e-PS

Replaces Doc #:

Product Model: OL400e, OL410e, OL410e-PS

This document contains the complete command set for the OL400e, OL410e and the OL410e/PS (PCL

Mode) printer emulations. Usually these codes will be transparent to the user. We include the command

set for those software applications which require you to enter printer commands to select printer features.

About the Escape Sequences

In the sequences below, ESC represents the escape character (decimal 27,

hexadecimal 1B). The letters l and O are printed in italics to distinguish them

from the numbers 1 and 0.

The spaces in the font command sequences were added for legibility. Do not

enter them as part of a command.

In all font-related escape sequences the character `` ( '' is used to indicate

primary font characteristics. You should substitute the character`` ) '' for a

secondary font.

The font commands below include the escape sequences that specify all of each

font's characteristics. In some cases the entire sequence is not necessary to

change fonts, but if you shorten the sequence, keep two things in mind, in

order to avoid unexpected results:

Make sure that the new font you requested (bold or italic, for

example) is available.

Remember that a higher priority font characteristic will override a

lower priority one.

Escape sequences with the same beginning characters can be combined. To do

this, change the final letter of the first sequence from upper case to lower case

and omit the common characters. For example, combining proportional

spacing ESC(s1P with 10 point character height ESC(s10V results in

the following:

ESC(s1p10V

Keep in mind that there should only be one uppercase letter in a combined

sequence, and that uppercase letter must come at the end of the sequence. Also

remember that the commands are executed in the order in which they are

given.

Commands Specific to OL400e (HP LaserJet Series IIP)

OL400e Function Command Notes

Select common character pitch ASCII: ESC & k # S Dec: 27

38 107 # 83 #=0: 10 cpi #=2: 16.66 cpi #=4:

12 cpi

Primary font default ASCII: ESC ( # @ Dec: 27 40

# 64 #=0 or 1: makes default

symbol set active for primary

font in current orientation

#=2: causes printer to

re-evaluate best font choice for

current specified primary font

and primary symbol set in

current orientation.

#=3: makes primary font the

default font in the current

orientation

Secondary font default ASCII: ESC ) # @ Dec: 27 41

# 64 #=0: makes default symbol set

the set for secondary font in

current orientation

#=1: makes secondary symbol

set same as default primary

font in current orientation

#=2: makes secondary symbol

set same as current primary

symbol set in current

orientation

#=3: selects default secondary

font in current orientation

Specify primary font symbol

set ASCII: ESC ( # `ID' Dec: 27 40

35 `ID' #=01 through 39 (see Symbol

Set Selection Commands table

below). ID=D, E, F, G, I, J, K,

M, N, Q, S, U, Y, Z, depending

on font to be engaged.

Specify secondary font symbol

set ASCII: ESC ) # `ID' Dec: 27 40

35 `ID' n=01 through 39 (see Symbol

Set Selection Commands table

below). ID=D, E, F, G, I, J, K,

M, N, Q, S, U, Y, Z, depending

on font to be engaged.

Specify primary font character

spacing ASCII: ESC ( s # P Dec: 27 40

115 # 80 #=0: fixed (default)

#=1: proportional

#=-1: compressed proportional

Specify secondary font

character spacing ASCII: ESC ) s # P Dec: 27 41

115 # 80 #=0: fixed (default)

#=1: proportional

#=-1: compressed proportional

Specify primary font character

pitch ASCII: ESC ( s # H Dec: 27 40

115 # 72 #=characters per inch (cpi).

Default is 10 cpi.

Specify secondary font

character pitch ASCII: ESC ) s # H Dec: 27 41

115 # 72 #=characters per inch (cpi).

Default is 10 cpi.

Specify primary font character

height ASCII: ESC ( s # V Dec: 27 40

115 # 86 #=point size (default is 12 pt.)

Specify secondary font

character size (height) ASCII: ESC ) s # V Dec: 27 41

115 # 86 #=point size (default is 12 pt.)

Specify primary font character

style ASCII: ESC ( s # S Dec: 27 40

115 # 83 #=0: upright (default)

#=1: italic

Specify secondary font

character style ASCII: ESC ) s # S Dec: 27 41

115 # 83 #=0: upright (default)

#=1: italic

Specify primary font weight ASCII: ESC ( s # B Dec: 27 40

115 # 66 #=-7 to +7

#=-1 to -7: light

#=0: normal (default)

#=+1 to +7: bold

Specify secondary font weight ASCII: ESC ) s # B Dec: 27 41

115 # 66 #=-7 to +7

#=-1 to -7: light

#=0: normal (default)

#=+1 to +7: bold

Specify primary font typeface ASCII: ESC ( s # T Dec: 27 40

115 # 84 #=0: like Line Printer

#=1: like Pica

#=2: like Elite

#=3: line Courier

#=4: like Helv

#=5: like Times Roman

#=6: like Gothic #=7: like Script

#=8: like Prestige

#=90: like Caslon #=10: like

Orator

#=11: like Presentations

#=14: like Swiss 721

#=15: like Dutch 801

#=17: like Optima

#=1 or 19: like Cooper Black

#=20: like Coronet Bold

#=21: like Broadway

#=22: like Bauer Bodoni Black

Condensed #=24: like Century

Schoolbook #=25: like

University Roman

Specify secondary font type

face ASCII: ESC ) s # T Dec: 27 41

115 # 84 #=0: like Line Printer

#=1: like Pica

#=2: like Elite

#=3: like Courier

#=4: like Helv

#=5: like Times Roman

#=6: like Gothic

#=7: like Script

#=8: like Prestige

#=90: like Caslon

#=10: like Orator

Specify font ID ASCII: ESC * c # D Dec: 27 42

99 # 68 #=0 (default) to 32,767

OL400e Font Commands

OL400e Font Printer Command

Courier 12 point ESC(8U ESC(s 0p 10h 12v 0s 0b 3T

Courier 12 point bold ESC(8U ESC(s 0p 10h 12v 0s 3b 3T

Courier 12 point italic ESC(8U ESC(s 0p 10h 12v 1s 0b 3T

Courier 10 point ESC(8U ESC(s 0p 12h 10v 0s 0b 3T

Courier 10 point bold ESC(8U ESC(s 0p 12h 10v 0s 3b 3T

Courier 10 point italic ESC(8U ESC(s 0p 12h 10v 1s 0b 3T

Line Printer 8.5 point ESC(8U ESC(s 0p 16.66h 8.5v 0s 0b 0T

Swiss 14.4 point bold (B) ESC(0U ESC(s 1p 14.4v 0s 3b 4T

Swiss 14.4 point bold (F) ESC(8U ESC(s 1p 14.4v 0s 3b 4T

Dutch 10 point (B) ESC(0U ESC(s 1p 10v 0s 0b 5T

Dutch 10 point bold (B) ESC(0U ESC(s 1p 10v 0s 3b 5T

Dutch 10 point italic (B) ESC(0U ESC(s 1p 10v 1s 0b 5T

Dutch 10 point compressed (B) ESC(0U ESC(s -1p 10v 0s 0b 5T

Dutch 10 point compressed bold (B) ESC(0U ESC(s -1p 10v 0s 3b 5T

Dutch 10 point compressed italic (B) ESC(0U ESC(s -1p 10v 1s 0b 5T mm

OL400e Font Printer Command

Dutch 10 point (F) ESC(8U ESC(s 1p 10v 0s 0b 5T

Dutch 10 point bold (F) ESC(8U ESC(s 1p 10v 0s 3b 5T

Dutch 10 point italic (F) ESC(8U ESC(s 1p 10v 1s 0b 5T

Dutch 8 point (B) ESC(0U ESC(s 1p 8v 0s 0b 5T

Dutch 8 point compressed (B) ESC(0U ESC(s -1p 8v 0s 0b 5T

Dutch 8 point (F) ESC(8U ESC(s 1p 8v 0s 0b 5T

HP 12 point ZIP code ESC(15Y ESC(s 1p 12v 0s 0b 0T

USPS 9.1 point ZIP code, portrait orientation ESC(2X ESC(97Y ESC(s 0p 21.06h 9.1v 0s 0b

USPS 9.1 point ZIP code, landscape orientation ESC(12X ESC(97Y ESC(s 0p 21.06h 9.1v 0s

0b 0T

USPS 45.1 point FIM bar, portrait orientation ESC(1X ESC(98Y ESC(s 0p 18.75h 45.1v 0s

0b 0T

USPS 45.1 point FIM bar, landscape orientation ESC(11X ESC(98Y ESC(s 0p 18.75h 45.1v 0s

0b 0T

USPS 64.6 point Stamp Here, portrait

orientation ESC(3X ESC(99Y ESC(s 0p 1.18h 64.6v 0s 0b

USPS 64.6 point Stamp Here, landscape

orientation ESC(13X ESC(99Y ESC(s 0p 1.18h 64.6v 0s

0b 0T

Commands Specific to OL410e (HP4 LaserJet Series III Commands LaserJet Series III)

Font Commands

ID# Resident Fonts Command Sequence

00 Courier ESC(8U ESC(s 0p #h 0s 0b 4099T

01 Courier bold ESC(8U ESC(s 0p #h 0s 3b 4099T

02 Courier italic ESC(8U ESC(s 0p #h 1s 0b 4099T

03 Courier Italic Bold ESC(8U ESC(s 0p #h 1s 3b 4099T

04 CG Times ESC(8U ESC(s 1p #v 0s 0b 4101T

05 CG Times Bold ESC(8U ESC(s 1p #v 0s 3b 4101T

06 CG Times Italic ESC(8U ESC(s 1p #v 1s 0b 4101T

07 CG Times Bold Italic ESC(8U ESC(s 1p #v 1s 3b 4101T

08 Univers ESC(8U ESC(s 1p #v 0s 0b 4148T

09 Univers Bold (scalable) ESC(8U ESC(s 1p #v 0s 3b 4148T

10 Univers Italic ESC(8U ESC(s 1p #v 1s 0b 4148T

11 Univers Bold Italic ESC(8U ESC(s 1p #v 1s 3b 4148T

12 Line printer (bitmap) ESC(8U ESC(s 0p 16.66h 8.5v 0s 0b

OL410e Feature Command Notes

OL410e Unique Commands

Down load LCD message ESC/d#W[data]

PostNet Check Digit Print ESC/b#W[data]

Begin multiple collated copies ESC/m#S

End multiple collated copies ECS/m#E

Specify copy mark ESC/m#M

Port lockout/ resume(TRAP) ESC/i#L

Auto Emulation(TRAP) ESC DEL#

Select 600dpi class graphics ESC*t600R

Download 600dpi class bitmap Font Header=20

Set 600dpi class positioning ESC&m600D

PCL V Compacted Graphics

Temporary X offset ESC*b#X # must be a multiple of 8;

max.value, #3200

Transfer raster graphics ESC*b#W #decimal ASCII number

Full graphics mode ESC*b0M

Select graphics mode 1 ESC*b1M

Select graphics mode 2 ESC*b2M

Select graphics mode 3 ESC*b3M

OL410e Feature Command Notes

PCL V Vector Graphics

Commands

Select PCL mode, specify

cursor and palette ESC%#A #0: use previous cursor and

palette;

#1: use current HPGL/2 pen

and palette

Select HPGL/2 mode, specify

cursor and palette ESC%#B #0: use previous HPGL/2 pen

and palette;

#1: use cur- rent PCL cursor

and palette

HPGL/2 horizontal size in

inches ESC*c#K #0.01 to 32,767.99 inches

HPGL/2 vertical size in inches ESC*c#L #0.01 to 32,767.99 inches

Anchor point at PCL cursor ESC*c0T

HPGL/2 horizontal window size

in decipoints ESC*c#X #0.01 to 32,767.99 inches

HPGL/2 vertical window size in

decipoints ESC*c#Y #0.01 to 32,767.99 inches

Reset PCL and HPGL/2 ESCE

Set PCL rotation in 90

increments ESC&a#P #0,90,180, or 270; #0: return to

current default

Select transparency pattern ESC*c#T #0: solid black;

#1: solid white;

#2: current pattern; N3: current

cross-hatch pat- tern.

Select advanced graphics

source transparency ESC*L#N #0: transparent; #1: opaque

Select advanced graphics

pattern transparency ESC*L#0 #0: transparent; #1: opaque

HPGL/2 Commands

Backspace BS

Backspace HT

Line Feed LF

Carriage Return CR

Shift-in SI

Shift-out SO

Space SP

OL410e Feature Command Notes

End label code ETX

Inverse line feed:TRAP VT

Arc absolute AA x,y,arc,chd; xx coordinate; yy coordi- nate;

arcdegree of arc,

pos:counterclockwise,

neg:clockwise; chdchord

angle.

Anchor point AC x,y; Range of x, y is -67,108,863 to

67,108,863

Alternate text definition AD knd,val...,knd, val; kndintegers 1 to 7; knd1: char.

set specified and val-

32,767.9999 to 32,767.9999;

knd2: font spacing specified

and val0 or 1; knd3: font pitch

specified and val0 to

32,767.9999; knd4: font height

specified and val0 to

32,767.9999; knd5: do not use

this value; knd6: font stroke

weight and val- 7, -3, 0, 3, 7;

knd7: type- face specified and

val0 to 32,767.9999

Arc relative AR x,y,arc,chdp; xx coordinate, yy coordi- nate;

range of x and y is -67,108,863

to 67,108,863; arcdegree of

arc; chdchord angle

Arc absolute-three point AT xi,yi,xe,ye,chd; xiintermediate x coordi- nate,

yiintermediate y coor- dinate,

xeend x coor- dinate, yeend y

coordi- nate, chdchord angle;

range of xi, yi, xe, and ye is

-67,108,863 to 67,108,863

Character fill mode CF fm,ep;

Circle CI r, chd; xirradius of circle, chdchord

angle; range of r is

-67,108,863 to 67,108,863

OL410e Feature Command Notes

Character plot CP sp, lin; spnumber of char. spaces,

linnumber of char. lines; range

of sp and lin is -32,767.999 to

32,767.999

Set default values DF;

Direction absolute DI run,ris; runrun, risrise; range of run

and rise is -32,767.999to

32,767.999

Direction relative DR run,ris; runrun, risrise; range of run

and rise is -32,767.999 to

32,767.999

Define label terminator DT t,mod; t1 to 127, excluding 0, 10, 27,

59; mod0: label is printable;

mod1: label is not printable

Define variable text path DV pat,lin; pat0: text path is hori- zontal to

the right; pat1: text path is

vertical down; pat2: text path is

horizon- tal to the left; pat3:

text path is vertical up; lin0 or 1

Rectangle edge absolute EA x,y; xx coordinate, yy coordi- nate;

range of x and y is -67,108,863

to 67,108,863

Edge Polygon EP;

Rectangle edge relative ER x,y; xx coordinate, yy coordi- nate;

range of x and y is -67,108,863

to 67,108,863

Extra space ES wid, ht; Range of wid (width) and ht

(height) is -32,767.999 to

32,767.999

Wedge edge EW r,sa,sw,chd; rradius, sastart angle,

swsweep angle, chdchord

angle

Primary font by ID FI id; 3 id0 to 2048

Secondary font by ID FN id; id0 to 2048

Fill polygon FP;

Fill type FT typ,o1,o2; typ1 to 4, 10, 11; o10 to

32,767.999; o245 to -45

OL410e Feature Command Notes

Initialize IN n; n0 or 1

Input scaling points IP P1x,P1y,P2x,P2y; P1x0 to 10365 (letter) or

11040 (A4); P1y0 to 7962

(letter) or 7721 (A4); P2x0 to

10365 (letter) or 11040 (A4);

P2y0 to 7962 (letter) or 7721

(A4)

Input relative P1 and P2 IR P1x,P1y,P2x,P2y; P1x, P1y, P2x, P2y

-32,767.999 to 32,767.999

Input window points IW Xlo,Ylo,Xhi,Yhi; Xlo, Ylo, Xhi, Yhi -67,108,863

to 67,108,863

Line attributes LA knd,val...,knd,val; When knd1, val1: butt ends,

2: square ends, 3 triangular

ends, 4: round ends; when

knd2: val1: mitered joins, 2;

mitered/ beveled joins, 3:

triangular joins, 4: round joins,

5: bev- eled joins, 6: no join

applied; when knd23: val0 to

32,767.999

Label text LB c...ct c10, 13, 32 to 256, t is

previously defined by the DT

command

Line type LT typ,len,mod; typ-8 to 8, len0 to 32,767.999,

mod0 or 1

Label origin LO n; n1 to 19, excluding 10

Number of pens NP n; n2, 4, or 8

Plot absolute PA x1,y1...; Range of x1 and y1 is -

67,108,863

Pen down PD x1,y1...,xn,yn;

Polygon encoded PE flg val... x y; Range of flg is : or 7

Page advance PG n; n-32,767 to 32,767

Polygon mode PM n;

Plot relative PR x1,y1...,xn,yn;

Pen up PU x1,y1...,xn,yn;

OL410e Feature Command Notes

Pen width PW wid,pen; wid-32,767.999 to 32,767,

pen0: command ignored,

pennumber set then cur- rent

pen is used

Rectangle absolute filled RA x,y; xx coordinate, yy coordi- nate;

range of x and y is -67,108,863

to 67,108,863

User defined raster fill RF ind,wid,ht,pix...; ind1 to 8; wid8, 16, 32, or 64;

ht8, 16, 32, or 64; pix0 to

76,108,863

Rotate coordinate system RO ang; ang0, 90, 180, 270

Replot RP n; n1 to 32,767

Rectangle relative filled RR x,y; xx coordinate, yy coordi- nate;

range of x and y is -67,108,863

to 67,108,863

Otros manuales para OL400e Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora de OKIDATA

OKIDATA

OKIDATA ML380 Manual de usuario

OKIDATA

OKIDATA OL600e Instrucciones de construcción

OKIDATA

OKIDATA C 7000 Instrucciones de instalación y mantenimiento

OKIDATA

OKIDATA Pacemark 3410 Manual de usuario

OKIDATA

OKIDATA ML320 Turbo Manual de usuario

OKIDATA

OKIDATA ML390 Turbo Manual de usuario

OKIDATA

OKIDATA OKIPAGE 8c Manual de usuario

OKIDATA

OKIDATA OL1200ex Manual de usuario

OKIDATA

OKIDATA C 9000 Instrucciones de instalación y mantenimiento

OKIDATA

OKIDATA MICROLINE ML590 Manual de usuario

OKIDATA

OKIDATA DOC-IT Series Manual de usuario

OKIDATA

OKIDATA MICROLINE 320 Manual de usuario

OKIDATA

OKIDATA Pacemark 4410 Manual de usuario

OKIDATA

OKIDATA Microline ML395C Manual de usuario

OKIDATA

OKIDATA DOC-IT3000 Manual de usuario

OKIDATA

OKIDATA ML184Turbo Manual de usuario

OKIDATA

OKIDATA PT330 Instrucciones de instalación

OKIDATA

OKIDATA OKIPAGE 20 Manual de usuario

OKIDATA

OKIDATA OKIMATE 20 Manual de usuario

OKIDATA

OKIDATA MC873 Manual de usuario

OKIDATA

OKIDATA ML320 Turbo Manual de usuario

OKIDATA

OKIDATA 120 Manual de usuario

OKIDATA

OKIDATA Microline 93 Manual de usuario

OKIDATA

OKIDATA MICROLINE ML590 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario
