Service Guide ML320/ML321

Chapter 0 About This Manual

ML320/ML321

Dot Matrix Printers

Adobe Acrobat printable reference

copy of the OKIDATA Service Training Manual.

09/17/97

Note: This Adobe Acrobat version of the Okidata Service Training Manual was built with the

pictures rendered at 300 dpi, which is ideal for printing, but does not view on most

displays well.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Table of Contents Page

Service Guide ML320/ML321

0 About This Manual

Front Cover 1

Manual Copyright 2

Manual Part Number and Revision 3

1 Product Specifications

1.1 General Description 4

....1.1.02 Serial Number Identification & (A-D) Revision Levels 5

........Compatibility Chart 6

1.2 Product Specifications 7

1.3 Paper Specifications 8

1.4 Physical Specifications 9

1.5 Power Requirements 10

1.6 Environmental Requirements 11

1.7 Agency Approvals 12

1.8 Options 13

1.9 Consumables 14

1.10 Memory Specifications 15

1.11 Reliability Specifications 16

2 Principles of Operation

2.1 Printer Overview 17

2.2 Circuit Board Description 18

....2.2.01 Operator Panel Board 19

....2.2.02 Power Supply 20

....2.2.03 Control Board 21

........Large Scale Integrated Circuitry (LSI) 22

2.3 Electrical Operation 23

....2.3.01 Initialization 24

....2.3.02 Interface Control 25

....2.3.03 Print Head Drive Circuit 26

....2.3.04 Spacing Operation 27

....2.3.05 Line Feed 28

....2.3.06 Alarm Circuit 29

2.4 Mechanical Principle Of Operation & Block Diagrams 30

....2.4.01 Printhead 31

....2.4.02 Space Mechanism / Operation 32

........Head Gap Adjusting Mechanism 33

....2.4.03 Ribbon Drive Mechanism / Operation 34

....2.4.04 Paper Feed Mechanism 35

....2.4.05 Paper-End Detection Mechanism 36

....2.4.06 Semi-Automatic Sheet Feeder (SASF) Operation 37

3 Maintenance & Disassembly

Maintenance & Disassembly 38

Table of Contents Page

....3.1.01 General Information, Tools & Precautions 39

3.2 Disassembly/Assembly Procedures 40

....3.2.01 Preliminary Items 41

....3.2.02 Separator Assembly 42

....3.2.03 Printhead Assembly 43

....3.2.04 Upper Cover Assembly 44

....3.2.05 Operator Panel Assembly 45

....3.2.06 Control Board (Rev A & B) 46

........Control Board (Rev C) 47

........Control Board (Rev D) 48

....3.2.07 IC Card (A) Panel 49

....3.2.08 Transformer (Rev A & B) 50

........Transformer (Rev C) 51

........Transformer (Rev D) 52

....3.2.09 Filter Assembly 53

....3.2.10 Power Supply Board (Rev A & B) 54

........Power Supply Boards (Rev C) 55

3.2.11 Power Interconnect Module / Cable Guide (Rev A & B) 56

........Power Interconnect Module / Cable Guide (Rev C) 57

........Power Interconnect Module / Cable Guide (Rev D) 58

....3.2.12 Indicator Assembly (Bail Bar Assembly) 59

....3.2.13 Head Cable Access Cover 60

....3.2.14 Ribbon Drive Assembly 61

....3.2.15 Space Motor Assembly 62

....3.2.16 Carriage Frame Assembly 63

....3.2.17 Space Rack 64

....3.2.18 Guide Rail 65

....3.2.19 Platen Assembly 66

....3.2.20 Line Feed Motor and Gear 67

........Line Feed Motor Gear 68

....3.2.21 Line Feed Motor Interconnect Module 69

....3.2.22 Reset Spring, Change Gear, and Idler Gear 70

....3.2.23 Release Lever 71

....3.2.24 Paper Pressure Guide 72

....3.2.25 Pressure Roller Assembly 73

....3.2.26 Tractor Assembly 74

....3.2.27 Sensor Lever 75

....3.2.28 Paper End (B) Lever 76

....3.2.29 Main Chassis Assembly 77

3.3 Adjustments 78

....3.3.01 Printhead Gap Adjustment 79

3.4 Cleaning 80

3.5 Lubrication 81

4 Failure & Repair Analysis

Table of Contents Page

Failure & Repair Analysis Introduction 82

4.4 Troubleshooting Tips 83

....4.4.02 Common Problems 84

4.5 Fault Alarms 85

4.6 Repair Analysis Procedures - Using The Raps 86

4.6.02 RAP Index 87

....4.6.03 Troubleshooting Cautions 88

........RAP 01A:Operator Panel Lamps Do Not Light - Rev A, B,

and C 89

........RAP 01B: Operator Panel Lamps Do Not Light - Rev D 90

........RAP 02A: Abnormal Spacing - Rev A, B, and C 91

........RAP 02B:Abnormal Spacing - Rev D 92

........RAP 03:Wrong or Missing Characters / Dots on Output 93

........RAP 04:Line Feed Problems 94

........RAP 05:Malfunction of Operator Panel Switch(es) 95

........RAP 06:Parallel Interface Does Not Receive Data 96

........RAP 07:Serial Interface Does Not Receive Data 97

#4.7 Hexadecimal Dump - Procedure 98

4.8 Resistance / Service Checks - Index To Charts 99

....4.8.02 Interconnect Diagrams (Rev A & B) 100

........Interconnect Diagrams (Rev C) 101

........Interconnect Diagrams (Rev D) 102

....4.8.03 Printhead 103

....4.8.04 Space Motor 104

....4.8.05 Line Feed Motor 105

....4.8.06 Operator Panel Board (Rev A, B, & C) 106

........Operator Panel Board (Rev D) 107

....4.8.07 Control Board (Rev A - D) 108

4.9 Printer Tests 109

....4.9.02 Rolling ASCII Print Test 110

....4.9.03 Font Sample Test 111

....4.9.04 Serial Interface Loopback Test 112

4.10 Menu Operation 113

4.11 Top Of Form 114

4.12 Paper Park 115

4.13 Forms Tear Off 116

A Reference Charts

A.1 Board Diagrams 117

A.2 Index To Charts (A, B, C, D) 118

....A.2.01 Control Board (LXMC) - Rev A and B 119

........A.2.02 Control Board (LXMC-3) - Rev C 120

........A.2.03 Control Board (LXMR) - Rev D 121

....A.2.04 Power Supply (PAII-2) - Rev A and B 122

........A.2.05 Power Supply (SUII-2) - Rev C 123

Table of Contents Page

....A.2.06 Filter Assembly - Rev A, B, C, and D 124

....A.2.07 Operator Panel (LXSP) - Rev A, B, and C 125

........A.2.08 Operator Panel (LXON) - Rev D 126

....A.2.09 RS232-C Serial Interface (LXHI) - Rev A, B, C, and D 127

B Illustrated Parts Listing

Illustrated Parts Listing - General Information 128

....B.1.02 Definitions of Terms 129

B.2 Index to Illustrated Parts Breakdown Charts 130

....B.2.01 Covers - Rev A, B, and C 131

........B.2.02 Covers - Rev D 132

....B.2.03 Electrical Components - Rev A and B 133

........B.2.04 Electrical Components - Rev C 134

........B.2.05 Electrical Components - Rev D 135

....B.2.06 Printer Mechanism - Rev A and B (1 of 2) 136

....B.2.07 Printer Mechanism - Rev A and B (2 of 2) 137

....B.2.08 Printer Mechanism - Rev C (1 of 2) 138

....B.2.09 Printer Mechanism - Rev C (2 of 2) 139

....B.2.10 Printer Mechanism - Rev D (1 of 2) 140

....B.2.11 Printer Mechanism - Rev D (2 of 2) 141

....B.2.12 Operator Panel - Rev A, B, C, and D 142

....B.2.13 Carriage Assembly - Rev A, B, C, and D 143

....B.2.14 Tractor Assembly - Rev A, B, C, and D 144

....B.2.15 Options - Rev A, B, C, and D 145

....B.2.16 Consumables - Rev A, B, C, and D 146

....B.2.17 Packaging - Rev A, B, C, and D 147

....B.2.18 Documentation - Rev A, B, C, and D 148

Page: 2

Service Guide ML320/ML321

Chapter 0 About This Manual

Manual Copyright

This document may not be reproduced without written permission of the Okidata® Technical

Training Group. Every effort has been made to ensure the accuracy of the information

contained in this training course. Okidata is not responsible for errors beyond its control.

P/N 59231501 First Edition May, 1988 Microline 320/321 Training Manual

P/N 59231501 [Second Release May, 1990] Microline 320/321 Training Manual

P/N 59263401 First Edition February, 1994 Microline 320/321 Service Handbook

P/N 59263401 Second Revision July, 1994 Microline 320/321 Service Handbook

Written and produced by the Okidata Technical Training Group

Please address any comments on this publication to:

Technical Training Group

Okidata

532 Fellowship Road

Mount Laurel, NJ 08054-3499

Fax Number: (609) 235-2600, ext. 7034

Okilink Login Name: Technical Training

OKIDATA is a registered trademark of Oki Electric Industry Company, Ltd.;

marques deposee de Oki Electric Industry Company, Ltd.; marca registrada, Oki

Electric Industry Company, Ltd.

Microline is a registered trademark of Oki Electric Industry Company, Ltd.

Centronics is a registered trademark of Centronics Inc.

IBM is a registered trademark of International Business Machines, Inc.

Proprinter is a registered trademark of International Business Machines, Inc.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 3

Service Guide ML320/ML321

Chapter 0 About This Manual

Manual Part Number and Revision

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 4

Service Guide ML320/ML321

Chapter 1 Product Specifications

1.1 GENERAL DESCRIPTION

The Microline 320 and Microline 321 are nine pin, dot matrix printers. Two versions of the printers

are available. The first provides Microline emulation. The second version provides Epson and IBM

Proprinter emulations, which are selected through the Printer Menu.

The major difference between the Microline 320 and Microline 321 is the width of each printer. The

Microline 320 can handle 80 print columns (at 10 CPI). The Microline 321 can print up to 136 columns

(at 10 CPI).

The standard interface is a Centronics parallel and an optional RS232-C serial interface can be

installed. The optional serial interface can transfer data at speeds up to 19.2K baud.

Both printers feature an enhanced operator panel which provides access to the following

capabilities.

Menu Selection

Quiet Mode

Printer Tests

Paper Park

Print Characteristics

Standard Printer Controls

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 5

Service Guide ML320/ML321

Chapter 1 Product Specifications

1.1.02 Serial Number Identification & (A-D) Revision Levels

Rev A units are original production units. An interconnect module connects the power supply board

to the main control board.

Rev B units are retrofitted to include a modified interconnect module, which prevents corrosion.

Rev C units have a cable harness connection between the power supply board and the main control

board. The cable harness replaces the interconnect module.

Rev D units have no power supply board. The circuitry for the power supply board has been

incorporated on the main control board.

Please Note the following:

The Rev C main control board (LXMC) and power supply board (SUII) are downward compatible

with Rev A and B units.

The Rev A and Rev B main control board (LXMC) and power supply board (PAII) cannot be used

in Rev C units.

Rev D units do NOT use Rev A, Rev B, or Rev C main control boards, transformers, operator panels,

upper covers, and lower covers. Rev D units have a unique main control board (LXMR), no power supply

board, a 50 volt transformer, and a unique operator panel (LXON).

NOTE:

Please refer to the parts lists (Appendix B( )) for parts differentiation. Please be sure of the parts you

need before ordering to avoid confusion and incorrect parts orders.

Printer Serial Number Identification

There are four serial number revision levels for the Microline 320 and 321 printers. Hardware differences

exist between levels. To identify the revision level of a printer, record the serial number from the back

of the printer. Refer to the following to decode the serial number.

Example Printer Serial Number: 401D0154693

Date Code 401 (4 = year. 01 = month)

Revision D

Serial Number 0154693
