Oki LED Printer Manual de usuario

E-1

English

User

Manual

E-2

Every effort has been made to ensure that the

information in this document is complete, accurate,

and up-to-date. OKIDATA assumes no responsibility for

the results of errors beyond its control. OKIDATA also

cannot guarantee that changes in software and

equipment made by other manufacturers and referred

to in this guide will not affect the applicability of the

information in it. Mention of software products

manufactured by other companies does not necessarily

constitute endorsement by OKIDATA.

First edition, July, 1999.

Written and produced by the OKIDATA Training and

Publications Dept.

Please address any comments to:

Training and Publications Department

OKIDATA

2000 Bishops Gate Boulevard

Mount Laurel, New Jersey 08054-4620

http://www.okidata.com

OKIDATA is a registered trademark of Oki Electric

Industry Company, Ltd.; Marque désposés de Oki

Electric Industry Company, Ltd.; Marca Registrada, Oki

Electric Industry Company, Ltd.

OKIPAGE is a trademark of OKI America, Inc.

ENERGY STAR is a trademark of the United States

Environmental Protection Agency.

TrueType is a registered trademark of Apple Computer

Company.

Hewlett-Packard, HP, and LaserJet are registered

trademarks of Hewlett-Packard Company.

IBM is a registered trademark of International Business

Machines Corp.

Microsoft and MS-DOS are registered trademarks and

Windows is a registered trademark of Microsoft

Corporation in the U. S. and other countries.

Intellifont is a registered trademark of Compugraphic

Corporation.

Epson is a registered trademark of Seiko Epson Corp.

Overview

E-3

Contents

Features .................................................................... 5

Consumables...................................................................... 5

Options................................................................................. 5

Operating Your Printer .......................................... 7

Using the Front Operator Panel.................................... 7

OKIPAGE 10e Front Operator Panel Reference........ 8

OKIPAGE 10e Function Reference .............................12

Changing the Menu Settings .......................................14

Using the Printer Menu Setup.....................................14

Resetting the Menu ........................................................15

Using Power Save to Minimize Warm-up Time .....15

Printing the Menu ...........................................................16

Maintenance Menu ........................................................16

Using Special Print Media.............................................16

Printing a Special Document.......................................17

Enhancing Print Quality.................................................18

Printing Envelopes ..........................................................18

Selecting Envelopes........................................................19

Printing Transparencies and Adhesive Labels.........19

Guidelines for Transparencies and Labels ...............20

Using Recycled Print Media .........................................20

Printer Maintenance ............................................ 22

Replacing The Toner Cartridge ....................................22

Replacing the Image Drum Cartridge .......................23

Cleaning the LED Array..................................................24

Printing a Cleaning Page...............................................26

Problem Solving.................................................... 28

Clearing Paper Jams.......................................................28

Print Quality Problems ..................................................32

Software Problems .........................................................34

Hardware Problems .......................................................37

E-4

Service and Support ............................................ 38

OKIDATA ONLINE ............................................................38

Your Dealer .......................................................................39

The Okidata Customer Support Center....................39

Okidata Customer Service Representatives ............39

Purchasing Supplies .......................................................40

Warranty Service ..............................................................40

OKIDATA SERVICE CENTERS.........................................41

Index........................................................................ 43

Overview

E-5

Features

•Fast print speed: 10ppm with a 28 MHz RISC

microprocessor

•Excellent print quality: 600 dpi class output

•Large paper capacity: 250 sheet paper tray and

manual sheet/envelope feeder plus options for

increasing paper capacity up to 850 sheets

•Memory: 4MB installed, expandable to 37MB

•Fonts: 35 PCLfonts (Agfa), 10 True Type fonts, USPS

Barcode font, OCR-A/B supported

•Emulations: Standard HPLaserJet 5 (PCL5e), IBM

Proprinter III/EpsonFX (9-pin emulation)

•Printer drivers: Windows95, Windows 98, Windows

3.1, Windows NT 4.0

•Interface: IEEE 1284 bi-directional parallel interface

•On-screen status monitor and interactive software

operator panel

•Energy Savings: Power is reduced when not printing

•1 year overnight exchange warranty, 5 year warranty

on the LED printhead (overnight exchange available

in the US and Canada)

Consumables

Toner: 2,000 pages @ 5% print density (Type 5 Toner

Cartridge Kit, Part# 52109001)

Drum: 20,000 pages with continuous printing (Type 5

Image Drum Cartridge Kit, Part# 40433305)

Options

•500 sheet 2nd Paper Tray/Mechanism

(Part# 70028701)

•100 sheet/50 envelope Multi-purpose Feeder

(Part# 70025101)

•1 MB Memory Expansion Board with 2 expansion

(SIMM) sockets (Part# 70033101)

•RS-232C Serial Interface Board with 2 expansion

(SIMM) sockets (Part# 00025302)

E-6

To install the following options, a Memory Expansion

Board or RS-232C Serial Interface Board must be

installed.

•Flash Memory SIMM 4MB (Part# 70032601)

•Flash Memory SIMM 8MB (Part# 70033201)

•4MB Memory SIMM Chip (Part# 70028801)

•8MB Memory SIMM Chip (Part# 70033801)

•16MB Memory SIMM Chip (Part# 70033901)

•32MB Memory SIMM Chip (Part# 70034001)

Overview

E-7

Operating Your

Printer

This section provides the following information:

•Using the front operator panel

•Setting printer features using the printer menu

•Using the printer software

•Using manual feed

•Printing envelopes

•Printing transparencies and labels

•Using recycled print media

Using the Front Operator Panel

Power Light

Printer is turned on.

Off

Printer is turned off.

E-8

OKIPAGE 10e Front Operator Panel Reference

Ready

(Green) Manual

Feed

(Amber)

Error

(Red) Meaning User Options/Switch Function

on off off Ready •Quick press: takes printer off

line

off off off Off line •Quick press: ready

•2 second press: print demo

page and menu page

•5 second press: print

cleaning page

blink off off Processing/receiving data •Quick press: pause printing

(off line)

slow blink: one blink every 4 seconds

blink: one blink per second

fast blink: several blinks per second

E-9

Ready

(Green) Manual

Feed

(Amber)

Error

(Red) Meaning User Options/Switch Function

slow blink off off Printing paused •Quick press: resume printing

(on line)

•2 second press: print buffer

contents

•5 second press: clear buffer

and reset printer

off off blink •Paper out

•Paper jam

(feed, eject and size error)

•Cover open

•Printing errors

•Quick press: resume printing

•Open cover, remove paper

jam, close cover

slow blink: one blink every 4 seconds

blink: one blink per second

fast blink: several blinks per second

E-10

Ready

(Green) Manual

Feed

(Amber)

Error

(Red) Meaning User Options/Switch Function

blink or

fast blink blink or

fast blink Hardware error Turn off and then re-power

printer.

If still not recovered, call

service.

−−slow blink •Warning

•Change image drum

•Toner low

•Toner sensor

Refer to on-screen status

monitor

slow blink: one blink every 4 seconds

blink: one blink per second

fast blink: several blinks per second
