OfficeServ WIP-5000M Manual de usuario
Quick Installation Guide
© SAMSUNG Electronics Co., Ltd. I
TABLE OF CONTENTS
Installation & Quick Reference
PREPARATION 2
Main Features and Services ....................................................................................... 2
Basic Telephone Services....................................................................................................3
System Telephone Services ................................................................................................3
Additional ISDN Telephone Services (ISDN Only)...............................................................3
Network Interfaces...............................................................................................................4
Software Specifications........................................................................................................4
Hardware Specifications ......................................................................................................4
Product Content .......................................................................................................... 5
Front Panel................................................................................................................... 6
INSTALLATION 8
OfficeServ SOHO Connection (ISDN Type)............................................................... 8
OfficeServ SOHO Connection (PSTN Type)............................................................ 10
Easy Installation of OfficeServ SOHO ..................................................................... 11
Easy Install ........................................................................................................................12
Connecting OfficeServ SOHO with Desktop / Laptop Computers ....................... 16
Connecting Computer to OfficeServ SOHO Wirelessly .....................................................16
Connecting Computer to OfficeServ SOHO by LAN Cable................................................17
MAKING CALLS 19
How to Make a Call .................................................................................................... 19
Making Intercom Calls .............................................................................................. 20
Calling from OfficeServ SOHO to Mobile phone (PSTN Only)...........................................20
Calling from ‘Station Status Display Screen’ of OfficeServ SOHO .....................................21
II © SAMSUNG Electronics Co., Ltd.
Making External Calls ............................................................................................... 22
Calling from OfficeServ SOHO ......................................................................................... 22
ANSWERING CALLS 23
How to Answer the Call............................................................................................. 23
Answering from OfficeServ SOHO.................................................................................... 23
Answer a call addressed to another station (Call Pick Up) ............................................... 24
FEATURES 25
Function Used during Calls............................................................................................... 25
VoIP .................................................................................................................................. 27
SMS.................................................................................................................................. 28
AA (Auto Attendant) .......................................................................................................... 28
Convenient features.......................................................................................................... 29
Web Management ............................................................................................................ 30
MENU 31
Main Screen...................................................................................................................... 31
Main Menu .................................................................................................................. 32
TROUBLESHOOTING 34
OfficeServ SOHO Troubleshooting.......................................................................... 34
Specifications of the OfficeServ SOHO................................................................... 36
© SAMSUNG Electronics Co., Ltd. III
Installation & Quick Reference
PREPARATION 38
Overview of WIP-5000M ............................................................................................ 38
Main features and services ...................................................................................... 38
Basic Telephone Services..................................................................................................38
Additional ISDN Telephone Services (ISDN Only).............................................................39
Software Specifications......................................................................................................39
Phone Layout............................................................................................................. 40
Menu Structure .......................................................................................................... 42
INSTALLATION 45
To Turn the Power On ............................................................................................... 45
Easy Registration ...................................................................................................... 45
To Turn the Power Off ............................................................................................... 47
Icons..................................................................................................................................47
MAKING CALLS 48
Calling Method........................................................................................................... 48
Making Intercom Calls .............................................................................................. 48
Making External Calls ............................................................................................... 49
ANSWERING CALLS 50
Answering from WIP-5000M ..................................................................................... 50
Answer a call addressed to another station (Call Pick Up) ................................................50
TROUBLESHOOTING 51
WIP-5000M Troubleshooting .................................................................................... 51
Specifications WIP-5000M ........................................................................................ 53
IV © SAMSUNG Electronics Co., Ltd.
This page is intentionally left blank.
For Basic Telephone
Installation & Quick Reference
2
© SAMSUNG Electronics Co., Ltd.
PREPARATION
Main Features and Services
Wide LCD Screen
Convenient Direction Button
Easy Installation
Wireless Data Service
Power Failure transfer (PTSN Only)
Various functions of the phone are shown on the LCD(3.9” Gray Graphic-
320 x 240 pixels). Users can use functions easily by finding and selecting
a menu from the LCD screen.
Users can use the direction button to move between menus so as to
access the various functions and services.
The installation wizard enables users to easily set the data and telephone
network mode, as well as to register the Wireless WIP-5000M phones.
This product supports wireless LAN data services with communication
devices(PC, PDA) that include WLAN modules. Also, a Web interface is
available for the programming of functions and data and telephone services.
You can make or receive external calls through a/b port even during power
failures. Press the telephone number directly without trunk access
code.(Only PSTN 1 is supported. However, other functions will be disabled.)
© SAMSUNG Electronics Co., Ltd. 3
Basic Telephone Services
- SMS(Support ETSI type I: Country Dependant Feature)
- Alphanumeric Phonebook, Speed Dialling, Memory Buttons for one-touch dialling
- List of outgoing calls, List of incoming calls, List of missed calls
- Dialling the most recent number, Automatic redial, Number pre-selection
- Alarm, Memo, Phonebook, Calculator, World Time, D-Day, Unit Converter
- Services Menu for Service Provider, Options and My Phone Menu
- User Selectable Rings, Tones(melodies) and background
- Automatic answer, Hands free talk
- Call Transfer, Camp On, Do Not Disturb, Phone Block, Password
- Internal Calls, Call Pick Up
System Telephone Services
- Auto Attendant with selection of the call destination, Music for calls on hold
- Time variable management for call destination, Flexible Internal Numbering
- Call Filter(list of prohibited numbers), Emergency Numbers
- Toll Restriction
- Setup and configuration menu
Additional ISDN Telephone Services (ISDN Only)
- Multi-number management
- Caller Number Display ‘Who is ?’(CLIP/CLIR and COLP/COLR)
- Call Forwarding(unconditional, busy or no answer)
- Three party conference(call holding and intermediate conversation)
- Call Waiting for busy or no answer destination
- Camp On, Call Parking
- Call duration display
- Time and date synchronization
- Call charge display per single extension
4© SAMSUNG Electronics Co., Ltd.
Network Interfaces
- 2 PSTN with PRS(Polarity Reverse Signal) optionally for PSTN type(SIT-200EM)
- 1 BRI for ISDN Type(SIT-200EI)
- 1 Analog port for FAX terminal, answering machine or standard phone
- 1 WAN port for connecting with a ADSL modem or data switch
- 1 LAN 10/100 BASE T port for connecting with a PC or local PDA
- 1 integrated WLAN with Access Point IEEE 802.11 b/g(compatible IEEE 802.11 b)
Software Specifications
- OS: Embedded Linux
- VoIP: SIP
- Protocols: TCP/IP, ICMP, VPN Pass through, WMM, TAPI 2.1
- Internet Connection: PPPoE, DHCP, Static IP
- Security: Firewall, Editable Filter, NAT,
- Wireless Feature: WMM, WEP, WPA 1.0, WPA 2.0(802.11i), MAC Access Control
Hardware Specifications
- CPU: Intel IXP 420
- Memory: 16 MB Flash, 64 MB SDRAM
- IC Melody: Yamaha 40 polyphonic
- DSP: VP101(CID, G711, G729)
© SAMSUNG Electronics Co., Ltd. 5
Product Content
After purchasing this product, check that the items below are all included in the package.
If any item is missing or damaged, please contact your dealer.
The cable type and quantity may be different according to the country.
WIP-5000M
For further information on the WIP-5000M, provided with OfficeServ SOHO, refer to
the ‘WIP-5000M’Section.
WIP-5000M
Mobile phone
Charger
Battery
(1 Standard Type)
User Guide
OfficeServ SOHO WIP-5000M
LAN Cable
OfficeServ SOHO
Power Adapter
Quick Installation Guide and
Quick User Guide
ISDN Cable(SIT-200EI)
or
Line cables(2EA)(SIT-200EM)
Telephone Cable
