Odys S18 Manual de usuario

ODYS MP3 player S18

Table of contents

1Contents of package ....................................................2

2Introduction ..................................................................3

3Getting started ............................................................. 4

3.1 Controls.........................................................................4

3.2 Inserting the battery.......................................................5

3.3 LCD and symbols ..........................................................6

3.4 Battery status ................................................................6

3.5 Installing the driver ........................................................7

3.6 Transferring files MP3 player - PC.................................7

3.7 Disable the MP3 Player from the PC .............................9

4Operation ...................................................................10

4.1 Switching the MP3 player on and off ...........................10

4.2 Music Mode (Play Music) ............................................10

4.3 Mode Switch in the Main Menu.................................... 11

4.4 Voice playback mode (Play Voice) ..............................12

4.5 Voice recording mode (Record)...................................14

4.6 System settings (Setting).............................................15

4.7 Preview function (Preview / Intro) ................................18

4.8 Memory Info (About).................................................... 18

4.9 Deleting files (Folder) ..................................................18

5Troubleshooting .........................................................20

6Specifications.............................................................21

7Safety instructions......................................................22

Warranty conditions...................................................21

ODYS MP3 player S18

1 Contents of package

Please ensure that the following items are included in the box. If the

package is not complete, please contact your dealer:

ODYS MP3 player S18

USB cable

Headphones

AAA battery

Warranty card

User manual

ODYS MP3 player S18

2 Introduction

Thank you for choosing our product. Please read this manual carefully

before use to make best use of all functions of the product and to

guarantee that it has a long service life. Please store the manual in a

safe place for later reference.

This product is a portable digital audio player which allows you to play

your MP3 and WMA tracks (multi-codec player) and make voice

recordings or save files of any kind. The backlit LCD displays

information on the current digital music file via the ID3 tag.

Caution

Please read the general safety instructions in chapter 7

before using the MP3 player. Pay particular attention to the

instructions on safely concluding the digital transfer

between the MP3 player and computer in chap. 3.7.

Support

URL: http://www.odys.de

See our website for the latest information on this MP3 player, on other

products by our company and on our company itself. Any firmware

updates for this MP3 player are also made available on our website. If

you have questions or problems, please read the FAQs on our website

or contact our customer support service [email protected].

ODYS MP3 player S18

3 Getting started

3.1 Controls

Familiarise yourself with the controls of your MP3 player before use.

PLAY

USB-

connector

Loop fo

carrying

strap

PREV 

Headphone

connection

MODE NEXT 

VOL +

VOL −

Microphone

LCD

Cover of the battery

compartment

POWER/

USB

protective cap

Headphone

connection

ODYS MP3 player S18

3.2 Inserting the battery

Use one AAA (micro) battery.

•Open the cover of the battery compartment.

•Insert the battery into the battery compartment and ensure that the

polarity is correct.

•Close the battery compartment cover.

Key Functions

1. PLAY : play, pause, end the menu, On/off

2. MODE : Switch to menu, selection of options, A/B repeat

3. VOL + : Increase volume

4. VOL −: Reduce volume

5. NEXT : Fast forward, select next option

6. PREV : Rewind, select previous option

Description of key operation

The keys can be operated in four different ways: with a short, long, or

normal press, or they can be held down. In this handbook, a "short

press" is to be assumed unless stated otherwise.

Short press: This will take effect shortly after you press the key.

Long press: This will take effect when you press the key and hold it

for 1 to 2 seconds.

Normal press: This will only take effect when you release the key.

Press and Hold: This will take effect and repeat at certain intervals while

the key is held down, such as for fast forward or rewind.

ODYS MP3 player S18

3.3 LCD and symbols

Overview of the LCD

The LCD shows a variety of information on the current track, the

running time and the system settings. The symbols are explained

below.

3.4 Battery status

The service life of the battery is approximately 8 hours. The service life

of the battery may vary depending on the various operating conditions

of the MP3 player and installed firmware.

The charge state of the battery is indicated by various symbols to

enable you to estimate how long the player will operate:

full 66% 33% empty

Please replace the battery if an empty battery symbol is displayed.

Use rechargeable batteries with at least 800 mAh or alkaline batteries.

/B repeat

Bit rate

Playback time

Repeat

mode

File name /

ID3 tag

Battery

status

File

format

sound

Track number /

number of tracks

Volume

Playback

-B

ODYS MP3 player S18

3.5 Installing the driver

When using Windows 98SE, you must first install the

correspondding driver before connecting the MP3 player to

your computer. You can find this driver on our website at

http://www.odys.de. This is not required when using

Windows ME, 2000 and XP.

•Connect the MP3 player to your PC using the USB cable.

•The driver installation starts. When

using Windows ME, 2000, XP and

Vista , the PC recognizes a new

hardware device (mass storage

device) and automatically installs the

corresponding driver.

•If an error occurs during installation, remove the USB cable, restart

the operating system and reconnect the USB cable to the PC.

3.6 Transferring files MP3 player - PC

•Connect the MP3 player to your PC using the supplied USB cable.

•Open the Windows Explorer or double-click My Computer.

•Select folders or files to be transferred and drag them to the

removable data storage symbol of the MP3 player (download to

root directory). It is possible to create different folders for the

classification of your file types in the player memory beforehand and

then to save the relevant files to them.

•Once the transmission is complete, click the MP3 player symbol and

check whether the files were completely copied.

•Following the same procedure, you can also copy files from the MP3

player to the PC (upload).

ODYS MP3 player S18

Formatting the Flash Memory

Using the PC operating system:

Open Windows Explorer and right click on the player’s removable data

storage symbol. Then click on the Format option in the context menu.

You can also use your MP3 player to transport all types of

files.

Never disconnect the USB cable from your MP3 player

during a data transfer or formatting.

PLease note that the device's main directory can only control a

maximun of 150 entries (Folders and Files). If you wish to save

more titels then you will have to create sub-folders. In these sub-

folders you can save as many files as you deem necessary.

The device creates automatically a folder using the file

format "DIR". Voice recordings which were created by the

device using the file format WAV can be found in this folder.

Please do not use this folder to save MP3 or WMA files.

Please note that only WAV files using IMADPCM coding can

be used when in the voice playback mode. Please use the

Music Playback mode to playback MP2 and WMA files.

ODYS MP3 player S18

3.7 Disable the MP3 Player from the PC

•Disable the digital MP3 player from the operating system correctly

using the “Remove Hardware Safely” option .

•Click the task bar on the right-hand side below the symbol and

select the “Remove USB Mass Storage Device – Drive (X:)” in the

following dialog window.

•Then the message now appears that the hardware can be removed.

When using Windows 98SE, does not appear in the task

bar. Once the data has been completely transferred, simply

remove the USB cable.

ODYS MP3 player S18

4 Operation

4.1 Switching the MP3 player on and off

Switching the MP3 player on

•Hold the Play key down for approx. one second

until the Display illuminates and a greeting is

displayed. When the MP3 player is switched on

for the first time, the player is in music mode. The LCD shows the

current track and the number of tracks available. See chapter 4.6

Settings for information on the duration of the blue backlighting. If

the MP3 player is not switched on, check the polarity of the battery

and ensure that it is charged.

Switching the MP3 player off

Press and hold the Play key for approximately three seconds until the

player has shut down and the LCD display goes blank. This is true

irrespective of the current operating state of the player.

4.2 Music Mode (Play Music)

Playback, forwards/back, pause, stop

•Insert the headphones in the headphone connection and turn the

player on.

•Press the PLAY button to play the track showed. The track informa-

tion (ID3 tag) is scrolled on the Display.

•Press and hold the or keys during play to skip forwards or

back within the track.

•If you briefly press the or keys playback skips to the next or

previous track respectively.

•Press the PLAY button briefly to pause playback. To resume play,

press the PLAY key again (resume function).
