Ocean Digital WR-100F Manual de usuario

WR-100F

Internet Radio

Please read this user manual carefully before using the receiver.

User Manual

Contents

Location of Controls .........................................1

Switching the radio on ......................................3

Connecting to your WiFi Network ......................4

Internet Radio ...................................................6

Media Center ....................................................9

FM Radio .........................................................11

Information Center ..........................................12

Aux In .............................................................13

Bluetooth .......................................................13

Conﬁguration .................................................14

Trouble Shooting ............................................22

Technical Speciﬁcation ...................................26

What is included in the box .............................27

Location of Controls

18 3 24 5 67

Dial /S elect

10 11 12 13

AUX-IN

- 01 -

1. Standby button

2. Home button

3. Left/Back button

4. Right button

5. Volume / Dial / Select rotary knob

(Rotate to adjust the volume or browse the menu. Push

down the button to conﬁrm selection)

6. Favourite button

(Press and hold to enter "Add to Favourite", press and

release to recall the favourite list)

7. 1-3 Presets buttons

(Press and hold to store preset, press to recall the

preset stations1-3)

8. Speaker

9. Color screen 2.4"

10. DC IN Jack

11. 3.5 mm Aux-In jack

12. 3.5 mm earphone jack

13. Telescopic antenna

Location of Controls

- 02 -

Switching the radio on

Connect the mains adaptor to the radio unit, one end to

the DC IN on the radio and the other end to the AC mains

wall socket.

Caution: Use only the mains adaptor supplied with the

radio. Connecting a power supply with a

different rating will cause permanent

damage to the radio and may be hazardous.

The radio will power up and display Welcome:

Select the language for the radio menu:

It will ask to set the <Check Network when Power on>, it

is suggested to choose <Yes>. The radio will always

check the available WiFi network automatically.

- 03 -

Connecting to your WiFi Network

Followed by the steps above, it will come to the network

conﬁguration setting. Choose <Yes> to start searching

the available WiFi network. If your router has the WPS

function, you can select <Yes(WPS)> to proceed.

After the search is done, it will display a list of the

available wiﬁ network.

Choose your network from the list, enter the password if

the network is set with encryption code. If your network

does not require any password to access, the wiﬁ will be

connected automatically.

Note: The encryption code would have been set up by

the person who set up and conﬁgured your network.

Follow the steps below to enter the password of your wiﬁ

network:

- 04 -

- Rotate the [Dial/Select] knob to browse the character

- Press the [►] button to skip to the next entry

- When it is done, push the [Dial/Select] rotary knob to

conﬁrm.

The radio will start connecting to the network.

When the wiﬁ is connected successfully, it will pop to the

main menu and you are ready to access the worldwide

internet stations.

08:58

Internet Radio

Connecting to your WiFi Network

- 05 -

Choose <Internet Radio> from the menu, you can see

several listed options.

To start listening the radio stations worldwide, select

<Radio Station / Music>. You can ﬁnd your favourite

station by Genre or Location.

My Favorite

This is to show the list of your Favorite stations which

have been added to the list.

To preset a station:

When your favourite station is playing and you want to add

it to favourite list, press and hold the [Preset] button and

<Add to My Favorite> menu will display. The preset

number will be assigned automatically to the next

available number. Push the [Dial/Select] knob to conﬁrm.

The playing station will be added to the preset list.

The presets will be stored in ascending order. You can

store up to 250 presets.

Note: Preset 1 to 5 are reserved for your own choice of

the dedicated radio channels. The preset will be

intended to store from no. 6 onwards, you can scroll to

choose no. 1-5 at your preference.

Internet Radio

Push [Dial/Select] dial to conﬁrm

The symbol on the top row

means station is added to

favourite list

- 06 -

For FM, you can store up to 99 presets

You can edit your favorite list anytime with the options

below:

Delete - To delete the selected station

Shift up - To shift the selected station by one level up on

the ranking

Shift down - To shift the selected station by one level down

on the ranking

Rename - To rename the selected station

Play - press and play the selected station

Navigate to <My Favourite> on the menu or press the [ ]

button, choose the radio station that you want to make the

above changes. Then press the [►] button to enter the

edit menu.

To recall a preset station:

Press the [ ] button brieﬂy and choose your desire

station.

Local Radio

Select this option to access quickly the radio station

located in your country.

Sleep Radio

Use this option to choose the sleeping sound for better

sleep, there are various kinds of sound for your selection.

Internet Radio

- 07 -

History

The radio will memorize the last 10 listened stations.

Service

Search Stations

You can ﬁnd your desire radio station by inputting the

name of the radio or just a few characters to ﬁlter the list.

Add New Radio Station

If you want to add the station and you have the audio

stream URL, it is suggested to add it through the

MediaYou website as follow, or you can contact MediaYou

if the station cannot be located.

http://www.mediayou.net/

Please refer to the “Manage My mediaU” under

Conﬁguration section below for more details.

When a radio station is playing, press the [►] button and it

will display the station logo (if any). Continue to press the

[►] button to view the radio information.

APP

Scan the QR code to visit the mediaU website to sign up

an account.

Internet Radio

Station

- 08 -
