Océ CS550/CS6xx Pro

Calibration

Océ User Manual

Océ-Technologies B.V.

in any form or by any means without written permission from Océ.

Océ makes no representation or warranties with respect to the contents hereof and specifi-

cally disclaims any implied warranties of merchantability or fitness for any particular purpose.

Further, Océ reserves the right to revise this publication and to make changes from time

to time in the content hereof without obligation to notify any person of such revision or

changes.

Edition: 2009-03

Contents

Chapter 1

Introduction.........................................................................................................5

Basic system configuration.......................................................................6

Why calibration...........................................................................................7

Main steps in calibration...........................................................................8

Chapter 2

Check the print quality.......................................................................................9

2.0 Check the print quality.......................................................................10

Chapter 3

Controller calibration........................................................................................11

3.1 Calibrate the EFI controller................................................................12

3.1 Calibrate the Creo controller.............................................................17

3.1 Calibrate the Océ PRISMAsync controller........................................20

3.2 Check the print quality.......................................................................28

Chapter 4

Printer calibration.............................................................................................29

4.1 Perform the adjustment operation...................................................30

4.2 Adjust the white point (gamma offset).............................................33

4.3 Calibrate the EFI controller................................................................39

4.3 Calibrate the Creo controller.............................................................44

4.3 Calibrate the Océ PRISMAsync controller........................................47

4.4 Check the print quality.......................................................................55

Contents

Chapter 1

Introduction

Basic system configuration

The basic system configuration contains the following parts.

■Printer

■Controller

■Scanner.

The basic system configuration has one of the following controllers

■Fiery ® PRO80/S450 65C-KM Color Server (IC303/IC305), default including a

photo spectrometer

■Creo controller, IC304/IC304 Plus, default including a photo spectrometer

■Fiery ® X3e TY2 65C-KM (embedded controller (IC408) for which a photo spectrom-

eter is optional.

■Océ PRISMAsync controller (Océ CS655 and Océ CS665 only) for which a photo

spectrometer is optional.

You can only calibrate a controller if you have a photo spectrometer.

Note:

Do not use the ColorCal / Off-the-glass method as described in the controller documen-

tation.

Chapter 1 - Introduction6

Basic system configuration

Why calibration

The printer is calibrated for a screen at installation and at every next service visit. The

default screen is Dot 1. The Océ CS550/CS6xx Pro will hold on to the calibrated level

of print quality by automatically performed adjustments. In normal circumstances there

is no need to do additional calibrations.

External circumstances, for example temperature, humidity and consumables change over

time. These changes effect the colour reproduction. You can perform a calibration as de-

scribed in this document to eliminate the effect of the external circumstance on the colour

reproduction.

There is no need or use to calibrate the scanner.

Chapter 1 - Introduction 7

Why calibration

Main steps in calibration

Sub-stepMain step

‘2.0 Check the print quality’ on page 101. Check the print quality

Continue only if the colour reference chart does not meet your requirements.

‘3.1 Calibrate the EFI controller’ on page 12

‘3.1 Calibrate the Creo controller’ on page 17

‘3.1 Calibrate the Océ PRISMAsync controller’ on page

2. Calibrate the controller

‘3.2 Check the print quality’ on page 28

The result of the controller calibration as checked in 3.2 normally meets the required

print quality. If the print quality still does not meet your requirements, you can

consider to proceed with the printer calibration.

‘4.1 Perform the adjustment operation’ on page 30 1

3. Calibrate the printer

‘4.2 Adjust the white point (gamma offset)’ on page 33

‘4.3 Calibrate the EFI controller’ on page 39 2

‘4.3 Calibrate the Creo controller’ on page 44 2

‘4.3 Calibrate the Océ PRISMAsync controller’ on page

472

‘4.4 Check the print quality’ on page 55

Note:

1 Calibration of your copy process only requires step 4.1 and 4.2.

Note:

2 Calibration of the printer requires calibration of the controller because the controller

takes the printer settings into account at controller calibration.

Chapter 1 - Introduction8

Main steps in calibration

Chapter 2

Check the print quality

2.0 Check the print quality

Introduction

You can print the Océ Color Reference chart to check the print quality. You can download

the print files used in this document form the Océ website. Before you print this chart,

you need to warm up the machine.

Before you begin

Load the A4/Letter portrait reference media with the correct paper settings.

Load the A3/Tabloid reference media with the correct paper settings.

Note:

Reference media is the media that you use mostly (bulk). The Océ reference media is

Océ Top Color 90 g/m2.

Warm up the printer

1. Print the file 'Océ Startup Page.pdf'.

Result

The Océ CS550/CS6xx Pro is warmed up and ready to evaluate the print quality.

Print the Océ Color Reference chart

1. Print the file 'Océ Color Reference Chart.pdf'.

Result

The result is a printed Océ Color Reference chart to evaluate the print quality.

Chapter 2 - Check the print quality10

2.0 Check the print quality
