NXP Semiconductors S32K344 Manual de usuario

S32K344

White Board

Rev. 1.0 — 11 April 2023 User manual

COMPANY PUBLIC

Revision Number Date Changes

Draft 0.6 Dec 2nd , 2020 Initial Version

Draft 0.7 Jan 6th , 2021 Added J86, J87, J88, J89, J90 and SBC debug

description based on SCH-47478 rev B.

Draft 0.8 Feb 1st , 2021 Updated the new board picture of rev B PCB.

Added power on requirement.

Added a few new jumpers and a power switch.

Draft 0.9 Mar 18th , 2021 Updated some detailed descriptions of key features.

1.0 April 7th , 2023 Updated the new BD, deleted the FS26 power up note.

Table 1. Revision history

NXP Semiconductors S32K344

White Board

1 Introduction

This document introduces the key features of S32K344 White Board, which can be used

for various applications evaluation, including Domain Controller, BCM, Gateway, T-box

and so on. The block diagram for S32K344 White Board is shown in below Figure 1

"S32K344 White Board block diagram".

This document illustrates the power supply architecture of the White Board. It also lists

the jumpers configuration, connectors/interfaces, and some MCU PINs assignment on

the board.

Users can read this manual together with the White Board schematics to better

understand the hardware design.

Figure 1. S32K344 White Board block diagram

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 2 / 32

NXP Semiconductors S32K344

White Board

2 Features overview

The following figure shows the features of S32K344 White Board. Key features include

the following:

Figure 2. S32K344 White Board features overview

•S32K344 BGA257 secured sample.

•Safety SBC FS26 supplies MCU with 5V, 3.3V, 1.5V and monitors MCU status.

•Ethernet switch SJA1105 and Ethernet phy TJA1101/TJA1102/DP83848C provide 3

channels of automotive ethernet (100BASE-T1) and 1 channel of industrial ethernet

(100BASE-TX).

•CAN/CANFD transceivers TJA1044 and TJA1145 provide 4 channels CAN/CANFD.

•LIN controller SJA1124 and LIN transceiver TJA1124 provide 8 channels of LIN.

•QSPI Flash 128Mb.

•I2C FRAM (fast EEPROM) 256 Kb.

•LF driver and RF receiver for car access applications.

•4 channels high side driver and 8 channels low side driver outputs.

•2 channels USB-to-UART interfaces.

•4 channels general purpose analog and digital inputs.

•12 channels switch-detection inputs through CD1030.

•HB2001 for H-bridge driver.

•Audio Codec SGTL5000 connected to MCU via I2S.

•Accelerometer sensor MMA8452 with I2C interface.

•10 pin SWD debug interface and 20pin JTAG debug interface with TRACE capability.

•IO Headers for external GD3000 EVB to evaluate motor control use cases.

•7 User LEDs, 2 user buttons and 2 ADC potentiometers.

•Touch sense pads.

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 3 / 32

NXP Semiconductors S32K344

White Board

3 Connectors and interfaces

The following figure shows the connectors and interfaces of the White Board:

•Four 20-pin connectors J31, J32, J33 and J36 include most general-purpose inputs/

outputs and CAN/LIN interfaces.

•Three automotive ethernet interfaces (100BASE-T1);

•One RJ45 can be connected to PC;

•Two USB-to-UART interfaces are used for printing some debug information in MCU;

•ARDUINO shield connectors can be used for compatible EVB installation (such as

GD3000 EVB);

•Specific connectors for 4G module communication via UART interface;

Figure 3. S32K344 White Board connectors and interfaces

The signals definitions of J32 are listed in the following table:

PIN Label Function PIN Label Function

J32-10 PEPS_TXN5 PEPS antenna J32-20 PEPS_TXN9 PEPS antenna

J32-9 PEPS_TXP5 PEPS antenna J32-19 PEPS_TXP9 PEPS antenna

J32-8 PEPS_TXN3 PEPS antenna J32-18 PEPS_TXN7 PEPS antenna

J32-7 PEPS_TXP3 PEPS antenna J32-17 PEPS_TXP7 PEPS antenna

J32-6 VBAT2 12V power J32-16 NC NC

J32-5 VBAT2 12V power J32-15 NC NC

J32-4 PEPS_TXN1 PEPS antenna J32-14 GND GND

J32-3 PEPS_TXP1 PEPS antenna J32-13 GND GND

J32-2 D_IN_4 PEPS wake up J32-12 HB_OUT1 HB2001 out

Table 2. Signals definitions of J32

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 4 / 32

NXP Semiconductors S32K344

White Board

J32-1 D_IN_3 PEPS wake up J32-11 HB_OUT2 HB2001 out

Table 2. Signals definitions of J32...continued

The signals definitions of J33 are listed in the following table:

PIN Label Function PIN Label Function

J33-10 GND GND J33-20 VBAT1 12V power

J33-9 GND GND J33-19 VBAT1 12V power

J33-8 NC NC J33-18 LS_DRV_OUT_

Low side output

J33-7 NC NC J33-17 LS_DRV_OUT_

Low side output

J33-6 VBAT3 12V power J33-16 LS_DRV_OUT_

Low side output

J33-5 VBAT3 12V power J33-15 LS_DRV_OUT_

Low side output

J33-4 HS_DRV_OUT4 High side output J33-14 LS_DRV_OUT_

Low side output

J33-3 HS_DRV_OUT3 High side output J33-13 LS_DRV_OUT_

Low side output

J33-2 HS_DRV_OUT2 High side output J33-12 LS_DRV_OUT_

Low side output

J33-1 HS_DRV_OUT1 High side output J33-11 LS_DRV_OUT_

Low side output

Table 3. Signals definitions of J33

The signals definitions of J36 are listed in the following table:

PIN Label Function PIN Label Function

J36-10 GND GND J36-20 +5V_OUT2 +5V power

J36-9 ISELED_P ISELED

Interface J36-19 ISELED_N ISELED

Interface

J36-8 MSDI_SP5 Switch input J36-18 MSDI_SG5 Switch input

J36-7 MSDI_SP4 Switch input J36-17 MSDI_SG4 Switch input

J36-6 MSDI_SP3 Switch input J36-16 MSDI_SG3 Switch input

J36-5 MSDI_SP2 Switch input J36-15 MSDI_SG2 Switch input

J36-4 MSDI_SP1 Switch input J36-14 MSDI_SG1 Switch input

J36-3 MSDI_SP0 Switch input J36-13 MSDI_SG0 Switch input

J36-2 A_IN_2 ADC input J36-12 D_IN_2 Digital input

J36-1 A_IN_1 ADC input J36-11 D_IN_1 Digital input

Table 4. Signals definitions of J36

The signals definitions of J31 are listed in the following table:

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 5 / 32

NXP Semiconductors S32K344

White Board

PIN Label Function PIN Label Function

J31-10 LIN8 LIN interface J31-20 NC NC

J31-9 LIN7 LIN interface J31-19 NC NC

J31-8 LIN6 LIN interface J31-18 CANL_3 TJA1145 CANL

J31-7 LIN5 LIN interface J31-17 CANH_3 TJA1145 CANH

J31-6 LIN4 LIN interface J31-16 CANL_2 TJA1145 CANL

J31-5 LIN3 LIN interface J31-15 CANH_2 TJA1145 CANH

J31-4 LIN2 LIN interface J31-14 CANL_1 TJA1044 CANL

J31-3 LIN1 LIN interface J31-13 CANH_1 TJA1044 CANH

J31-2 GND GND J31-12 CANL_0 TJA1044 CANL

J31-1 KL15_WAKE SBC wake input J31-11 CANH_0 TJA1044 CANH

Table 5. Signals definitions of J31

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 6 / 32

NXP Semiconductors S32K344

White Board

4 MCU pins assignments and board resources mapping

The hardware configurations and MCU PINs assignments are listed in below table.

Interface Reference/

Signals

Configuration Description

Power Input VBAT1/2/3 12V 12V power supply input for this board

VCC1_5V0

(VDD_HV_A)

5.0V Some MCU pins are in VDD_HV_A

domain

VCC1_3V3

(VDD_HV_B)

3.3V Some MCU pins are in VDD_HV_B

domain

VREFH_MCU 5.0V ADC reference voltage

VCC_1V5 1.5V MCU Core is supplied by 1.5V from

SBC

V11_MCU 1.1V MCU generated 1.1V

MCU Power

Supply

V25_MCU 2.5V MCU generated 2.5V

BUCK_5V0 5.0V 5V to supply some circuits on the

board

BUCK_3V3 3.3V 3.3V to supply ethernet related circuits

Other Power

Supplies

LDO_1V2 1.2V 1.2V LDO to supply ethernet switch

core

MCU MAC Enabled MCU MAC is connected to ethernet

switch SJA1105 MII_0 in RMII mode

TJA1101 Enabled SJA1105 MII_1

DP83848C Enabled SJA1105 MII_2

Ethernet

TJA1102 Enabled SJA1105 MII_3 and MII_4

PCS0 NCK2910 (RF Receiver)

PCS2 CD1030(MSDI)

PCS3 XS6500(High Side Driver)

PCS4 MC33879 (Low Side Driver)

LPSPI_0

PCS5 HB2001(H-Bridge Driver)

LPSPI_1 PCS0 FS26 (Safety SBC)

LPSPI_2 (3.3V) PCS0 SJA1105 (Ethernet Switch)

PCS0 SJA1124 (LIN Ctrl and Phy)

PCS1 TJA1145 (CAN Phy)

LPSPI_3

PCS3 TJA1145 (CAN Phy)

PCS0 IO HeaderLPSPI_4

PCS1 NJJ29C2 (LF Driver)

SPI

LPSPI_5 PCS0 IO Header

QSPI QSPI_A Enabled QSPI Flash 128Mb

Table 6. White Board resources mapping

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 7 / 32

NXP Semiconductors S32K344

White Board

MMA8452 (Accel Sensor, address

0x1D)

SGTL5000 (Audio Codec, address

0x0A)

CS2100 (Clock Multiplier, address

0x4F)

I2C LPI2C0 (3.3V) Enabled

FRAM (Fast EEPROM, address 0x57)

CAN_0 TJA1044_1 PTA7_CAN0_TX, PTA6_CAN0_RX

CAN_1 TJA1044_2 PTA23_CAN1_TX, PTA22_CAN1_RX

CAN_2 TJA1145_1 PTD18_CAN2_TX, PTD19_CAN2_RX

CAN_3 TJA1145_2 PTE28_CAN3_TX, PTE29_CAN3_RX

CAN

CAN_4 IO Header PTG8_CAN4_TX, PTG9_CAN4_RX

LIN1 SJA1124_LIN1

LIN2 SJA1124_LIN2

LIN3 SJA1124_LIN3

LIN4 SJA1124_LIN4

LIN Controller and Phy controlled by

LPSPI3 with PCS0.

LIN5 TJA1124_LIN1 PTF2_LPUART6_TX,

PTF3_LPUART6_RX

LIN6 TJA1124_LIN2 PTF18_LPUART7_TX,

PTF19_LPUART7_RX

LIN7 TJA1124_LIN3 PTF23_LPUART9_TX,

PTF24_LPUART9_RX

LIN

LIN8 TJA1124_LIN4 PTF16_LPUART12_TX,

PTF17_LPUART12_RX

LPUART0 PTA27_LPUART0_TX,

PTA28_LPUART0_RX

LPUART2

CP2104 USB2

UART

PTE12_LPUART2_TX,

PTD17_LPUART2_RX

UART

LPUART1 Ext 4G Module PTB22_LPUART1_TX,

PTB23_LPUART1_RX

Audio SAI0 Enabled SGTL5000 Audio Codec

SW2 PTC20 (high active)Push Buttons

SW3 PTC21 (high active)

POT1 PTB13 (ADC0_S8)ADC POT

POT2 PTB14 (ADC0_S9)

LED D28 PTF8 (high active)

LED D29 PTF9 (high active)

LED D30 PTF10 (high active)

LED D31 PTF11 (high active)

User

Peripherals

User LEDs

LED D44 PTG0 (low active)

Table 6. White Board resources mapping...continued

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 8 / 32

NXP Semiconductors S32K344

White Board

LED D45 PTG1 (low active)

LED D46 PTG2 (low active)

SW4 PTC23, PTE10

SW5 PTC24, PTE15

Touch Sense Pad

Slider PTD23, PTA11, PTD24, PTA14

A_IN_1 (0~12V) PTE21_ADC2_P3Analog Inputs

A_IN_2 (0~12V) PTE22_ADC2_P4

D_IN_1 (0~12V) PTC26_ADC0_S21

General

Purpose Inputs

Digital Inputs

D_IN_2 (0~12V) PTE13_ADC1_S19

HS_D1 PTG18_EMIOS2_CH18

HS_D2 PTG19_EMIOS2_CH19

HS_D3 PTG20_EMIOS2_CH20

High Side Output

HS_D4 PTG21_EMIOS2_CH21

LS_DRV_OUT1 Controlled by LPSPI0 with PCS4

LS_DRV_OUT2 Controlled by LPSPI0 with PCS4

LS_DRV_OUT3 Controlled by LPSPI0 with PCS4

LS_DRV_OUT4 Controlled by LPSPI0 with PCS4

LS_DRV_OUT5 PTE20_EMIOS1_CH0

LS_DRV_OUT6 PTE27_EMIOS1_CH7

LS_DRV_OUT7 Controlled by LPSPI0 with PCS4

General

Purpose

Outputs

Low Side Output

LS_DRV_OUT8 Controlled by LPSPI0 with PCS4

JTAG_TMS PTA4

JTAG_TCLK PTC4

JTAG_TDO PTA10

JTAG_TDI PTC5

JTAG

RESET PTA5

TRACE_CLKOUT PTG6

TRACE_D0 PTG7

TRACE_D1 PTG15

TRACE_D2 PTG16

Debug Interface

TRACE

TRACE_D3 PTF31

Table 6. White Board resources mapping...continued

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 9 / 32

NXP Semiconductors S32K344

White Board

5 White Board startup

Make sure the jumper J5 is closed and J87 is open so the SBC FS26 can power up in

debug mode. Apply 12V to the power supply input. Turn on the switch SW10. Connect

debugger to the SWD interface and refer to the White Board quick start guide to start the

software development.

The following figure shows the LED indicators for various power supplies on the board.

Figure 4. S32K344 White Board features

The 12V can be applied either through the power jack J3, connector J88 or the connector

pins J33-9,10(GND)/J33-19,20(VBAT). The LEDs indicate the presence of power supply

as following:

•LED D10 – indicates that the 12V is connected to the board correctly;

•LED D11 – indicates that the 5V supply from SBC is ON;

•LED D12 – indicates that the 5V supply from the standalone DC/DC is ON;

•LED D13 – indicates that the 3.3V supply from SBC is ON;

•LED D14 – indicates that the 3.3V supply from standalone DC/DC is ON;

•LED D15 – indicates that the MCU RESET pin is low (MCU in reset status);

The above figure also shows the basic elements to start the White Board:

•12V power input

•10-pin Cortex Debug Connector (SWD/JTAG debug interface)

•20-pin Debug + ETM connector (Debug with trace capability)

•RESET push button and RESET LED indicator

•USB2UART interface

User manual Rev. 1.0 — 11 April 2023

COMPANY PUBLIC 10 / 32

Tabla de contenidos

Otros manuales de Hardware de computadora de NXP Semiconductors

NXP Semiconductors

NXP Semiconductors OM11058 Manual de usuario

NXP Semiconductors

NXP Semiconductors i.MX 6Dual Manual de usuario

NXP Semiconductors

NXP Semiconductors MX93AUD-HAT-UM Manual de usuario

NXP Semiconductors

NXP Semiconductors OM13506 Manual de usuario

NXP Semiconductors

NXP Semiconductors freescale MC9S12G128 MCU Manual de usuario

NXP Semiconductors

NXP Semiconductors Freescale TWR-S12G240 Manual de usuario

NXP Semiconductors

NXP Semiconductors RD710 Manual de usuario

NXP Semiconductors

NXP Semiconductors FRDM-MCXA153 Manual de usuario

NXP Semiconductors

NXP Semiconductors freescale MC92604 Manual de usuario

NXP Semiconductors

NXP Semiconductors SLN-VIZNLC-IOT Manual de usuario

NXP Semiconductors

NXP Semiconductors Qorivva MPC5643L Manual de usuario

NXP Semiconductors

NXP Semiconductors AXIOM M52259DEMOCOM Manual de instalación

NXP Semiconductors

NXP Semiconductors i.MX 8M Manual de instalación

NXP Semiconductors

NXP Semiconductors LPCXpresso54608 Manual de usuario

NXP Semiconductors

NXP Semiconductors MCUXpresso IDE MQX RTOS Guía

NXP Semiconductors

NXP Semiconductors JN5179 Manual de usuario

NXP Semiconductors

NXP Semiconductors i.MX 8M Plus Manual de usuario

NXP Semiconductors

NXP Semiconductors PCA9555 Manual operacional

NXP Semiconductors

NXP Semiconductors i.MX 6SoloX SABRE-SDB Manual de usuario

NXP Semiconductors

NXP Semiconductors UM10301 PCA2125 Manual de usuario

NXP Semiconductors

NXP Semiconductors RD9Z1-638BJBEVM Manual de usuario

NXP Semiconductors

NXP Semiconductors Android i.MX 8M Mini Manual de usuario

NXP Semiconductors

NXP Semiconductors i.MX 8M Mini LPDDR4 EVK Manual de usuario

NXP Semiconductors

NXP Semiconductors QorIQ LS1028A Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
