Nussbaum SPL 3200 Manual del operador

Operating instruction and documentation

serial-number:..........................................................

SPL 3200

Automotive lift date: 07/2000

Manual date: 07/2000

Nußbaum Hebetechnik GmbH & Co. KG || Korker Straße 24 || D-77694 Kehl-Bodersweier ||

Tel: +49 (0) 78 53/89 90 || Fax +49 (0) 78 53/87 87 ||

E-mail: info@nussbaum-lifts.de || http://www.nussbaum-lifts.de ||

retailer addresse / phone

Table of contents

Record of Installation............................................................................................. 3

Record of handing over...........................................................................................4

1. Introduction........................................................................................ 5

2. Master Document of the automotive lift.......................................... 6

Attestation of conformity....................................................................................... 7

3. Technical Information........................................................................ 8

Data Sheet over floor..............................................................................................9

Foundation plan ..................................................................................................... 10

Electrical diagram drawing (standard version).......................................................11

Electrical clamped connection drawing..................................................................12

Electrical diagram drawing (single phase Canada version)....................................13

Electrical diagram drawing (three phase Canada version).....................................14

Electrical diagram drawing (single phase USA version)........................................15

Hydraulic diagram drawing.................................................................................... 16

4. Safety regulations............................................................................... 17

5. Operating instructions....................................................................... 17

6. Troubleshooting...................................................................................19

Emergency lowering...............................................................................................20

Torn rope.................................................................................................................21

7. Maintenance........................................................................................ 22

8. Security check......................................................................................22

9. Installation and Initiation...................................................................23

Installation of the lift...............................................................................................23

Regulations for installation.....................................................................................23

Erection and doweling of the lift........................................................................... 23

Initiation..................................................................................................................26

Changing of the installation place.......................................................................... 26

Appendix

Document ”First security check before Installation”

Document ”Regular security check”

Document ”Extraordinary security check”

Spare parts list

Instruction and Documentation

SPL 3200

Record of installation

The automotive lift SPL 3200 with the

serial number.: ................................... was installed on .........................................................

at the firm........................................... at............................................................................

the safety was checked and the lift was startet.

The installation was effected from the operating authority / competent (please delete as applicable)

The safety of the automotive lift was checked from the competent before the initial operation

The operating authority attest the installation of the automotive lift, the competent attest the correct

initial operation.

.............................. ................................................ .............................................................

date name of the operating authority signature of the operating authority

.............................. ................................................ .............................................................

date name of the competent signature of the competent

Otto Nußbaum GmbH & Co.KG

Korker Straße 24

777694 Kehl-Bodersweier

Germany

Send this record, filled in and undersigned, to the

automotive manufacturer after the installation

Instruction and Documentation

SPL 3200

Record of handing over

The automotive lift SPL 3200 with the

serial number.: ................................... was installed on .........................................................

at the firm........................................... at............................................................................

the safety was checked and the lift was startet.

The persons below were introduced after the installation of the automotive lift. The introduction

was carried out from an erector of the lift-manufacturer or from a franchised dealer (competent).

.............................. ........................................................... .................................................

date name signature

.............................. ........................................................... .................................................

date name signature

.............................. ........................................................... .................................................

date name signature

.............................. ........................................................... .................................................

date name signature

.............................. ........................................................... .................................................

date name signature

.............................. ........................................................... .................................................

date name of the competent signature of the competent

Instruction and Documentation

SPL 3200

1. Introduction

The document ”Operating Instructions and Documentation” contains important

infomation about installation, running and preserving of the automotive lift.

To furnish proof of installation of the automotive lift the form ”Record of Installation”

must be sent undersigned to the manufacturer.

To furnish proof of the single, regular and special security checks this documentation

contains forms. The forms should be used to document the checks. They should also be

left in this documentation.

Every Changes in the construction and changing place of the automotive lift must be

registered in the ”Master document” of the lift.

Installation and check of the automotive lift

Only specialist staff is allowed to do the works concerning safety and to hold the safety

checks of the lift. They are called experts and competents in this document.

Experts are persons (for example self-employed engineers, TÜV-experts) which have

got an instruction and experience to check and to test automotive lifts in an

expert’s report. They know the signified regulations for protection of labour and

prevention of accidents.

Competents are persons which have got enough knowledge and experience with

automotive lifts. They took part in a training from the lift-manufacturer

(servicing erectors of the manufacturer and the franchised dealer are

Competents)

Information of danger

To show danger and to show important information the three symbols below with the

special meanings are used. Pay attention of those passages, which are marked with these

symbols

Danger!

This sign marks a danger to life. Inexpert handling of the marked series of

event ist dangerous to life

Caution!

This sign marks a caution against possible damage of the automotive lift or

other material defects in case of inexpert handling .

Indication!

This sign marks an indication for an important function or for another

important note.

Instruction and Documentation

SPL 3200

2. Master document of the automotive lift

Lift designation SPL 3200

Lift-manufacturer Otto Nußbaum GmbH & Co.KG

Korker Straße 24

77694 Kehl-Bodersweier

Germany

Application

The automotive lift SPL 3200 is a lifting stage for lifting vehicles with a laden weight of

3200 kg and a max. load sharing of 2:1 in and against drive-on direction. The lift is

equipped for working under the load. It is not allowed to enter the load or to carry persons

with it.

Instruction and Documentation

SPL 3200

Changes of construction, repairings and changes of place must be registered

in this master document

Changes of the construction, expert checking, resumption of work (date, kind of

change, signature of the expert)

................

...........

...........................................................................................................................................

name, address of the expert

............................................................ .................................................................

place, date signature of the expert

Change of automotive-lift-place, expert checking, resumption of work (date, address

and signature of the competent)

...........................................................................................................................................

name, address of the competent

............................................................ .................................................................

place, date signature of the competent

Instruction and Documentation

SPL 3200

3. Technical Information

Technical ratings

Lifting capacity: 3200 kg

Load sharing: max. 2:1 in or against drive-on

direction

Lifting time: ca. 32 sec

Lowering time: ca. 41 sec

lifting capacity: 1740 mm

Line voltage: 3 x 400V, 50 Hz (standard)

(observe the power supply of your state)

Driving voltage: 220 V

Power rating: 3.0 kW (standard)

Motor speed: 2800 revolution/minute

Output oil-pump: 3 ccm/revolution

Hydraulic pressure: 185 bar

Responsing pressure of pressure relief valve: 215 bar

Hold-up oil tank: ca. 8 Liter

Sound level (measured at operating panel) ≤75 dBA

Safety devices

1. Ratchets

safety device of the load against unintentional lowering when the

hydraulic system isn’t tight any more

2. Screens at hydraulic cylinder

safety device for slow lowering in case of pipe breaking

3. Lockable main switch

safety device against unauthorized using

Instruction and Documentation

SPL 3200

Data sheet

Instruction and Documentation

SPL 3200

command unit

Foundation plan

Instruction and Documentation

SPL 3200

Quality of the concrete B25
