TTB-455 OPERATION MANUAL

the knowledge is in our hands

LAST PAGE

RETURN TO MENU

TWINTEC 455

TTB 455 OPERATION - INFORMATION INDEX

1. Part Identification Diagram

2. Basic Operation Instructions

3. Dos and Donts

4. Fitting The Brush / Dri e Board

5. Filling The Clean Water Tank

6. Water Release Controls

7. Adjusting The Handle Height

8. Handle Controls

9. Emptying The Top Tank

10. Emptying The Bottom Tank

11. Cleaning The Separator Filter

12. Cleaning The Top Tank Filter

13. Cleaning The Bottom Tank Filter

14. Daily Maintenance Routine

15. Charging The Batteries

16. Changing The Squeegee Blades

17. Problem Sol ing

TWINTEC 455

TTB 455 OPERATION - PART IDENTIFICATION

HANDLE TOP (DIRTY

WATER) TANK

BOTTOM (CLEAN

WATER) TANK

SEPARATOR

SQUEEGEE TOOL

BRUSHES

CHASSIS

BRUSH

DECK

CHARGING

LEAD

TWINTEC 455

TTB 455 OPERATION - OPERATING INSTRUCTIONS

1. Ensure that charging lead has been disconnected

2. Ensure that the isolator pin is in place

3. Fit pad & drive board / scrubbing brush

4. Unclip deck so that the pad / brush is positioned flat to the floor

5. Lower the squeegee blade so that it is positioned flat to the floor

6. Fill bottom tank with clean water and detergent

7. Ensure that water on/off control is set at appropriate position

8. Ensure that top tank(s) are empt

9. Ensure that separator is fitted correctl

10. Adjust handle height to suit

11. Stand behind the machine

12. Press both of the black rubber buttons on the handle displa

13. Press and hold in the ellow button on the rear of the handle and at the same

time squeeze the triggers on the handle. Release the ellow button

14. Push the machine in the direction in which ou want to clean, holding in the black

triggers

15. When ou want the machine to stop, release triggers

TWINTEC 455

TTB 455 OPERATION - DOS AND DONTS

DO ensure onl competent persons unpack and assemble the machine

DO keep the machine clean

DO keep the brushes in good condition

DO replace an worn or damaged parts immediatel

DO ensure that the working area is clear of obstructions

DO ensure that the working are is well illuminated

DO follow all the instructions supplied

DO ensure that if using a pad, it is washed after each use

DONT use steam cleaners or pressure washers to clean the machine

DONT use the machine outdoors in the rain

DONT attempt machine maintenance or cleaning with the isolator pin intact

DONT allow an inexperienced repairs

DONT leave the brush or pad on the machine when not in use

DONT allow the machine to be used b inexperienced or unauthorised personnel

DONT lift or pull the machine b an of the operating triggers

DONT leave the machine running in one spot, turn off if not being used

DONT leave the brush or pad on the machine overnight, the will flatten

WARNING

It is essential that the equipment is correctl assembled and operated in accordance

with current safet regulations. When using the equipment alwa s ensure that all

necessar precautions are taken to guarantee the safet of the operator and an other

persons who ma be affected. Wear non-slip footwear when scrubbing. Alwa s use a

respirator mask in dust environments. The use of other accessories ma affect the

safet of the scrubber dr er. A full range of brushes and other accessories are available

from Numatic International.

TWINTEC 455

TTB 455 OPERATION - FITTING THE BRUSH / DRIVE BOARD

1. MACHINE SHOWN WITH

BRUSHES. 2. POSITION BRUSH ONTO

THE GEARBOX WITH THE 3

INDENTATIONS ALLIGNING

WITH THE 3 TABS. TURN

ANTI-CLOCKWISE TO LOCK

THE BRUSH IN PLACE.

3. THE BRUSHES WILL NOW

BE LOCKED IN PLACE AND

READY FOR USE.

NOTE: WHEN USING A DRIVE BOARD FOLLOW THE SAME INSTRUCTIONS

TO FIT DRIVE BOARD AND THEN FIX PAD CENTRALLY ONTO BOARD.

TTB 455 OPERATION - PROBLEM SOLVING

MACHINE NOT PICKING UP WATER

CHECK - SQUEEGEE BLADES ARE NOT WORN

CHECK - SQUEEGEE IS TOUCHING FLOOR

CHECK - HOSE IS CONNECTED TO SQUEEGEE

CHECK - HOSE IS CONNECTED TO SUCTION DOME

CHECK - SUCTION DOME IS SECURED TO TOP TANK

CHECK - HOSE FROM SUCTION DOME IS CONNECTED TO VAC MOTOR

NO WATER GOING ONTO FLOOR

CHECK - WATER CONTROL IS TURNED ON - SEE HANDLE CONTROLS PAGE

CHECK - WATER TAP IS TURNED ON - SEE WATER ON / OFF PAGE

CHECK - CLEAN WATER TANK IS NOT EMPTY

MACHINE ONL RUNS FOR SHORT PERIODS

CHECK - MACHINE HANDLE IS POSITIONED AT WAIST HEIGHT

CHECK - BATTERIES ARE FULLY CHARGED

TWINTEC 455

TTB 455 OPERATION - CHANGING THE SQUEEGEE BLADES

1. REMOVE THE SQUEEGEE

TURN UPSIDE DOWN, AND

REMOVE THE 4 SCREWS

ALONG THE CENTRE OF THE

TOOL.

2. LIFT AND REMOVE THE 2

PLASTIC INSERTS AND DIS-

CARD THE WORN BLADES.

3. PLACE THE NEW BLADES

INTO POSITION WITH THE

RIBBED SIDES FACING OUT-

WARD. ENSURE THAT THE

BLADES OVERHANG EQUALLY

AT EACH END.

4. ALLIGN PLASTIC INSERTS

AND APPLY PRESSURE UNTIL

YOU FEEL THE BLADE GRIP

INTO PLACE. REPLACE

SCREWS AND PUT SQUEEGEE

BACK ONTO MACHINE.

NOTE:

REPLACEMENT SQUEEGEE BLADE PART NUMBER: 217213

TWINTEC 455

TTB 455 OPERATION - CHARGING THE BATTERIES

1. LIFT THE FLAP ON THE

MACHINE HANDLE AND

INSERT CHARGING LEAD.

2. PLUG THE CHARGING

LEAD INTO A STANDARD

230 or 110 VOLT SOCKET.

NOTE:

WHEN THE MACHINE IS CHARGING YOU WILL BE ABLE TO HEAR THE

COOLING FAN. THIS WILL AUTOMATICALLY SWITCH OFF WHEN THE

MACHINE IS FULLY CHARGED.

BATTERY CHARGE TIME: 8 HOURS

TWINTEC 455

TTB 455 OPERATION - DAILY MAINTENANCE ROUTINE

1. RINSE THE BRUSHES WITH

CLEAN WATER ON A DAILY

BASIS.

2. RINSE THE SQUEEGEE ON

A DAILY BASIS AND REMOVE

ANY DEBRIS.

3. RINSE DIRTY WATER TANK

WITH CLEAN WATER AND

EMPTY AS NORMAL.

4. IF MACHINE IS NOT TO BE

USED FOR MORE THAN 2

DAYS, RINSE AND EMPTY

THE CLEAN WATER TANK.
