NOVA BIOMEDICAL Lactate Plus Manual
i
Instructions for Use Manual
PN62659B1 Lactate Plus IFU EN.indd 1PN62659B1 Lactate Plus IFU EN.indd 1 8/5/22 11:54 AM8/5/22 11:54 AM
PN62659B1 Lactate Plus IFU EN.indd 2PN62659B1 Lactate Plus IFU EN.indd 2 8/5/22 11:54 AM8/5/22 11:54 AM
i
Contents
Quick Reference Guide...........................................................1
Symbols.................................................................................5
Intended Use .........................................................................6
Limitations .............................................................................7
Safety ....................................................................................8
Introduction.......................................................................... 11
The Lactate Plus Meter ................................................... 11
Overview .........................................................................15
Meter, Supplies, Transport Case.....................................16
Environmental Specications ..........................................16
Disposal of Used Batteries and Meters
for Customers in Europe .................................................17
Interfering Substances ....................................................18
PN62659B1 Lactate Plus IFU EN.indd 1PN62659B1 Lactate Plus IFU EN.indd 1 8/5/22 11:54 AM8/5/22 11:54 AM
ii
Setup ...................................................................................20
Installing the Battery (Replacing) ....................................20
Set the Date and Time ....................................................22
Set Time Format..............................................................22
Set Date Format..............................................................25
Beeper On or Off.............................................................28
End of Setup ...................................................................29
Testing: Blood and Quality Control Solutions ......................30
Testing a Quality Control Solution ...................................32
Important Safety Instructions ..........................................35
Testing a Blood Sample ..................................................37
Data Review ........................................................................44
Data Review....................................................................44
Manually Reviewing Stored Test or Control Results .......44
Basic Upkeep ......................................................................46
PN62659B1 Lactate Plus IFU EN.indd 2PN62659B1 Lactate Plus IFU EN.indd 2 8/5/22 11:54 AM8/5/22 11:54 AM
iii
Cleaning and Disinfecting the Meter ...............................46
General Precautions for Cleaning and Disinfecting the
Meter ...............................................................................53
Error Messages ...................................................................56
Codes..............................................................................56
Appendix..............................................................................57
Specications ..................................................................57
Ordering Information .......................................................59
Performance Characteristics...........................................59
Accuracy .........................................................................60
Methodology....................................................................61
Precision .........................................................................62
Traceability ......................................................................64
Instructional Notes ..........................................................66
Warranty..........................................................................70
PN62659B1 Lactate Plus IFU EN.indd 3PN62659B1 Lactate Plus IFU EN.indd 3 8/5/22 11:54 AM8/5/22 11:54 AM
iv
PN62659B1 Lactate Plus IFU EN.indd 4PN62659B1 Lactate Plus IFU EN.indd 4 8/5/22 11:54 AM8/5/22 11:54 AM
1
1. Prepare the lancet.
a. Simply twist off the lancet cap:
Hold the lancet body and twist off the
lancet cap until you feel it separate
from the device.
b. Do not pull, just twist the lancet
cap. Dispose of the cap in a suitable
container.
NOTE: This lancet is for single-use
only. The needle retracts immediately
after sampling. This leaves the device
safe for immediate disposal into a
sharps container. To reduce the risk
of pre-analytical error, facilities should
consider using a 21-gauge lancet when
collecting capillary samples.
a
b
Quick Reference Guide
PN62659B1 Lactate Plus IFU EN.indd 1PN62659B1 Lactate Plus IFU EN.indd 1 8/5/22 11:54 AM8/5/22 11:54 AM
2
Insert Test Strip: Automatic
System Check begins.
User Prole Number displays:
use the left or right
arrow button to select prole.
2. Insert a Test Strip.
Quick ReferenceGuide
MODELeft Arrow Right Arrow
PN62659B1 Lactate Plus IFU EN.indd 2PN62659B1 Lactate Plus IFU EN.indd 2 8/5/22 11:54 AM8/5/22 11:54 AM
3
3. Prepare the Puncture Site.
c. The best puncture sites are on
the middle or ring nger. Clean the
nger tip thoroughly with soap and
water. Then dry thoroughly.
d. Place the single-use, disposable
safety lancet against the pad of the
nger, press the release button,
remove the device from the nger.
e. Wait a few seconds for a blood
drop to form. Wipe off the rst drop
with a clean tissue. Squeeze the
nger to form a second drop of
blood. Do not squeeze vigorously.
c
d
e
Quick ReferenceGuide
PN62659B1 Lactate Plus IFU EN.indd 3PN62659B1 Lactate Plus IFU EN.indd 3 8/5/22 11:54 AM8/5/22 11:54 AM
4
4. Add Blood to Test Strip.
When the second blood drop
appears, touch the end of the
test strip to the blood drop until
the well of test strip is full and
the meter beeps.
The on-screen Blood Drop
ashes on and off repeatedly
until sufcient blood has been
added to the test strip.
The Lactate result is available
on-screen in 13 seconds.
Quick ReferenceGuide
PN62659B1 Lactate Plus IFU EN.indd 4PN62659B1 Lactate Plus IFU EN.indd 4 8/5/22 11:54 AM8/5/22 11:54 AM
