Nostalgia Electrics HDF510 Guía rápida

All products are trademarks of Nostalgia Products LLC.

Worldwide design & utility patented or patents pending.

www.nostalgiaproducts.com

(rev. 07/29/16 DJ)

HDF510

Hot Dog Ferris Wheel Cart

Chariot pour chien-chaud style grande roue

Carro Para Perros Calientes De Vuelta Al Mundo

Instructions and Recipes

Instructions et Recettes

Instrucciones y Recetas

ENGLISH

Make everyday a party!

Visit www.nostalgiaproducts.com for more fun products.

CONTENTS

SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

HOW TO OPERATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

HELPFUL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

RETURNS & WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

SAFETY

Appliance Specications:

120 Volts, 60 Hertz

800 Watts

THIS PRODUCT IS FOR USE IN 120V AC OUTLET ONLY.

Refer to www.nostalgiaproducts.com/user-manuals/ for the most updated manual.

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and

on your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can

cause serious injury to you and others.

All safety messages will follow the safety alert symbol.

All safety messages will tell you what the potential hazard is, tell you how to reduce the

chance of injury, and tell you what can happen if the instructions are not followed.

ENGLISH

IMPORTANT PRECAUTIONS

1. NEVER immerse base in water.

2. NEVER use near water.

3. NEVER use an abrasive sponge or cloth on the Canopy or Base.

4. NEVER use a scouring pad on the appliance.

5. NEVER leave appliance unattended while in use.

6. NEVER place anything other than what is being cooked on the appliance.

7. Unplug unit from outlet when not in use and during cleaning.

8. DO NOT operate this appliance with a damaged cord or

plug, nor if the appliance ever malfunctions.

9. DO NOT place Base in a dishwasher.

10. Always keep Drip Tray in place while cooking hot dogs.

11. Keep out of reach of children.

12. This appliance is NOT A TOY.

13. Unsupervised young children and cognitively challenged

individuals should never operate this appliance.

14. Young children should be supervised while in proximity of the

appliance to ensure that they do not play with it.

IMPORTANT SAFEGUARDS

Basic safety precautions should always be followed when using

electrical appliances, including the following:

1. Read all instructions before operating this appliance.

2. Avoid contact with moving parts.

3. To protect against electrical shock do not immerse cord, plug or

any part of this appliance in water or other liquids.

4. Close supervision is necessary when any appliance is used near children.

5. Unplug from outlet when not in use, before removing parts and before cleaning.

6. DO NOT operate any appliance with a damaged cord or plug, nor if

the appliance has been damaged in any manner. Return the appliance

to the nearest repair shop for examination or repair.

7. The manufacturer does not recommend the use of accessory

attachments. Use of accessory attachments may cause injuries.

8. DO NOT use outdoors.

9. Position the appliance as close to the outlet as possible

to prevent injury due to tripping over cord.

10. DO NOT place on or near a hot gas or electric burner, nor in a heated oven.

11. Extreme caution must be used when moving this appliance.

ENGLISH

12. DO NOT use the appliance for other than its intended use.

13. An appliance that is plugged into an outlet should not be left unattended while in operation.

14. Check unit for presence of foreign objects prior to use.

15. A short power supply cord is provided to reduce the risk resulting

from becoming entangled or tripping over a long cord.

16. Longer detachable power supply cords can be used if care is exercised in their use.

17. The marked electrical rating of an extension cord should be at

least as great as the electrical rating of the appliance.

18. This appliance has a 3-prong plug. To reduce the risk of electrical shock, this plug is

intended to t into a polarized outlet only one way. If the plug does not t, contact

a qualied electrician. Do not attempt to modify the plug in any way.

SAVE THESE INSTRUCTIONS!

INTRODUCTION

Thank you for purchasing the HOT DOG FERRIS WHEEL CART! This 54”tall vendor-style

hot dog cart cooks up to 8 regular-size or foot-long hot dogs, and includes a built-in

hot dog and bun warmer. Great for birthdays, parties, family gatherings and more!

Features include:

• Cooks up to 8 regular-size or foot-long hot dogs at a time

• Dual heating elements with LOW/HIGH temperature settings

• Carousel rotates for even heating

• Built-in hot dog and bun warmer

• Full-size 54 inches tall

• Durable enameled steel construction

• Includes sliding drip tray

• Storage compartment for supplies

• Utility shelf for hot dog preparation

• Carousel and baskets remove for easy cleaning

• Top unit removes from cart for countertop use

ENGLISH

PARTS & ASSEMBLY

Please ensure that you have removed all of the hardware and parts listed before

discarding packaging. In our eorts to reduce packaging, we maximize the packing

material to protect your new purchase. As a result, small parts may not be readily visible.

Hardware

#1 Screw (8mm) #2 Screw (8mm) #3 Bolt (25mm) #4 Bolt (60mm)

Qty. 4 Qty. 6 Qty. 4 Qty. 4

#5 Flat Washer #6 Flat Washer #7 Nut Cap

Qty. 2 Qty. 4 Qty. 6

ENGLISH

Parts

(A) Main Unit (B) Drip Tray (C) Storage

Compartment

(D) Carousel

(E) Push Handle (F) Axle Bolts (G) Wheel (H) Wrenches

(I) Base Support (J) Bottom Plate (K) Cross Bar (L) Leg Assembly

(M) Carousel Cradle (N) Screwdriver (O) Tray handle (P) Screw

(A)Main Unit (B)Tray (C)Storage

Compartment

(D)Basket holder

(E )Push Handle (F)Axle Bolts (G)Wheel (H)Wrench

(I)Base Support (J)Cross Bar (K)Leg Assembly (L)Basket

(M)Bottom plate (N)Screwdriver (O)Tray handle (P)Screw

(A)Main Unit (B)Tray (C)Storage

Compartment

(D)Basket holder

(E )Push Handle (F)Axle Bolts (G)Wheel (H)Wrench

(I)Base Support (J)Cross Bar (K)Leg Assembly (L)Basket

(M)Bottom plate (N)Screwdriver (O)Tray handle (P)Screw

(A)Main Unit (B)Tray (C)Storage

Compartment

(D)Basket holder

(E )Push Handle (F)Axle Bolts (G)Wheel (H)Wrench

(I)Base Support (J)Cross Bar (K)Leg Assembly (L)Basket

(M)Bottom plate (N)Screwdriver (O)Tray handle (P)Screw

(A)Main Unit (B)Tray (C)Storage

Compartment

(D)Basket holder

(E )Push Handle (F)Axle Bolts (G)Wheel (H)Wrench

(I)Base Support (J)Cross Bar (K)Leg Assembly (L)Basket

(M)Bottom plate (N)Screwdriver (O)Tray handle (P)Screw

ENGLISH

1. Attach Push Handle (E) from inside Storage Compartment (C) using supplied #1 Screws.

2. Insert Cross Bar (K) into the square inserts on the inside of Base Support

(I) and secure from below with two #2 Screws. Insert the Leg Assembly

(L) over the protruding ends of the Base Support (I) and fasten from the

inside of Base Support (I) using four #4 Bolts, and four #7 Nut Caps.

3. Secure Bottom Plate (J) to Base Support (I) using four #2 Screws.

4. Assemble Base Support (I) into the bottom of the Storage

Compartment (C) and secure with four #3 Bolts.

Assembly of Base Support

ENGLISH

Assembly of Wheels

1. Slide one #5 Flat Washer onto Axle Bolt (F) and insert Axle Bolt (F) into Wheel (G).

2. Put on one #6 Flat Washer. Insert Axle Bolt (F) with Wheel (G) into Base Support (I).

3. Add a second #6 Flat Washer and #7 Nut Cap. Use Wrench (H) to tighten the #7 Nut Cap.

4. Repeat steps to attach second Wheel (G) onto the other side of the Base Support (I).

(#7)

Nut

Cap

(#5)

Flat

Washer

(F)

Axle

Bolt

(G)

Wheel

(I)

Base

Support

(#6)

Flat

Washers
