Nostalgia Electrics CCP-510 Guía rápida
All products are trademarks of Nostalgia Products Group, LLC.
Worldwide design & utility patented or patents pending.
© 2011 Nostalgia Products Group, LLC.
www.nostalgiaelectrics.com
(rev. 08/23/11)
CCP510
Vintage Collection™
Old Fashioned Movie Time Popcorn Cart
Instructions and Recipes
Instructions et Recettes
Instrucciones y Recetas
ENGLISH
2
CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . 3
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . 4
PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . 5
HOW TO OPERATE . . . . . . . . . . . . . . . . . . . . . . . 10
HELPFUL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . 11
CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . 11
RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RETURNS & WARRANTY . . . . . . . . . . . . . . . . . . . . 14
SAFETY
Appliance Specifications:
120 Volts, 60 Hz
667 Watts, ETL Approved
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and
on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards
that can kill or hurt you and others.
All safety messages will follow the safety alert symbol.
All safety messages will tell you what the potential hazard
is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
ENGLISH
3
IMPORTANT PRECAUTIONS
NEVER immerse in water.1.
NEVER use near water.2.
NEVER use an abrasive sponge nor cloth.3.
NEVER use a scouring pad on the appliance.4.
NEVER leave appliance unattended while in use.5.
NEVER force Kettle in or out of the brackets as this may cause gears6.
to become misaligned and appliance will not operate properly.
Unplug unit from outlet when not in use and during cleaning.
7.
DO NOT operate this appliance with a damaged cord or8.
plug, nor if the appliance ever malfunctions.
DO NOT clean any parts of this appliance in a dishwasher.9.
Keep out of reach of children.10.
This appliance is NOT A TOY.11.
Unsupervised young children and cognitively challenged12.
individuals should never operate this appliance.
Young children should be supervised while in proximity13.
of the appliance to ensure their safety.
IMPORTANT SAFEGUARDS
Basic safety precautions should always be followed when
using electrical appliances, including the following:
Read all instructions before operating this appliance.
1.
Keep door of Main Unit closed while operating. Do not2.
touch Kettle while operating; it gets very HOT.
To protect against electrical shock do not immerse cord, plug
3.
or any part of this appliance in water or other liquids.
Close supervision is necessary when any appliance is used near children.4.
Unplug from outlet when not in use, before removing parts and before cleaning.5.
DO NOT operate any appliance with a damaged cord or plug,6.
nor if the appliance has been damaged in any manner. Return the
appliance to the nearest repair shop for examination or repair.
The manufacturer does not recommend the use of accessory
7.
attachments. Use of accessory attachments may cause injuries.
DO NOT use outdoors.8.
Position the appliance as close to the outlet as possible9.
to prevent injury due to tripping over cord.
DO NOT leave Kettle motor running once popping has ceased.10.
Extreme caution must be used when moving this appliance.11.
ENGLISH
4
DO NOT use the appliance for other than its intended use.12.
An appliance that is plugged into an outlet should not be left unattended.13.
Check Kettle for presence of foreign objects prior to use.14.
Make sure the Kettle is properly attached to brackets before15.
operating and that the motor plug is plugged into the Kettle.
A short power supply cord is provided to reduce the risk resulting16.
from becoming entangled or tripping over a long cord.
Longer detachable power supply cords can be used if care is exercised in their use.
17.
The marked electrical rating of an extension cord should be at18.
least as great as the electrical rating of the appliance.
This appliance has a three-prong plug. To reduce the risk of electrical shock,19.
this plug is intended to fit into an outlet only one way. If plug does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any way.
CAUTION: The lightbulb inside of this unit will get hot. This bulb is
20.
only for use with the popcorn cart. If the bulb gets damaged, it must
be replaced by a qualified person in order to avoid a hazard.
Do not attempt to service this appliance yourself, as opening or21.
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
SAVE THESE INSTRUCTIONS!
INTRODUCTION
Thank you for purchasing the OLD FASHIONED MOVIE TIME POPCORN CART,
a product in Nostalgia Electrics’ Vintage Collection™. This 53” tall vendor-style
popcorn cart will be the hit of every party. It pops up to 16 cups of hot, fresh,
kettle cooked popcorn per batch. Providing a vintage look and feel, reminiscent
of silent movie houses and carnivals circa-early 1900s, the OLD FASHIONED
MOVIE TIME POPCORN CART is designed for both home and commercial
use. It features a large, stainless steel kettle with a built-in stirring system and
kernel catcher to keep unpopped kernels out of each perfect batch. There is a
compartment in the base of the unit to store supplies, making it easy to keep the
cart well stocked and organized. The OLD FASHIONED MOVIE TIME POPCORN
CART has an easy-to-clean design. Its accessible height makes serving a snap.
ENGLISH
5
PARTS & ASSEMBLY
Hardware
#1 Bolt (10mm) #2 Bolt (60mm) #3 Flat Washer #4 Flat Washer
Qty. 10 Qty. 4 (8mm) Qty. 14 (6mm) Qty. 14
#5 Locking Washer #6 Nut Cap #7 Nut
Qty. 6 Qty. 6 Qty. 4
ENGLISH
6
Parts
(A) Main Unit (B) 4 oz. Kernel (C) Storage (D) Oil Measuring
Measuring Cup Compartment Spoon (1 tbsp.)
(E) Push Handle (F) Axle Bolts (G) Wheel (H) Wrenches
(I) Base Support (J) Cross Bar (K) Leg Assembly (L) Popcorn Scoop
ENGLISH
7
Assembly of Base Support
Attach Push Handle (E) from inside Storage Compartment (C) using four #11.
Bolts, eight #4 Flat Washers and four #7 Nuts. For each hole, add one #4
Flat Washer to #1 Bolt, then put bolt through Storage Compartment (C) and
Push Handle (E). Add a second #4 Flat Washer and tighten with a #7 Nut.
Insert Cross Bar (J) into the square inserts on the inside of Base Support (I)2.
and secure from below with two #1 Bolts and two #4 Flat Washers. Insert
the Leg Assembly (K) over the protruding ends of the Base Support (I) and
fasten from the inside of Base Support (I) going outward using four #2 Bolts,
eight #3 Flat Washers, four #5 Locking Washers and four #6 Nut Caps.
Assemble Base Support (I) into the bottom of the Storage Compartment3.
(C) and secure with four #1 Bolts and four #4 Flat Washers.
ENGLISH
8
Assembly of Wheels
Put #3 Flat Washer onto Axle Bolt (F) and insert into Base Support (I).1.
Put on #3 Flat Washer. Slide Wheel (G) onto Axle Bolt (F), then add a second2.
#3 Flat Washer, #5 Locking Washer and #6 Nut Cap.
Use Wrench (H) to tighten the #6 Nut Cap.3.
On the other side of Base Support (I), insert second Axle Bolt (F)4.
with #3 Flat Washer, add #3 Flat Washer, second Wheel (G), another
#3 Flat Washer, #5 Locking Washer and a #6 Nut Cap.
Use Wrench (H) to tighten the #6 Nut Cap.5.
(#6)
Nut
Cap
(#3)
Flat
Washer
(F)
Axle
Bolt
(G)
Wheel
(I)
Base
Support
(#3)
Flat
Washer
(#5)
Locking
Washer
