Nortel BayStack 100-S Manual de instrucciones

Part No. 212139-A

April 2001

4401 Great America Parkway

Santa Clara, CA 95054

Release Notes for the

BayStack Instant Internet

Version 7.11.2

*212139-A*

212139-A

The information in this document is subject to change without notice. The statements, configurations, technical data, and

recommendations in this document are believed to be accurate and reliable, but are presented without express or implied

warranty. Users must take full responsibility for their applications of any products specified in this document. The

information in this document is proprietary to Nortel Networks NA Inc.

The software described in this document is furnished under a license agreement and may be used only in accordance

with the terms of that license. The software license agreement is included in this document.

Trademarks

NORTEL NETWORKS is a trademark of Nortel Networks.

BayStack, Instant Internet, and the Nortel Networks logo are trademarks of Nortel Networks.

Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation.

All other trademarks and registered trademarks are the property of their respective owners.

Restricted rights legend

Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subparagraph

(c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013.

Notwithstanding any other license agreement that may pertain to, or accompany the delivery of, this computer software,

the rights of the United States Government regarding its use, reproduction, and disclosure are as set forth in the

Commercial Computer Software-Restricted Rights clause at FAR 52.227-19.

Statement of conditions

In the interest of improving internal design, operational function, and/or reliability, Nortel Networks NA Inc. reserves

the right to make changes to the products described in this document without notice.

Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s) or

circuit layout(s) described herein.

In addition, the program and information contained herein are licensed only pursuant to a license agreement that contains

restrictions on use and disclosure (that may incorporate by reference certain limitations and notices imposed by third

parties).

CAUTION: To avoid bodily injury from hazardous electrical shock, never open the Instant Internet unit. There are no

user-serviceable components inside.

Release Notes for the BayStack Instant Internet Version 7.11.2

Introduction

This document contains release notes for the BayStack Instant Internet version

7.11.2 on:

•Using Windows ME and Instant Internet

•Installing Instant Internet in a Windows NT environment

•Using Windows 2000 and Instant Internet

•Using Microsoft Internet Explorer with Web cache

•Upgrading a V.35 or X.21 unit to an S series unit

•Setting the Aux port speed for out-of-band management

•Using the IICTL program

Using Windows ME and Instant Internet

Microsoft®has confirmed an issue with Windows ME and 16-bit Winsock

applications. If you are running Windows ME and experience failures for Instant

Internet utilities, you have two options:

•Download the appropriate Microsoft patch from:

http://support.microsoft.com/support/kb/articles/Q279/8/

66.ASP?LN=EN-US&SD=gn&FR=0&qry=Q279866&rnk=1&src=DHCS_

MSPSS_gn_SRCH&SPR=MSALL and follow the instructions to apply the

patch to Windows ME.

•Try removing Dial-Up Networking to see if that solves the problem:

aChoose Start > Settings > Control Panel.

bClick Add/Remove Programs.

cFrom the Windows Setup tab, double click to select Communications.

dIn the Communications dialog box, uncheck Dial-Up Networking.

eClick OK.

If you continue to experience problems with Windows ME and Instant Internet

after installing the Microsoft patch, contact one of the Nortel Networks Technical

Solutions Centers. For contact information, see the manuals that came with your

Instant Internet unit.

4Installing Instant Internet in a Windows NT environment

212139-A

Installing Instant Internet in a Windows NT environment

When you install Instant Internet on a computer running Windows NT®(3.51, 4.0

or Windows 2000), you must have administrator rights on that computer.

Using Windows 2000 and Instant Internet

If you use the Windows 2000 operating system, members of your network that do

not have administrative rights may find that iiLogin cannot connect to the Instant

Internet unit. In this case, the iiLogin icon remains red instead of turning green.

You can correct this problem by logging in with administrative rights and adding a

parameter to the iiLogin command line.

To edit the iiLogin command line to correct the problem between Instant Internet

and Windows 2000:

1Right click the Start button.

2Choose Open All Users.

The Start Menu window opens for all users.

3From the Start Menu window, open the Programs folder.

4From the Programs folder, open the Startup folder.

5In the Startup folder, right click Login and select Properties.

The Login Properties dialog box opens with the Shortcut tab displayed

(Figure 1).

Using Windows 2000 and Instant Internet 5

Release Notes for the BayStack Instant Internet Version 7.11.2

Figure 1 Login Properties dialog box

6In the Target field, do one of the following:

•If you have set Instant Internet to be the gateway for the computer, add

maxhops=0 (Figure 2).

C:\WINNT\System32\IILOGIN.EXE maxhops=0

6Using Windows 2000 and Instant Internet

212139-A

Figure 2 Login Properties dialog box when Instant Internet is the gateway

•If you have not set Instant Internet to be the gateway for the computer,

add the Instant Internet unit’s IP address (Figure 3)

C:\WINNT\System32\IILOGIN.EXE xxx.xxx.xxx.xxx

where xxx.xxx.xxx.xxx is the IP address of the Instant Internet unit, for

example: 192.168.1.1.

Figure 3 Login Properties dialog box when Instant Internet is not the gateway

7Click Apply.

8Click OK.

Using Microsoft Internet Explorer with Web cache 7

Release Notes for the BayStack Instant Internet Version 7.11.2

Using Microsoft Internet Explorer with Web cache

If you use Microsoft Internet Explorer version 5.5 or older with the Web cache

functionality of Instant Internet, you may not be able to use Internet Explorer to

update the cache. In this case, you have to wait until the cache content expires.

Microsoft Internet Explorer versions 5.5 SP1 and newer have corrected this

problem.

Additionally, if you use Microsoft Internet Explorer version 5.5 with the Web

cache functionality of Instant Internet and you save the Web sites configured on

the Instant Internet unit (Web Cache > Web Sites > Backup > Save) to disk,

Internet Explorer saves the Web page instead of saving the Web sites configured

on the unit.

To save the Web sites configured on the unit:

1On the unit’s Web page, click Web Cache.

2On the Web Cache page, click Web Sites.

3On the Web Sites page, click Backup.

4On the Backup Web Sites page, click Save.

The File Download dialog box opens.

5Select Open this file from its current location and click Ok.

6Do one of the following:

•If the Web cache backup list opens, choose File > Save as. Next, choose

Text File (*.txt) in the Save as file type field and click Save.

•If the File Download dialog box redisplays with the file name changed to

default, choose the Save to disk option and click OK.

The correct file is now saved to disk. However, if you saved the file as a

Text file, you will need to look for that file instead of the .wcb file for the

Restore.

Note: The name of the file to be saved should be default.wcb but it is

backup instead.

8Upgrading a V.35 or X.21 unit to an S series unit

212139-A

Upgrading a V.35 or X.21 unit to an S series unit

The V.35/X.21 card used on the Instant Internet 400-S unit has a universal

interface and the wiring selects the line drivers. Note that the connector on the

V.35 or X.21 card for the Instant Internet 400 models is the same as the connector

for the V.35/X.21 card for the Instant Internet 400-S model. However, the specific

cables used for each model are not compatible. Therefore, you cannot use the

same cable for your Instant Internet 400-S as you used for your Instant Internet

400 without some modification to the cable.

Setting the Aux port speed for out-of-band management

Using the configuration switches on the rear of the Instant Internet 100-S or

Instant Internet 400-S unit, you can change the Aux port connection speed from

115200 to 9600 baud in order to use a device or terminal emulation software that

does not support 115200 baud.

During the power-up sequence, your Instant Internet unit checks the settings of the

configuration switches to determine certain configurations. If switch number 4 is

on, the Aux port connection speed is set to 9600 baud. If switch number 4 is off,

the Aux port connection speed is set to 115200.

Table 1 shows the switch settings for configuring your Aux port speed to 9600

baud.

Table 2 shows the switch settings for configuring your Aux port speed to 115200

baud.

Table 1 Switch settings for setting the Aux port speed to 9600 baud

12345678

OFF • NANA NANANANA

ON NA NA • NA NA NA NA

Table 2 Switch settings for setting the Aux port speed to 115200 baud

12345678

OFF • NA NA • NA NA NA NA

ON NA NA NA NA NA NA

Using the IICTL program 9

Release Notes for the BayStack Instant Internet Version 7.11.2

Using the IICTL program

The IICTL program is a 32-bit console program available for Windows 95 or

newer operating systems. This program allows you to bring a group of interfaces

up or down or to enable or disable them from a batch file.

With IICTL, you can regulate the hours that users can access the Internet by

disabling all relevant interfaces for a specific period of time. IICTL provides a

means for automating this process using the Windows scheduler or a third-party

scheduler product.

“IICTL /?”shows the following help screen.

IICTL [/?]

Get this help screen

IICTL name | * [interface]

Show information on the interface for a box or all boxes

IICTL name interface operation [password]

Perform the operation on the specified box

name Name of the Instant Internet box

interface Name of the interface

operation

up - Bring up the interface

down - Take down the interface

enable - Administratively enable the interface

disable - Administratively disable the interface

Information for a box is in the following format

name MACaddress version

interface IPaddress inbytes outbytes state

lastcall

status
