Nolan NSRX3C2MTR Manual de usuario
BLUETOOTH WIRELESS
Microphone & Receiver Set
P/N NSRX3C2MTR
USER GUIDE
Declaration of Conformity: We declare that product
NSRXRM3C2MRS conforms to the R&TTE Directive 1999/5/RC.
.
R
E
C
E
I
V
E
R
M
I
C
R
O
P
H
O
N
E
FCC ID:TNZNSRX3C2XXX
0678
GETTING STARTED
Unpack the package carefully and confirm that you
have all of parts as shown below.
INTRODUCTION
The Microphone & Receiver Set allows capturing
the source of audio wirelessly and freely with
BTMIC wireless microphone. This wireless
Microphone & Receiver provides the unique low
latency to allow receiver to have well listening
or recording remote voice without delayed.
USB charging
cable X2
Receiver(RX) 3.5mm TRRS
stereo cable
3.5mm earphone
Microphone
BTMIC
Please check the contents carefully and contact
your local dealer immediately if anything is missing
or damaged.
PRODUCT OVERVIEW
See image below. Please note some models will
differ slightly in style, colour and the functionality
may vary according to their specifications.
(RX)
Mic
Clipper
On/Off
/Volume Button
3.5’ Audio
Jack
USB Charging
Connector
LED
(BTMIC)
Mic
Clipper On/Off
/VolumeButton
USB Charging
Connector
LED
CHARGING
Before using the BTMIC and RX, you must charge
it for approximately two hours. After fully charged,
the battery provides up to 5 hours of vocie talk time
and up to 100 hours of standby time .
Plug USB charging cable into BTMIC and RX mini
USB connector. Plug the other side of USB
charging cable into a powered USB connector.
When charging, the amber LED will be lighted.
When charging is completed, the amber LED will be
turn off or dim.
or
TURN ON AND PARING
You need to pair both BTMIC and RX when both
first time to use together.
1. On RX, press and hold the
ON/OFF button for 2 seconds
until blue and amber LED
fast flashing alternatively.
2. On BTMIC, press and
hold the ON/OFF button for
about 2 seconds until blue
LED blinking fast.
3. Both BTMIC and RX will pair and connect each
other automatically. The blue LED of both devices
will change to flash slowly (approx once every two
seconds) after completed paring and connecting.
BTMIC type A
pairing mode
The BTMIC supports two pairing modes. The type
A and type B pairing mode have different LED
indication. Please ensure you are using type A
pairing mode during pairing with RX.
※
When you press and hold the ON/OFF button
without released, the BTMIC will switch between
the type A and B mode circularly with different LED
indication. When the BTMIC is into desired type A
pairing mode with the blue LED quick flashing,
release the button. The BTMIC will keep this pairing
mode for using. If you like to change again, you can
repeat this operation for mode changing between
Type A and Type B.
Using
BTMIC
desired Type A
Power On
blue LED solid on
and then into type
A(or B) pairing mode
Switch Pairing Mode
blue and amber LED
solid on together and
then LEDS off
Switch Pairing Mode
blue and amber LED
solid on together and
then LEDS off
Power
Off
blue LED solid
on and then into type
B(or A) pairing mode
2. After the both devices connected, plug your
earphone 3.5mm audio plug into the RX’s 3.5 mm
audio jack, you can listen the voice on the RX from
earphone.
TURN OFF
1. For remote voice using BTMIC transmit captur-
ing and delivering the remote voice to earphone for
listener wirelessly.
Using for remote voice and commuicaiton
(RX)(BTMIC)
Press and hold the ON/OFF button for about 2
seconds, the amber LED on BTMIC and blue
LED on RX will stay on for about 1 second and
then device will be turn off，release the ON/OFF
button.
Put BTMIC microphone close to the sound source
within 8 inches tocaptured the best sound quality.
voice
“Listener”
RX
“Speaker”
BTMIC
max. 20cm
8 inches
Too far away
BTMIC
Using for listening or recording remote voice
Connect to audio output of RX to speakers or
iPad/iPhone to listen or record remote voice
wirelessly.
“Receiver”
audio or voice
RX
“Tansmitter”
camcorder
iPhone
Speaker
Tablet
PC
To increase the audio volume
While listening audio, click the ON/OFF button
once to increase the volume by one step. Repeat
this procedure until you reach the desired level.
To decrease the audio volume
While listening audio, quick click the ON/OFF
button two times continuously to decrease the
volume by one step. Repeat this procedure until
you reach the desired level.
Plug 3.5mm plug of earphone or audio cabel plug
into 3.5mm audio jack on RX. Then, the audio of
RX will output to earphone or speaker.
The 3.5mm audio jack on RX has offer audio
output receiving from remote microphone. You can
plug the 3.5mm audio plug to the most of recording
devices with audio microphone inputjack such as
camcorder, handycam, iPhone, iPad, iPod or
audio recording devices to receive the audio.
Adjusting the RX Audio Volume
Earphone or Speaker for Listening
3.5mm Audio plug for audio output from RX
