Nokia MEDIAMASTER 9780 S Manual de usuario

Owner’s Manual

MEDIAMASTER

9780 S

GB 3

MEDIAMASTER 9780 S

Nokia and Nokia Connecting People are registered trademarks of Nokia

Corporation. Other product and company names mentioned herein may be

trademarks or trade names of their owners.

Nokia Multimedia Terminals operates a policy of continuous development.

Therefore we reserve the right to make changes and improvements to any of

the products described in this manual without any prior notice.

The EMC Directive 89/336/EEC is applied to this product.

Contents

General operation of the Mediamaster 4

For your safety 4

Remote control 5

Front and rear panel 6

About the smartcard 7

General 7

How to insert the card 7

PIN Code 7

Connection of the Mediamaster 8

Preparing the Remote Control 8

Connecting the Mediamaster to the Dish 8

Connecting the Mediamaster 9

Connecting a TV and VCR 9

Connecting to the TV 9

If your TV has a SCART socket, but your

VCR does not 9

Nokia Smart switch 10

Connecting an Analogue Satellite

Receiver and VCR 10

Connecting a HiFi System 10

Connecting to the built in phonemodem 10

Switching on for the First Time with

SCART Connections 11

When RF connections are used 11

First time installation 12

General Information 12

The Welcome Menu 12

Language 12

Antenna/Satellite Selection 13

Antenna with one LNB for Sirius 13

About Signal Strength (AGC) and

Signal Quality (SNR) 14

LNB type 14

Other Antenna/Satellite Combinations 14

One Antenna/One LNB Configuration 14

Multisatellite/DiSEqC Switch Configuration

Connection of a DiSEqC switch 16

Channel Search 17

Viewing mode 18

General Information 18

Automatically downloaded information 18

Programme Information 18

The “i” (Information) Button 19

Guide 19

List of TV and Radio Channels 20

Options (Green Button) 20

TV Release (Zero button) 21

Video Recording 21

The TEXT Button (Teletext) 21

EXIT TV 21

Main Menu 22

General Information 22

TV and Radio Channels 22

Edit Channels 22

Update Channels 26

System Configuration 27

Channel Search 27

Antenna/Satellite Configuration 28

TV Settings 28

Modem configuration 29

Receiver Upgrade 29

Reinstall 30

User Preferences 30

Language Preferences 30

Parental Control 31

Appearance Preferences 31

System Information 32

Conditional Access 33

Viaccess Embedded 33

Smartcard settings 33

Glossary 34

Problem solving 35

Front panel display 36

Technical specifications 37

Menu screen structure 38

GB 4

GENERAL OPERATION OF THE MEDIAMASTER

Throughout this manual you will notice that the everyday opera-

tion of your Mediamaster is based on a series of user friendly on-

screen displays and menus.

All functions can be carried out using the buttons on the remote

control, and some of the functions can also be carried out using

the buttons on the front panel.

Please be aware that new software may change the functional-

ity of the Mediamaster.

Should you experience any difficulties with the operation of your

Mediamaster, please consult the relevant section of this manual,

including the Problem Solving, or call your service provider.

If you have got access to the Internet it is a good advice to visit

the Viasat homepage “www.viasat.se” now and then to get fur-

ther information concerning the functions of the Mediamaster.

• Allow clear space around the Media-master

for sufficient ventilation.

• Do not cover the Mediamaster or place it on

a unit that emits heat.

• Use a soft cloth and a mild solution of

washing-up liquid to clean the casing.

• Never allow liquids, spray or other materi-

als to come into contact with the inside of

the Mediamaster.

• Do not connect or modify cables when the

Mediamaster is plugged in.

FOR YOUR SAFETY

• Do not remove the cover.

• Do not allow the unit to be exposed to hot,

cold or humid conditions.

• Service should be carried out only at a Nokia

Authorised Service Centre.

• Please note that the only way to isolate the

Mediamaster completely from the mains

supply is to unplug the mains lead!

GB 5

To switch the Mediamaster in and out of standby mode.

EXIT TV To return to the viewing mode from a menu without stor-

ing settings (in menu mode).

To switch between TV or Radio (in viewing mode).

To turn the sound off/on (mute).

- + To adjust the volume of digital programmes.

The Mediamaster’s maximum level is controlled by the TV’s

present volume setting.

0 - 9 To change channel and to select individual menu options.

Note: If 0 is entered as the first digit, the TV Release func-

tionality is activated (see below).

0 TV Release. To switch between digital TV/Radio, analogue

TV and analogue satellite TV and VCR, when your systems

are connected by SCART leads.

Info. To display short and extended information (if transmit-

ted) about current and next programmes.

BACK To go back one level in the menus without storing settings.

TEXT To select teletext information.

Press to enter teletext (if available).

MENU To display or exit from the ”Main Menu” screen.

GUIDE Start the downloading of the Viasat Programme Guide

P+ P- To change channels up and down by one unit.

To leave an automatically downloaded application and return

to TV/radio mode.

To change page in a menu/list/text if more than one page is

available. To browse through teletext history.

To move up/down in the menus and to change channels.

To change settings in menus.

OK To confirm choices and selection of a highlighted item.

To display the TV/Radio channel list.

(Red) No function for the present.

OPTION (Green) Perform temporary settings (if transmitted)

OPTION + code: Open a locked channel.

FREEZE (Yellow) To select the freeze function.

Press once to freeze the screen picture.

Press any other key to go to normal mode again.

(Blue) To toggle between present and previous TV/Radio

channels.

This section describes how to operate the Mediamaster using the buttons on the remote control.

Some of the functions can also be carried out using the buttons on the front panel.

REMOTE CONTROL

GB 6

FRONT AND REAR PANEL

Rear Panel

to put the Mediamaster

in and out of standby

mode

to move up/down in

the menus and to

change channels.

Display

shows channel number, error messages, remote

control commands and time in standby mode

Front Panel

Slot

for a Smartcard

AUDIO L R

phono connectors

Stereo outputs for

connection to a HiFi

system

TV SCART

for connection

to the TV

AUX SCART

for connection to a

VCR, or an analogue

satellite receiver

* LNB cable also feeds the LNB with a supply voltage of

13/18 V (V/H polarisation) and a 0/22 kHz signal

(bandswitch). Max LNB current 400 mA.

DIGITAL AUDIO

phono connector

S/PDIF output for

connection to

a HiFi system

Mains lead

95-250 V AC

50-60 Hz

ANTENNA *

Satellite dish

input (F-connec-

tor)

SERIAL PORT

to read and load

data information

TV AERIAL

for a terrestrial

(conventional)

TV aerial

TV/VCR

for an RF-cable to

the aerial input of

the TV or VCR

TELEPHONE

Connection to the tel-

ephone

GB 7

How to insert the card

Insert your Smartcard fully into the slot behind the lid of the front

panel of the Mediamaster. The gold chip should face downwards

and inwards.

PIN Code

The Smartcard is loaded with a 4-digit code, also called a PIN code

(Personal Identification Number).

You will need this code when you want to communicate with

Viasat via the telephone modem.

ABOUT THE SMARTCARD

General

To be able to receive scrambled digital satellite channels you will

need a Smartcard from your Service Provider Viasat.

The Service Provider is the programme distributor.

Important. To be able to use the box, the card has to be

inserted in the slot. If the card is missing the box is

locked! Furthermore, new information from Viasat can

only be downloaded when the card is in the slot.

GB 8

The box for your Mediamaster should contain the

following items:

•the Mediamaster

•a remote control with 2 AAA batteries

•a SCART lead (fully featured 1,0 metre)

•a mains lead

•an aerial/RF lead (double screened 1,5 metres)

•a cable to the telephone

•an Owner’s Manual (this document)

•a Software License agreement

•a quick guide

CONNECTION OF THE MEDIAMASTER

About the SCART sockets

The rear panel of the Mediamaster is equipped with 2 SCART

sockets (see diagram). When you connect other products to

any of these sockets, always use fully featured SCART leads

(as supplied). There are “less well specified”SCART leads on the

market and picture quality could be reduced if you use them. SCART socket

SCART lead

Owner’s manual

License agreement

Quick guide

Phone

cable

RF lead

Preparing the Remote Control

•Remove the cover on the battery compartment at the bottom

of the remote control.

•Insert the 2 AAA (1,5 V) batteries, as shown in the diagram,

taking care to observe the +and -markings indicated inside.

•Replace the cover.

Installing the Satellite Dish

Connect the coaxial cable, with F-connectors fitted, from the LNB

on the satellite dish to the socket marked ”ANTENNA”on the rear

panel of the Mediamaster.

Connecting the Mediamaster to the Dish

If you need to fit the F-connectors onto the cable

•Prepare each end of the cable as shown in the diagram. You

will need to fold back the outer braid (as shown).

•Slide the F-connector onto the cable, then turn it clockwise

until it grips the braid.

•Ensure that 3 mm of the core is protruding from the end of the

connector.

8 mm

15 mm

3 mm

F-connector

Mains

lead

Remote

control

GB 9

Connecting to the TV

•Connect the SCART lead between the main SCART socket on

the TV and the TV SCART socket on the Mediamaster.

•Connect an RF lead from the TV/VCR output on the Media-

master to the RF input socket on the TV.

•Connect the TV aerial to the TV AERIAL input socket on the

Mediamaster.

Connecting the Mediamaster

There are many different types of TV/VCR and other equipment

that you can connect to the Mediamaster.

In this manual you will see some of the most common ways to

connect your equipment.

If you use RF leads you will have to tune your TV and VCR to the

Mediamaster output channel (see page 11).

If you have problems with your connections and need help, con-

tact your Service Provider.

SCART

Connecting a TV and VCR

Refer to your VCR’s manual for full instructions.

•Connect one SCART lead between the main SCART socket on

the TV and the TV SCART socket on the Mediamaster.

•Connect another SCART lead between the VCR

and the AUX SCART socket on the

Mediamaster.

•Connect the RF lead from the RF output on the

VCR to the TV aerial input on the TV.

•Connect the TV aerial to the RF input socket on the VCR.

VCR

Mediamaster

SCART

•Connect a SCART lead between the main SCART socket on

the TV and the TV SCART socket on the Mediamaster.

•Connect an RF lead from the RF output on the

VCR to the TV aerial input on the TV.

•Connect an RF lead from the TV/VCR output on

the Mediamaster to the RF input socket on

the VCR.

•Connect the TV aerial to the TV AERIAL input

socket on the Mediamaster.

VCR

Mediamaster

SCART

CONNECTION OF THE MEDIAMASTER

If your TV has a SCART socket, but your VCR does not

GB 10

Connecting an Analogue Satellite Receiver and VCR

Nokia Smart switch

Connecting a HiFi System

•Connect an RCA/Cinch stereo cable from the AUDIO L R sock-

ets on the Mediamaster to the LINE, AUX, SPARE or EXTRA

input sockets on your HiFi system.

•If available you can connect an RCA/Cinch single cable from

the DIGITAL AUDIO socket on the Mediamaster to your HiFi

or Dolby Pro Logic system.

Note: To avoid interference you must use a screened audio

cable.

VCR

•Connect a SCART lead between the main SCART socket on

the TV and the TV SCART socket on the Mediamaster.

•Connect a SCART lead between the VCR and the AUX SCART

socket on the Mediamaster.

•Connect an RF lead from the RF output on the VCR to the TV

aerial input on the TV.

•Connect an RF lead from the RF output on the

Analogue receiver to the RF input socket on the

VCR.

•Connect the TV aerial to the RF input socket on the

analogue receiver.

In order to switch the signal from the dish between the ana-

logue and digital receivers, you need a Nokia Smart switch (at

A B in the diagram) or a Universal Twin LNB.

Nokia Smart switch

•Connect a coaxial cable between output A on the switch (ac-

cessory) to the LNB socket on the analogue receiver.

•Connect a coaxial cable between output B on the switch to

the socket marked ANTENNA on the Media-master.

The analogue receiver must be switched to OFF (standby)

when you want to watch digital satellite channels from

the Mediamaster.

With Nokia Smart

switch

Analogue receiver

Mediamaster

SCART

Connecting to the built in phonemodem

The built in phone modem makes it possible for you to use inter-

active services.

•Connect the attached telephone cable between the socket

marked TELEPHONE on the rear of the Mediamaster and the

ordinary telephone socket in the wall.

CONNECTION OF THE MEDIAMASTER

Otros manuales para MEDIAMASTER 9780 S

Tabla de contenidos

Otros manuales de Receptor de Nokia

Nokia

Nokia FastMile 4G Manual de usuario

Nokia

Nokia FastMile 5G14-B Manual de usuario

Nokia

Nokia Mediamaster 260T Manual de usuario

Nokia

Nokia MD-310 Manual de usuario

Nokia

Nokia Mediamaster 210 Manual de usuario

Nokia

Nokia Mediamaster 9828 Manual de usuario

Nokia

Nokia 230 T Manual de usuario

Nokia

Nokia MEDIAMASTER 211S Manual de usuario

Nokia

Nokia RP 9199 Manual de usuario

Nokia

Nokia Mediamaster 9820 T Manual de usuario

Nokia

Nokia MEDIAMASTER 9460 S Manual de usuario

Nokia

Nokia Mediamaster 9802 S Manual de usuario

Nokia

Nokia 6000 Manual de usuario

Nokia

Nokia Mediamaster 9602 S Manual de usuario

Nokia

Nokia MEDIAMASTER 9800 S Manual de usuario

Nokia

Nokia MEDIAMASTER 9701 S GOLD BOX Manual de usuario

Nokia

Nokia MEDIAMASTER 9902 S Manual de usuario

Nokia

Nokia MEDIAMASTER 9400S Manual de usuario

Nokia

Nokia MEDIAMASTER 9780 S Manual de usuario

Nokia

Nokia MEDIAMASTER 9761 C Manual de usuario

Nokia

Nokia MEDIAMASTER 9450 S Manual de usuario

Nokia

Nokia MD-310 Manual de usuario

Nokia

Nokia FastMile 4G Instrucciones de funcionamiento y seguridad

Nokia

Nokia FastMile Manual de usuario

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario
