Nokia X1-01 Manual de usuario

Nokia X1–01 User Guide

Cyan

Magenta

Yellow

Black

Issue 2.0EN

Keys and parts

Select

Exit

1Earpiece

2Screen

3End/Powerkey

4Keypad

5Microphone

6Scrollkey

7Callkey

8 Selection keys

Cyan

Magenta

Yellow

Black

9 Headset connector

10 Loudspeaker

11 Music keys

12 Memory card slot

13 Flashlight

14 Charger connector

The headset and memory card may be

available separately.

Cyan

Magenta

Yellow

Black

Insert the SIM card and battery

Put your finger in the gap, and lift the

back cover.

Open the SIM 1 card holder

Insert SIM1.

Close the SIM card holder.

Open the SIM 2 card holder

Insert SIM2.

Cyan

Magenta

Yellow

Black

Close the SIM card holder.

Line up the battery contacts and push

the battery in.

Press the back cover into place.

Insert a memory card

Open the cover of the memory card

slot. See vi) in General Information.

Make sure the contact area is facing up,

and push the card in.

Close the cover.

Cyan

Magenta

Yellow

Black

Charge the battery

Connect the charger to a wall outlet.

Connect the charger to the phone.

The phone indicates a full charge. You

can use the phone while charging.

Switch on

2 seconds

Press and hold the power key .

Select Back

SIM1

Dual SIM

SIM2

Set which SIM card to use. Press OK.

See v) in General Information.

OK Back

Time:

09:0009

To set the hour, press up or down. You

can also press the number keys.

Cyan

Magenta

Yellow

Black

OK Back

Time:

15:00

To set the minutes, press right, and

then press up or down. Press OK.

Time is set

The time is changed.

OK Exit

Date:

08.04.2011

To set the date, press up or down.

Press OK.

15:00

Menu Go to

The phone is ready to use.

Cyan

Magenta

Yellow

Black

Explore your phone

Menu Go to

To see the available functions, press

Menu.

Select Exit

To go to a function, press the scroll key

up, down, left, or right.

Select Exit

To select the function, press Select.

Select Back

To select an item, press Select.

Select Back

To return to the previous view, press

Back.

ExitSelect

To return to the home screen, press

Cyan

Magenta

Yellow

Black

Select a SIM card for calls and messages

SIM1

SIM2

SIM1

SIM2

You can use two SIM cards, and share

your phone with your family.

Menu Go to Select Exit

Press Menu. Select Settings.

Select Back

Tone settings

Dual SIM

settings

Display

settings

Select Dual SIM settings. See v) in

General Information.

Select Back

Default SIM for

calls

Default SIM for

msgs

Ask every time

Select Default SIM for calls.

Select Back

Ask every time

SIM1

SIM2

Select Ask every time.

Default SIM for

calls:

Yes

Ask every time

Press the call key to

call directly!

Your phone asks which SIM card to use

when you make a call.

Cyan

Magenta

Yellow

Black

Select Back

Default SIM for

calls

Default SIM for

msgs

Ask every time

Select Default SIM for msgs.

Select Back

Ask every time

SIM1

SIM2

Select Ask every time.

Default SIM for

msgs.:

Ask every time

Press the call key to

send the message

directly!

Your phone asks which SIM card to use

when you send a message.

Menu Go to

Tip: To open Dual SIM settings from

the home screen, press and hold *.

Cyan

Magenta

Yellow

Black
