Handbook version no. 20190903
==========================================================================
接总电源说明
本款机型电机功率为3.75KW
请使用(3+1; 三根相线，一根地线)2.5平方线电源线
当相序接错时，旋转总电源开关接通电源，电控箱内的相序控制器工作指示
灯不亮，按下启动按钮设备不能启动，这时需更换相序（更换任意两根相线
就可以调换相序）。
当相序接正确时，旋转总电源开关接通电源，电控箱内的相序控制器工作指
示灯会亮红灯，按下启动按钮设备就可以启动。
Main Power Connection
The motor power is 3.75kw
-Please use (3 + 1, three phase lines, one ground line)2.5 square power
line
-If the phase sequence is misconnected, when you turn the main power
switch to connect the power, the working indicator light of the phase
sequence controller in the electric cabinet won’t be on, and the device
cannot start when press the start button. At this time, the phase sequence
should be switched (switching any two phase lines will do).
-When the phase sequence is correctly connected, rotate the main power
switch to connect the power, and the working indicator light of the phase
sequence controller in the electric cabinet will turn red. Press the start
button to start the device.
