Nobles Concord HP Plus Manual de usuario

Nobles | 701 N. Lilac Drive | P.O. Box 1452 | Minneapolis MN 55440-1452 | 800.553.8033 | www.nobles.com | [email protected]

Specifications subject to change without notice. REV 8.14.06

Vacuum System

Airflow at orifice 76 ft3 pm

Combined airflow 152 ft3 pm

Vacuum motor amps 17 A each

Vacuum motor horsepower 0.9 hp each

Vacuum motor quantity 2

Vacuum motor stages 3 each

Vacuum motor type Bypass, tangential discharge, 5.7 in / 145 mm diameter

Vacuum motor voltage 36 V

Vacuum motor watts 612 watts

Waterlift at sealed orifice 135 in / 3430 mm

Solution Delivery System

Coverage rate per tank of solution 2700 ft2per tank

Nominal solution flow rate 1.2 gpm

Solution capacity 32 gpm (122 L / min) gallon marker

Spray jets/spraybar 6 twist out jets, quick-release spray bar, electrical solenoid for positive spray shut-off

Brush/Pad System

Brush design description 18 bristle rows x 38 holes per row, spiral design with 5 degree lead spiral

Brush diameter 8 in / 260 mm

Brush length 24 in / 610 mm

Brush motor amps 13 A

Brush motor horsepower 0.5 hp

Brush motor type Permanent magnet; protected by a 10 A circuit breaker

Brush motor voltage 36 V

Brush RPM 1200 rpm

Power System

Battery amp hour rating 215 amp hour

Battery description (3) Three 215 amp hour, 12-volt deep cycle lead acid batteries with rope handles

Battery run time per charge 3.5 hours continuous run time

Power consumption amps 50 A (maximum)

Power consumption voltage 36 V

Transport Drive System

Drive chain description #40 nickel-plated x 69 pitches

Drive motor description 0.5 Hp. /rpm variable, 1800 maximum

Dimensions / Weight / Sound level

Length 54 in / 137 0 mm

Width 28 in / 710 mm

Height 44 in / 1,120 mm

Net weight 675 lb / 307 kg with batteries installed

Sound level 76 dBA

Warranty 3 years/2500 hrs on parts and labor (excluding batteries).

10 years on rotationally-molded polyethylene tanks.

Concord®HP Plus

specifications
