INSTALLATION, OPERATION,

AND SERVICE MANUAL

HT-180 HH

SERIES

HT-180 HH Series Manual • 07610-003-26-29-H

NOBLE DOOR-TYPE DISHMACHINES

REVISION HISTORY

Revision

Letter

Revision

Date Made by Applicable

ECNs Details

A 7-24-15 KAP N/A Release to production.

B 10-8-15 KAP N/A Added HH ventless booster tank assembly on pg. 40.

C 11-10-15 JH N/A Corrected P/N for item #40 on pg. 37.

D 11-23-15 JH QOF-386 Replaced Plumbing Booster Inlet diagram, pg. 50.

E 1-12-16 JH

QOF-386

N/A

Changed item #12 on pg. 36 to 05700-003-07-76.

Added 05700-004-23-78, 05700-004-23-79, and 05700-004-23-

80 to view (pg. 35) and parts list (pg. 36).

Corrected Typical Electrical Circuits for HT-180HH Ventless.

F 5-11-17 JH N/A

Removed views that showed pressure regulator in certain

locations. Added the pressure regulator as an option.

Added exploded view and parts list for Motor & Pump Assembly.

Changed name of delime switch throughout from NORMAL/

DELIME to AUTO/MANUAL.

Added instructions on rinse arm maintenance to the

Maintenance section.

Added dimensions for the corner table notch to the Table

Dimensions page.

Added a Plumbing Options page.

Added the dispenser connections decal for the 460 V machine.

Added instructional pictures where appropriate.

Added external device wiring instructions as an Addendum.

Added instructions for programming new exhaust fan timer.

Updated schematics.

Updated to new manual format.

Audited and corrected all P/Ns in the manual.

G 9-11-17 JH 8541

8543

Moved door switch from the Tub Assembly page to the Hood

Assembly page.

Added door switch bracket assembly to the Hood Assembly

page.

Updated schematics.

H 10-23-18 JH

8392

8533

8536

8558

8567

8576

8599

Updated pg. 4.

Changed steam pressure to 10-30 PSI on pg. 5.

Updated electrical requirements on pgs. 6-7.

Added links to exhaust fan timer instructions to pg. 9.

Added Chemical Connections section to pg. 10.

Added Motor Rotation section to pg. 11.

Added False Panel/Corner Install section to pg. 12.

Added new exhaust fan timer to pgs. 23 and 25.

Changed P/N for contactor, item #4 on pg. 24.

Updated pgs. 28-29 with new door and arm assembly.

Replaced thermostat and components with solid state thermostat

and components pgs. 30-34.

Added phase conversion kit P/Ns to pg. 41.

Changed rinse arm bearing assembly on pgs. 52-53.

Changed rinse arm bearing kit P/N on pg. 53.

Added list of applicable kits to pg. 59.

Updated schematics.

The manufacturer provides

technical support for all of

the machines detailed in

this manual. We strongly

recommend that you refer to

this manual before making a

call to our technical support

sta󰀨. Please have this manual

open when you call so that our

sta󰀨 can refer you, if necessary,

to the proper page. Technical

support is not available on

holidays.

Contact technical support toll

free at 1-888-800-5672.

Technical support is available

for service personnel only.

NOMENCLATURE

HT-180 HH

Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing,

with booster heater.

HT-180 HH NB

Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing,

no rinse booster.

HT-180 HH S

Door-type dishmachine; steam-heated, high-temp, hot-water sanitizing.

HT-180 HH VER

Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing,

with booster heater and ventless energy recovery system.

GUIDES

Symbols......................................................................................................................................... 1

Abbreviations & Acronyms ............................................................................................................ 1

SPECIFICATIONS

Dimensions.................................................................................................................................... 2

Dimensions - HH VER................................................................................................................... 3

Table Dimensions .......................................................................................................................... 4

Operating Parameters ................................................................................................................... 5

Electrical Requirements ................................................................................................................ 6

INSTALLATION

Installation Instructions.................................................................................................................. 8

Inspection......................................................................................................................... 8

Unpacking........................................................................................................................ 8

HH VER Assembly........................................................................................................... 8

Leveling............................................................................................................................ 8

Plumbing.......................................................................................................................... 8

Water Supply Connection ................................................................................................ 8

Steam Line Connection.................................................................................................... 9

Pressure Regulator.......................................................................................................... 9

Shock Absorber ............................................................................................................... 9

Connecting the Drain Line ............................................................................................... 9

Exhaust Fan Timer........................................................................................................... 9

Chemical Connections................................................................................................... 10

Plumbing Check............................................................................................................. 10

Electrical Power Connections .........................................................................................11

Motor Rotation ................................................................................................................11

Voltage Check................................................................................................................ 12

Surrounding Area........................................................................................................... 12

Temperature Setpoints................................................................................................... 12

False Panel/Corner Install.............................................................................................. 12

Facility Hot Water Heater............................................................................................... 12

TABLE OF CONTENTS

OPERATION

Operating Instructions ................................................................................................................. 13

Preparation..................................................................................................................... 13

Power Up........................................................................................................................ 13

Filling the Wash Tub ....................................................................................................... 13

Ware Preparation ........................................................................................................... 13

Daily Machine Preparation ............................................................................................. 13

Warm-up Cycles ............................................................................................................. 14

Washing a Rack of Ware................................................................................................ 14

Operational Inspection.................................................................................................... 14

Shutdown & Cleaning..................................................................................................... 14

VER Coil Cleaning.......................................................................................................... 16

Detergent Control ........................................................................................................... 17

Deliming.......................................................................................................................... 18

MAINTENANCE

Preventative Maintenance........................................................................................................... 19

TROUBLESHOOTING

Common Problems...................................................................................................................... 20

PARTS

Control Box.................................................................................................................................. 22

Hood............................................................................................................................................ 26

Door & Arm.................................................................................................................................. 28

Tub .............................................................................................................................................. 30

Steam Tub ................................................................................................................................... 33

Frame .......................................................................................................................................... 35

Rinse Tank .................................................................................................................................. 36

VER Rinse Tank ......................................................................................................................... 37

Steam Coil .................................................................................................................................. 38

Motors ......................................................................................................................................... 39

Heaters........................................................................................................................................ 41

Inlet Plumbing - HH ..................................................................................................................... 42

Outlet Plumbing - HH .................................................................................................................. 44

Plumbing - HH VER ................................................................................................................46

Inlet Plumbing - HH S ................................................................................................................. 48

Outlet Plumbing - HH S .............................................................................................................. 49

TABLE OF CONTENTS

vii

PARTS

Plumbing Options ....................................................................................................................... 50

Solenoid Valve & Vacuum Breaker Parts .................................................................................... 51

Wash & Rinse Assemblies........................................................................................................... 52

VER System ................................................................................................................................ 54

VER System Door Interlock......................................................................................................... 56

VER System Door Interlock Override.......................................................................................... 57

460 V Machine Transformer Mounting Box ................................................................................. 58

Kits .............................................................................................................................................. 59

SCHEMATICS

HH/HH VER 208/230 V ............................................................................................................... 60

HH/HH VER 460 V ...................................................................................................................... 61

HH NB 208/230 V........................................................................................................................ 62

HH NB 460 V............................................................................................................................... 63

HH S 208/230 V .......................................................................................................................... 64

SDI Options ................................................................................................................................. 65

TABLE OF CONTENTS

07610-004-26-29-H

GUIDES GUIDES

SYMBOLS

CAUTION

WARNING

NOTICE

- risk of injury to personnel.

- risk of damage to equipment.

- risk of electrical shock.

- lockout electrical power.

- reference data plate.

- important note.

- caustic chemicals.

ABBREVIATIONS & ACRONYMS

 - instructions hyperlink.

ANSI - American National Standards Institute

Btu/Hr - British Thermal Units per Hour

CFM - Cubic Feet per Minute

GHT - Garden Hose Thread

GPH - Gallons per Hour

GPM - Gallons per Minute

GPG - Grains per Gallon

HP - Horsepower

Hz - Hertz

ID - Inside Diameter

kW - Kilowatts

MCA - Minimum Circuit Ampacity

MOP - Maximum Overcurrent Protection

NFPA - National Fire Protection Association

NPT - National Pipe Thread

OD - Outside Diameter

PRV - Pressure Regulating Valve

PSI -Pounds per Square Inch

V- Volts

07610-004-26-29-H

[641 mm]

31 [803 mm]

[97 mm] 1

[25 mm]

[864 mm]

[299 mm]

6812

[1740 mm]

7638

[1941mm]

[641 mm]

[1874 mm]

[686 mm]

CLEARANCE

[2203 mm]

WITH DOOR

OPEN

[1854 mm]

17 [432 mm]

[727 mm]

25 [635 mm]

15 [387 mm]

LEGEND

A - Drain 1 1/2" NPT

B - Water Inlet 3/4" NPT

C - Electrical Connection

increased 2" using the machine's

adjustable feet.

[1856mm]

[102 mm]

MINIMUM

4 [124 mm]

[102 mm]

MINIMUM

[508 mm]

5 1/2

(140 mm)

D - Optional Steam Connection 3/4” NPT

DIMENSIONS

SPECIFICATIONS

07610-004-26-29-H

( 3 mm)

4(79mm)

151

4(387mm)

113

4(298mm)

17 (432mm)

2 ( 7mm)

73 (1856mm)

34 (861mm)

93 (2362mm)

88 (2235mm)

10mm

4(134mm)

LEGEND

A - Drain 1 1/2" NPT

B - Water Inlet 3/4" NPT

C - Electrical Connection

increased 2" using the machine's

adjustable feet.

(

872

7 ( mm)

CLEARANCE

2668

325

MINIMUM

DIMENSIONS - HH VER

SPECIFICATIONS

07610-004-26-29-H

TABLE DIMENSIONS

SPECIFICATIONS

(762 mm)

8 1/4

(210 mm)

20 1/2”

(521 mm)

OPENING

4 (102 mm) MIN

ALIGN WITH TABLE -

DISTANCE CAN VARY

4 (102 mm) MIN

ALIGN WITH TABLE -

DISTANCE CAN VARY

8 1/4

(210 mm)

Distance from wall

to rear rack rail.

Distance from wall

to right rack rail.

Control Panel

1 1/4”

[32 mm]

1 3/8”

[35 mm]

20 1/2”

[521 mm]

OPENING

(762 mm)

8 1/4

(210 mm)

20 1/2”

(521 mm)

OPENING

4 (102 mm) MIN

ALIGN WITH TABLE -

DISTANCE CAN VARY

Distance from wall

to rear rack rail. Control Panel

20 1/2”

(521 mm)

OPENING

For corner

install instructions:

CORNER INSTALLATION

STRAIGHT-THROUGH INSTALLATION



Otros manuales para HT-180 HH

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lavavajillas de Noble

Noble

Noble HT-180EC Guía de configuración

Noble

Noble UH30 Manual

Noble

Noble DG-E Manual

Noble

Noble HT-180 HH Guía de configuración

Noble

Noble 495HTGW22 Manual de usuario

Noble

Noble UH30-E Guía de configuración

Noble

Noble HT-180 Series Manual de usuario

Noble

Noble CG-1200 Guía de configuración

Noble

Noble CG-115 Manual de usuario

Manuales populares de Lavavajillas de otras marcas

Electrolux

Electrolux ESI5211LOX Manual de usuario

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario
