Njoy Aster Series Manual de usuario
Aster Series EBM User Manual
Manual de ulizare
UPBPCA0312FX-CG01B
UPBPCA0712FX-CG01B
Before using this product, carefully read all product documentaon and retain it for future reference.
131.0
2 3
English
Română
Product overview
Batteries Module
Battery Cable
Rackmount ears (2 pcs)
Flat head screws: M4X8L (8)
Pan head screws: M5X12L (4)
Screw hole dust covers (8)
Ground wire
User manual
Warranty card
Package contents
1
2
The following EBM models are compable with the Aster Series UPS:
CA0712F
CA0312F
Aster 2K / 3K
Aster 1K
Thank you for purchasing our products!
Please read this manual before using the product.
Focusing on quality at compeve prices, nJoy designs
consumer products for a beer and enjoyable way into
the digital world.
The baery pack is a product that works only with an UPS. The
baery pack will provide or extend the backup me of your UPS.
Aster EBM CA0312F/ CA0712F - Front view
Aster EBM CA0312F/ CA0712F - Back view
NOTE!
Before installaon, please inspect the unit. Be sure that nothing inside the
package is damaged. Keep the original package in a safe place for future use.
1 2 3
1. On-board Replaceable Fuse Cover:
Replaceable fuse is accessible from the rear panel. It must be done by
qualied personnel.
2. Baery Input Connector:
Use this input Connector to connect the Baery module to the Power
module (UPS) or to Output connector of another Baery module.
3. Baery Output Connector:
Use this output connector to daisy chain the next Baery module (Note:
Please be aware that UPS models Aster 1K, Aster 2K and Aster 3K
support only one Baery module).
4 5
English
Română
Important safety warnings
3
Please read carefully the following instrucons before installing the unit.
Do not operate this unit before reading through all safety informaon
and operang instrucons carefully!
Preparaon
• This baery bank is connected to an UPS. There will be voltage at the
output terminals if the UPS is turned on even if the input AC Mains is
not available.
• Make sure that the AC Ulity outlet is correctly grounded.
• Do not try to repair the unit yourself, contact your local supplier or
your warranty will be void.
Installaon and connecon warnings
• Use a cered input power cable with the correct plugs and sockets.
• To eliminate any overheang of the baery bank, keep all venlaon
openings free from obstrucon and do not place any foreign objects
on top of the baery bank. Keep the baery bank 20 cm away from
the wall.
• Make sure the baery bank is installed within the proper
environment as specied: 0-40°C and 30-90% non-condensing
humidity.
Storage and maintanance
• The warranty for this baery bank will be void if water or other liquid
is spilt or poured directly onto the baery bank. Similarly, warranty is
void if any damage to the baery bank occurs due to foreign objects
which are deliberately or accidentally inserted into the baery bank
enclosure.
• The baery will discharge naturally if the system is unused for a
period of me. It should be recharged every 2-3 months if unused.
If this is not done, then the warranty will be void. During normal
operaon, the baeries will be automacally charged.
• Servicing of baeries should be performed or supervised by trained
personnel only. When replacing baeries, replace with the same
quanty, type & capacity.
• The unit contains no user-serviceable parts. If the baery service
life has been exceeded, the baeries must be replaced. In this case,
please contact your dealer.
Cautions regarding battery installation
• Do not install the battery bank under direct sunlight. Your
warranty will be void if the batteries fail due to overheating.
• This battery bank is designed for indoor use only.
• This battery bank is not designed for use in dusty, corrosive
and salty environment.
Other battery cautions
•Donotdispose of batteriesinanopen fire,they may explode.
• Do not open or otherwise damage the batteries. The
electrolyte from the batteries is toxic and harmful to the
skin and eyes. Risk of electric shock! The battery circuit is
not isolated from AC, hazardous voltage may exist between
battery terminals and ground. Test before touching with
bare hands.
• A battery can present a risk of electrical shock and high
short circuit current.
6 7
English
Română
Installing your baery module
4
4.1 Rack-mount installaon
1. Rack-mount ears installaon
Aach the two rackmount ears to the baery module using the provided
screws M4X8L*8pcs.
2. Install the baery module on the rack
Place the baery module on a at stable surface with the front of the
unit facing toward you. Secure the baery module to your rack with four
M5X12L screws at the front of the rack. (Located in posion 2 & posion 5).
4.2 Tower installaon
1. Aach the base stands
Tighten the screws (M4X8L*8pcs) of the base stands (rackmount ears)
onto the boom of the baery module.
2. Aach dust covers
Insert dust cover into the rackmount ear screw holes that are not being
used.
89
English
Română
Baery Installaon and replacement
5
If your baery pack is not installed with baeries, please follow the
proper procedure to put the baeries inside the unit.
NOTE!
Make sure that the baery pack is disconnected from the UPS before
performing the following sequence of operaons!
Following these precauons when working on baeries:
• Remove watches, rings, or other metal objects.
• Use tools with insulated handles.
• Do not lay tools or metal parts on top of baeries as you might
produce a short.
• Disconnect charging source prior to connecng or disconnecng
baery terminals.
• Do not plug or unplug the baery connector if UPS works in DC
(discharging) mode.
IMPORTANT NOTE
Please be aware that UPS models Aster 1K, Aster 2K and Aster
3K support only ONE Battery module.
Step 1. Unscrew and remove the top cover from the baery module.
Step 2. Unscrew and unplug steel straps from the baery module.
Step 3. Remove the baery pack from the module.
Step 4. Open the baery pack and begin placing the baeries.
For 36 Vdc baery pack (UPBPCA0312FX-CG01B)
A. Place 3 baeries in the le tray and connect the cables as shown in
the image below. (the following drawing indicates the fasten posions for
the correct baeries connecon).
10 11
English
Română
B. Aer connecng the cables, rotate the baeries as shown below and
close the lid of the tray (the illustraon shows only the baery posions,
not the cables).
C. Place 3 baeries in the right tray and connect the cables as shown in
the image below. (the following drawing indicates the fasten posions for
the correct baeries connecon).
D. Aer connecng the cables, rotate the baeries as shown below and
close the lid of the tray (the illustraon shows only the baery posions,
not the cables).
E. Place the trays back into the cabinet and connect the baery cables
with the cabinet’s cables as shown in the picture below.
12 13
English
Română
For 72 Vdc baery pack (UPBPCA0712FX-CG01B)
A. Place 6 baeries in the le tray and connect the cables as shown in
the image below. (the following drawing indicates the fasten posions for
the correct baeries connecon).
B. Aer connecng the cables, rotate the baeries as shown below and
close the lid of the tray (the illustraon shows only the baery posions,
not the cables).
C. Place 6 baeries in the right tray and connect the cables as shown in
the image below. (the following drawing indicates the fasten posions for
the correct baeries connecon).
D. Aer connecng the cables, rotate the baeries as shown below and
close the lid of the tray (the illustraon shows only the baery posions,
not the cables).
14 15
English
Română
E. Place the trays back into the baery cabinet and connect the baery
cables with the cabinet’s cables as shown in the picture below.
Step 5. Reasemble the steel straps and the top cover. The cabinet is now
ready to be connected to the UPS.
Connecng baery pack module
6
Follow the image below in order to connect the baery pack with Aster
1K, Aster 2K and Aster 3K UPS with included cable.
IMPORTANT NOTE
Please be aware that UPS models Aster 1K, Aster 2K and Aster
3K support only ONE Battery module.
17
English
Română
16
Disposal of Old Electrical & Electronic Equipment
(Applicable in the European Union and other European countries with
separate collecon systems)
This symbol on the product or on its packaging indicates that this product shall not be
treated as household waste.
Instead it shall be handed over to the applicable collecon point for the recycling of
electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potenal
negave consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product.
The recycling of materials will help to conserve natural resources.
Mulțumim pentru că ați ales produsele noastre!
Vă rugăm ciți cu atenție manualul de ulizare înainte de a
pune în funcțiune acest produs.
Concentrându-ne pe calitate la preţuri compeve,
construim produse pentru consumatori în ideea unei
interacţiuni cât mai plăcute cu lumea digitală.
Cabinetul de baterii este un produs care funcționează doar
împreună cu un UPS. Acesta asigură sau suplimentează rezerva
de energie pentru UPS.
NOTĂ!
Înainte de instalare inspectați unitatea. Fiți siguri că nimic din interiorul
pachetului nu este stricat. Țineți pachetul original într-un loc sigur pentru o
ulizare ulterioară.
Cabinet de baterii
Cablu pentru baterii
Accesorii rack (2 pcs)
Șuruburi tip M4X8L (8)
Șuruburi tip M5X12L (4)
Dopuri apărătoare de praf (8)
Cablu împământare
Manual de utilizare
Certificat de garanție
Conținut cue
1
Următoarele modele de cabinete sunt compabile cu seria Aster:
CA0712F
CA0312F
Aster 2K / 3K
Aster 1K
18 19
English
Română
Prezentarea produsului
2
Aster EBM CA0312F/ CA0712F - Vedere din față
Aster EBM CA0312F/ CA0712F - Vedere din spate
1 2 3
1. Capac siguranță înlocuibilă:
Siguranța înlocuibilă este accesibilă de pe panoul din spate. Înlocuirea
trebuie să e făcută de personal calicat.
2. Conector de intrare al modulului de baterii:
Ulizați acest conector de intrare pentru a conecta modulul baterie la UPS
sau la conectorul de iesire al altui modul baterie.
3. Conector de ieșire al modulului de baterii:
Ulizați acest conector de ieșire pentru a conecta următorul modul
baterie (Observae: La modelele de UPS Aster 1K, Aster 2K și Aster 3K
se poate conecta un singur modul de baterii). .
Averzări de siguranță
3
Vă rugăm să respectați toate aversmentele și instrucțiunile de ulizare
din acest manual. Nu folosiți această unitate înainte de a ci toate
instrucțiunile de siguranță și de ulizare cu atenție:
Pregăre
• Acest cabinet de baterii este conectat la un UPS, asel că la
terminalele acestuia va exista curent electric chiar dacă intrarea UPS-
ului nu este conectată la rețea.
• Vericați ca toate prizele să e corect împământate.
• Nu încercați să reparați dumneavoastră acest produs, pentru orice
problemă contactați centrul de service, în caz contrar veți pierde
garanția.
Averzări privind conectarea și instalarea
• Vă rugăm să folosiți numai cabluri de alimentare și prize testate VDE
și cu marcaj CE pentru a conecta produsul.
• Pentru eliminarea posibilității de supraîncălzire a cabinetului de
baterii, aveți grijă ca toate fantele de aerisire să e deschise și nu
amplasați niciun obiect străin pe suprafața produsului. Amplasați
produsul de așa natură încât între el și pereți să rămână o distanță de
cel puțin 20 cm.
• Instalați produsul într-un mediu corespunător, cu o temperatură
cuprinsă între 0-40 grade C și umiditate relavă fără condensare între
30%-90%.
Atenționări cu privire la instalarea bateriilor
• Nu instalați produsul sub incidența directă a razelor solare.
În caz de supraîncălzire a bateriilor, veți pierde garanția.
• Produsul este destinat doar pentru utilizare de interior.
• Totodată, el nu este proiectat a fi utilizat în medii corozive
sau cu mult praf.
Otros manuales para Aster Series
1
Este manual sirve para los siguientes modelos
5
Tabla de contenidos
Idiomas:
Otros manuales de Unión Postal Universal de Njoy
Njoy
Njoy Ranger 60KR Manual de usuario
Njoy
Njoy Argus Series Manual de usuario
Njoy
Njoy Cadu 650 Manual de usuario
Njoy
Njoy Echo Pro Series Manual de usuario
Njoy
Njoy Ranger 30KT Manual de usuario
Njoy
Njoy Cadu Series Manual de usuario
Njoy
Njoy Renton 650 Manual de usuario
Njoy
Njoy Balder Series Manual de usuario
Njoy
Njoy Ranger 30KR Manual de usuario
Njoy
Njoy Shed 625 Manual de usuario
Njoy
Njoy Aster Series Manual de usuario
Njoy
Njoy Helios PRO Series Manual de usuario
Njoy
Njoy Aira 600 Manual de usuario
Njoy
Njoy PWAV-10001AK-AZ01B Manual de usuario
Njoy
Njoy Soter 600 Manual de usuario
Njoy
Njoy Eido 600 Manual de usuario
Njoy
Njoy Balder Series Manual de usuario
Njoy
Njoy Echo Pro Series Manual de usuario
Njoy
Njoy Code Series Manual de usuario
Njoy
Njoy Soter 600 Manual de usuario
Manuales populares de Unión Postal Universal de otras marcas
Pylontech
Pylontech Victron & Pylontech US5000 Manual de usuario
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario
Mecer
Mecer ME-1000-WTU Manual de usuario
Mustek
Mustek PowerMust 530(B) Plus Manual de instalación y operación
Emerson
Emerson Liebert NXL series Manual de usuario
MAKELSAN
MAKELSAN BOXER SERIES Manual de usuario
