Njoy Aster Series Manual de usuario

Aster Series User Manual

Manual de ulizare

UPCMCOP910HASCG01B

UPCMCOP920HASCG01B

UPCMCOP930HASCG01B

Before using this product, carefully read all product documentaon and retain it for future reference.

131.0

UPS unit

Power cord

USB cable

Screws

Screw hole dust covers

Rack accessories

User manual

Warranty card

Package contents

The following models belong to the Aster Series UPS:

2000 VA

1000 VA

3000 VA

Aster 2K

Aster 1K

Aster 3K

Thank you for purchasing our products!

Please read this manual before using the product.

nJoy is a brand of power and backup protecon products that

create soluons for mulple levels of environment complexity,

residenal to industrial.

This UPS will protect your electronic equipment from physical

damage and will provide emergency baery backup power to

prevent data loss in the event of power problems.

NOTE!

Before installaon, please inspect the unit. Be sure that nothing inside the

package is damaged. Keep the original package in a safe place for future use.

English

Română

Product overview

Aster 1K/2K/3K - Front view

Aster 1K/2K - Back view

Aster 3K - Back view

ON ESC

1 2

5 8 10

1197

5 8 10

12 1197

1. Power On/O buon: Master ON/OFF for the UPS.

2. Funcon Buons: Scroll up, scroll down, select and cancel LCD menu

in seng mode.

3. LCD Display: Indicate status informaon, sengs and events.

4. Input Circuit Breaker: The circuit breaker provides opmal overload

protecon.

5. AC Input Inlet: Connect the AC Power cord to a properly wired and

grounded outlet.

6. Baery Backup & Surge Protected Outlets: Provide baery backup

and surge protecon. They ensure power is provided to connected

equipment over a period of me during a power failure.

Crical / Non-crical outlets: Allows the creaon of load priories to

ensure that baery power reserves are transferred to specied outlets

during a power outage. The unit can be programmed to provide

addional runme for equipment connected to the “CRITICAL”

outlets, while stopping the power supply to equipment connected to

“NON-CRITICAL” outlets aer a designated period of me.

7. Extended Runme Baery Module Connector: Connect to

addional external baery modules.

8. SNMP/HTTP Network slot: Slot to install the oponal SNMP card

for remote network control and monitoring.

9. EPO (Emergency Power O) Connector: Enable Power-O in

emergency from a remote locaon.

10. Serial Port: Serial port provides communicaon between the UPS

and the computer. The UPS can control the computer’s shutdown

during a power outage through the connecon while the computer

can monitor the UPS and alter its various programmable parameters.

11. HID USB port: Allows the UPS to appear in Windows like a baery

icon. When the power is out, you can sll see the baery level and

adjust its sengs. Also Windows power management opons are

available. In case you need more advanced local management we

recommend you to install and use “PowerMonitor” soware.

12. Output Circuit Breaker: Provide overload and fault protecon.

English

Română

Important safety warnings

Please comply with all warnings and operang instrucons in this manual

strictly. Save this manual properly and carefully read the following

instrucons before installing the unit. Do not operate this unit before

reading through all safety informaon and operang instrucons

carefully:

Transportaon

• Please transport the UPS system only in the original package to

protect against shock and impact.

Preparaon

• Condensaon may occur if the UPS system is moved directly from

cold to warm environment. The UPS system must be absolutely dry

before being installed. Please allow at least two hours for the UPS

system to acclimate to the environment.

• Do not install the UPS system near water or in moist environments.

• Do not install the UPS system where it would be exposed to direct

sunlight or near heat sources.

• Do not block venlaon holes in the UPS housing.

Installaon

• Do not connect appliances or devices which would overload the UPS

system (e.g. laser printers) to the UPS output sockets.

• Place cables in such a way that no one can step on or trip over them.

• Do not connect domesc appliances such as hair dryers to UPS

output sockets.

• The UPS can be operated by any individuals with no previous

experience.

• Connect the UPS system only to an earthed shockproof outlet which

must be easily accessible and close to the UPS system.

• Please use only VDE-tested, CE-marked mains cable (e.g. the mains

cable of your computer) to connect the UPS system to the building

wiring outlet (shockproof outlet).

• Please use only VDE-tested, CE-marked power cables to connect the

loads to the UPS system.

• When installing the equipment, it should ensure that the sum of

the leakage current of the UPS and the connected devices does not

exceed 3.5mA.

Operaon

• Do not disconnect the mains cable on the UPS system or the building

wiring outlet (shockproof socket outlet) during operaons since this

would cancel the protecve earthing of the UPS system and of all

connected loads.

• The UPS system features its own, internal current source (baeries).

The UPS output sockets or output terminals block may be electrically

live even if the UPS system is not connected to the building wiring

outlet.

• In order to fully disconnect the UPS system, rst press the OFF/Enter

buon to disconnect the mains.

• Prevent uids or other foreign objects from entering the inside of the

UPS system.

• WARNING: This is a category C2 UPS product. In a residenal

environment, this product may cause radio interference, in which

case the user may be required to take addional measures.

Maintenance, service and faults

• The UPS system operates with hazardous voltages. Repairs may be

carried out only by qualied maintenance personnel.

• Cauon - risk of electric shock. Even aer the unit is disconnected

from the mains (building wiring outlet), components inside the UPS

system are sll connected to the baery and electrically live and

dangerous.

• Before carrying out any kind of service and/or maintenance,

disconnect the baeries and verify that no current is present and no

hazardous voltage exists in the terminals of high capability capacitor

such as BUS-capacitors.

English

Română

• Only persons are adequately familiar with baeries and with the

required precauonary measures may replace baeries and supervise

operaons. Unauthorized persons must be kept well away from the

baeries.

• Cauon - risk of electric shock. The baery circuit is not isolated

from the input voltage. Hazardous voltages may occur between the

baery terminals and the ground. Before touching, please verify that

no voltage is present!

• Baeries may cause electric shock and have a high short-circuit

current. Please take the precauonary measures specied in this

manual and any other measures necessary when working with

baeries: remove wristwatches, rings and other metal objects, use

only tools with insulated grips and handles.

• When changing baeries, install the same number and same type of

baeries.

• Do not aempt to dispose of baeries by burning them. This could

cause baery explosion.

• Do not open or destroy baeries. Escaping electrolyte can cause

injury to the skin and eyes. It may be toxic.

• Please replace the fuse only with the same type and amperage in

order to avoid re hazards.

• Do not dismantle the UPS system.

Installing your UPS system

4.1 Rack-mount installaon

1. Rack-mount ears installaon

Aach the two rackmount ears to the UPS using the provided screws

M4X8L*8pcs.

2. Install the UPS on the rack

Place the UPS on a at stable surface with the front of the unit facing

toward you. Secure the UPS to your rack with four M5X12L screws at

the front of the rack. (Located in posion 2 & posion 5).

English

Română

4.2 Tower installaon

1. Aach the base stands

Tighten the screws (M4X8L*8pcs) of the base stands (rackmount ears)

onto the boom of the UPS.

2. Aach dust covers

Insert dust cover into the rackmount ear screw holes that are not being

used.

Baery Installaon and replacement

Step 1. Remove the front panel. Remove the retaining screws from the

baery bracket and then remove the cover itself. undraw the connectors.

Step 2. Pull the baery tray out slowly. Put the new baery tray back

into the compartment aer that.
