Section 7 - ADDRESS SETTING
To set the address of the device, set the address switch by adding
up the numbers on the left or right side. For example to set
address 24, set switch 4 and 5 to the ‘ON’ position. Switch 4 gives
you 8 and setting switch 5 adds 16 which gives the address 24. In
the example to the left, the address is set to 49 (1 + 16 + 32).
Section 8 - VOLUME
To set the volume, place the link in high or low volume position.
Section 9 - TONE CONFIGURATION
To set the sound pattern, set the tone selection switch according
to the table below. In the example to the left, tone 13 is selected
as switch 1 and 2 is on and switch 3 and 4 is off.
Ref No: 000011 Date: 16.04.09 Issue: 7
• evolution • EV-ABS • addressable base sounder instruction manual
5
Tone Alarm Alert SW1 SW2 SW3 SW4
1 Standard alarm tone. 750Hz/1000Hz alternating, 0.5s for each tone 10 ON ON ON ON
2 Warble tone, general use. 850-950Hz sweep at 9Hz 10 OFF ON ON ON
3 Sweep 1s (UK). 800Hz to 970Hz sweep over 1s, repeating 10 ON OFF ON ON
4 French fire tone. 440Hz for 400ms, 554Hz for 100ms, repeating 10 OFF OFF ON ON
5 German DIN tone. 1200Hz to 500Hz sweep over 1s, repeating 10 ON ON OFF ON
6 Dutch tone. 500Hz to 1200Hz over 3.5s, 0.25s gap, repeating 10 OFF ON OFF ON
7 Pulsed tone 1s on, 1s off at 750Hz 10 ON OFF OFF ON
8 Continuous, 750Hz 10 OFF OFF OFF ON
9 Continuous, 1000Hz 10 ON ON ON OFF
10 Pulsed tone 1s on, 1s off at 1000Hz 10 OFF ON ON OFF
11 Alternating at 2250Hz for 0.5s, 3000Hz, for 3s 10 ON OFF ON OFF
12 Sweep 9Hz. 2250Hz to 3000Hz, repeating 10 OFF OFF ON OFF
13 Sweep 1Hz. 2250Hz to 3000Hz, repeating 10 ON ON OFF OFF
14 Continuous, 3000Hz 10 OFF ON OFF OFF
15 Pulsed tone 1s on, 1s off at 3000Hz 10 ON OFF OFF OFF
16 Silent (no sound) 10 OFF OFF OFF OFF
