Nilfisk-Advance AX 310 Manual de usuario

On-board accessories on

AX 410 make it easy to clean

seat and wall coverings and

hard to-reach spots

The control panel is simple

to understand and easy to

use

AX 310/410 – the newest and most modern

options in carpet cleaning

The handle is

adjustable for easy

storage and ergonomic

operation

•AX 410 offers dual mode cleaning - choose

maintenance and renovation mode by turning a

simple valve

• AX 310 is the rugged no-frills version for rental

and simplified applications

• Quality design and first-class engineering saves

water and chemicals

• State-of-the-art moisture recovery speeds up

drying time

• Durable construction for long-life

Large, non-marking

wheels for easy

operation and

transport

Rotating brush for

deep cleaning

Rugged aluminium vacuum

shoe for excellent water

recovery

AX 310 is an economically

priced extractor with basic

functional features

An extensive range of accessories

Nilfisk-Advance A/S

Sognevej 25

DK-2605 Brøndby

Denmark

Tel.: +45 4323 8100

Fax: +45 4343 7700

www.nilfisk-advance.com

TECHNICAL SPECIFICATIONS

Description Unit AX9/14 UC 912 AX 310 AX 410 AX 650 BRX 700

Rated power W1000 2000 900 1120 2000 3220

Vacuum kPa 20 22 -- 18.3 18.3

Brush motor W - - 243 246 2 x 560 375

Brush speed r.p.m - - 1000 1000 1,200 900

Suction width mm 220 270 310 457 780 710

Working width mm 220 270 260 410 635 710

Airflow L/sec 60 51 41 46 44 80

Sound level dBA 76 59-69 72 69 76 73

Solution/ recovery tank litre 9/14-7,5/14 15/45 19/15 30/23 151/117 170/95

Solution pump

- low moisture mode - 1.9 l/min psi 5 3,5 60 60 100 100

- restoration mode - 4.1 l/min psi 53,5 60 60 100 100

Cable length m 10 15 7,5 15 - -

Weight (machine only) kg 11,7/12,7 22 30 45 195 283

Dimension ( L x W x H ) cm 54x37,5/50x40 90x45x99 64x33x72 71x47x80 140x71x109 152x79x130

Specifications and details are subject to change without prior notice.

Every cleaning application is special, and to get the best out of the machines you buy it is important to have

the right accessories to go with them.

The right accessories not only enable the cleaning job to be done in the fastest and most efficient way, they

also help to prevent damage to the machine and reduce maintenance cost.

All products carrying the Nilfisk-Advance label have been fully tested and are guaranteed for use with our

equipment.

Nilfisk AX 9/14, UC 912, AX 310/410, AX 650, BRX 700

Carpet Extractors

Caring for your

carpet!

Clean carpets

last longer!

Dual Mode or Basic - the choice is yours

The AX 310/410 - intelligent options for cleaning carpets

in mid-sized area.

Fast and effective dirt extraction from carpets is the

name of the game. Thanks to the intelligent design and

quality engineering that are the hallmark of all Nilfisk

machines, the AX 310 and AX 410 are ready-to-go,

reliable and simple to use.

The needs of all carpet extractor users are not the same.

AX 410 is the right choice if on-board accessories and

dual mode cleaning is required. For those demanding an

economically priced extractor the AX 310 offers all the

basic functionality.

Both these models offer you the unique dual cleaning

mode system to allow you to switch between a real

deep clean of the carpet, and a low moisture

maintenance mode that ensures a fast turnaround of

the area. They are ideal for cleaning medium sized

carpeted areas in offices, schools, airports, restaurants,

hotels, shopping malls, and other heavy traffic areas.

| UC 912 ||AX 9/14 |

Keeping operating

cost down

A COMMERCIAL CARPET EXTRACTOR WITH TROLLEY, VERY

HIGH SUCTION AND DRYING CAPACITY

COMPACT BOX EXTRACTORS FOR EFFECTIVE SPOT-

CLEANING

•Perfect for all applications where cleaning solution has to be

pressure-applied

•For spot cleaning, carpet cleaning and other tough cleaning

jobs

• Solution is distributed directly to the surface through a spray

nozzle, activated by a trigger on the handle

•The high capacity vacuum recovers dirty solution and leaves

the carpet slightly damp

•Can also be used as a separate wet and dry vacuum cleaner

www.nilfisk-advance.com

For more information:

Perfect for hard-to-reach

areas eg. theatres or

cinemas

Available in 9 or 14 litre

capacity, these extractors

meet the demand for flexible

cleaning of carpets, wall

coverings, rugs, armchairs,

seats and other textile

coverings

The AX 9/AX 14 provide an easy-to-use, effective way of taking

care of stains on carpet and textile coverings. Designed with the

user in mind, these machines are light and compact, easy to store

and simple to transport from area to area or job to job. When fast

spot cleaning is required, the AX9 or AX 14 will take care of it.

•A full range of accessory tools for flexibility in handling

various applications

• Perfect for spot cleaning and cleaning of carpets or fabrics in

small or hard-to-reach areas

•Superb design provides effective cleaning with a lightweight,

easy-to-move machine

• Polyethylene body and accessories with inox tubes ensure

durability and long-life

•The 4 pivot wheels provide full mobility

•The ideal extractors for cleaning contractors, institutions,

restaurants, rental stores, hotels etc.

| AX 650 ||BRX 700 |

TAKING CARPET CARE TO THE ULTIMATE LEVEL WHY WALK WHEN YOU CAN RIDE!

The advanced battery-powered AX 650 is a walk-behind extractor

that can be used either for deep-cleaning restoration work or for

interim maintenance cleaning.

The AX 650 battery-powered automatic extractor cuts

operation costs with longer run-time by minimizing operator

dumping and refilling time. The extractor is durable and

manoeuvrable. The heavy-duty steel frame and scrub deck is

corrosion-protected and built to last. The drive wheel is centred

for manoeuvrability and tight turning

•Dual purpose ability allowing interim cleaning or deep resto-

ration cleaning

• Two self-leveling vacuum shoes with down pressure

applied so that they follow the contour of the floor

• Easy maintenance (brush, vacuum shoes and vacuum motors

are removable without any use of tools)

• Double scrub with auto reverse scrub

The BRX 700 is the industry’s first ride-on sweeper/extractor, and is

the sensible answer for large area carpet cleaning.

It will change how your customers think about cleaning their

facilities. The machine is designed to improve productivity, reduce

operator fatigue and drive down the overall cost of cleaning.

The BRX 700 sweeps debris into the integrated hopper and

extracts dirt from the carpet in one pass. Due to the dual counter

rotating brushes the carpet is left with a groomed appearance

and with the 71 cm cleaning path, your productivity is increased

up to 400%!

• Cleans up to 1720 m2/h

• 160 cm turning radius and can fit through a 83 cm doorway

•One touch control, and excellent driver visibility

• Dual vacuum motors allow short drying time

•Designed to eliminate vacuuming before extracting by

sweeping and extracting in one pass!

Solution sprays directly into

the carpet for deep cleaning. Solution sprays on brush for

maintenance cleaning.

1. Restoration mode 2. Low moisture mode

Dual cylindrical technology

for rider sweeper/extractor

With a front roller that has

3 settings the carpet gets

cleaned all the way to the

edge

Easy switch between

restoration and maintenance

modes

No tools needed for daily

inspections of the brushes

and cleaning is simple

Dual vacuum motors are

protected by an anti-foam

chamber and easy access

vacuum filters, which

assure optimum air flow
