Niles IREMOTE Manual de usuario

QUICK INSTALL GUIDE

2-WAY WIRELESS RF

SYSTEM REMOTE CONTROL

WITH LCD DISPLAY

iREMOTE®

The IntelliControl ICS iRemote is a two-way RF (Radio

Frequency) hand-held remote control user interface. Eight

backlit Master Keys provide Niles exclusive “One Touch

to Music,” which turns the system on, selects a source

and starts the music. Additional backlit Hard Keys and

Soft Keys provide complete source and system control.

The High Resolution LCD displays metadata, setup menus

and important system information from the Niles source

modules. The iRemote includes a Master Charging Base

that recharges the battery and communicates with an

IntelliControl ICS Modular MultiZone Receiver to provide

system status updates from any zone.

Table of Contents

Product Overview ------------------------------------------------ 2

Getting Started---------------------------------------------------- 5

Installation---------------------------------------------------------10

ZigBee Networks ------------------------------------------------13

Operating the iRemote ----------------------------------------19

System Settings --------------------------------------------------28

Troubleshooting ------------------------------------------------- 35

Specifications ---------------------------------------------------- 36

Contact Information ------------------------------------------- 38

Warranty ---------------------------------------------------------- 39

J3&.05&

4&-&$5

/&95

13&7

70-



"#$



%&'





+,-



./0



()*



567



89:;



1234



&OUFS

.65&0''

;POF;POF

".'. $%$)/(3

J10% 3&26&45

30$, +";;

$-"44*$"- -*()54

The White Album

The Beatles

Revolution

MenuShuffle

iPod

PRODUCT OVERVIEW

Display – Backlit LCD

displays system information

from iPod, Digital Audio

Broadcasting Radio and AM/

FM and functions associated

with “Soft Keys”

Soft Keys

3 backlit buttons

that change function

depending upon the

source selected

Cursor Keys

and Select Key

5 backlit buttons provide

navigation of menus,

playlists and favorites

Master Keys

8 backlit buttons provide

“One Touch to Music”

OFF

Backlit button turns zone

or system off

PREV/NEXT

2 backlit buttons move to

Next or Previous/Track

or Station

Alphanumeric Keys

Provide direct access

tuning, numeric selection

of track and alphabetic

search for iPod

MUTE

Backlit button mutes/

un-mutes audio output

to zone

VOL+/VOL–

2 backlit buttons adjust

volume up or down

Niles System Settings

Provides access to system

settings: audio (bass,

treble, balance), sleep

timer, alarm clock, etc.

Figure 1. IntelliControl ICS iRemote

Charging Base

Battery Indicator

12V DC

Power Supply

www.nilesaudio.com

FEATURES AND BENEFITS

Two-Way Wireless Communication

The iRemote transmits commands to a Master Charging Base,

connected to the IntelliControl ICS Modular MultiZone Receiver

for system and source control. The iRemote Base/Charger receives

system and source status information and metadata from the

Master Charging Base as provided from the IntelliControl ICS

Modular MultiZone Receiver.

Eight Customizable, Backlit Master Keys Provide

“One Touch to Music”

Each of the 8 Master Keys can be customized to identify the

specific source or music genre that will be selected when that

button is pressed. The Master Keys turn the zone on, select a

source, and play your favorite channel or music selection.

High Resolution LCD Display with LED Backlighting

The high resolution LCD displays complete metadata from

IntelliControl ICS sources, zone and system status, “Soft Key”

control functions, and system setup menus.

Metadata, Preset Favorites and Menus

Metadata (channel frequency, favorite channel lists, menus

and guides) are displayed as provided by the IntelliControl

ICS source modules (iPod, Digital Audio Broadcasting Radio,

AM/FM, etc). IntelliControl ICS Modules. IntelliControl ICS

Modular MultiZone Receiver system settings can be displayed

for configuration of tone controls, clocks, timers and other

system functions.

Three Soft Keys

These 3 buttons located directly under the LCD, provide a wide

range of controls that change with each selected source.

Cursor Navigation Keys

Up, Down, Left, Right and Select buttons allow navigation and

selection of options through menus, lists and guides.

FEATURES AND BENEFITS (CONT’D)

Alphanumeric Keys

Provide direct access tuning, numeric selection of track and alpha

search for media.

Convenient backlighting for all keys

The iRemote is equipped with a motion sensor that illuminates the

keys when it is moved.

Party Mode

Party Mode turns on all your enabled “Party Zones,” with the

push of a button, from anywhere in your home. Press and hold

a Master Key for two seconds to turn on zones enabled for

“Party Mode.”

Source/Zone On Indicator

The Master Key for the source selected illuminates to indicate

source selected and zone on status.

Mute On Indicator

“Zone Muted” will appear in the title bar of the iRemote display

to indicate the selected zone is muted.

Zone Off

Press the OFF key to turn off the zone you’re controlling.

Global Off

Press and hold the OFF key for 2 seconds to turn off all zones

from anywhere in the house.

www.nilesaudio.com

GETTING STARTED

Unpacking the Box (Contents)

■1, iRemote Handheld Remote Control

■1, Nickel Hydride Rechargeable Battery

■1, iRemote Charging Base

■1, 12Volt Power Supply

■10, Master Key Caps

■1, Master Key Label Sheet

■1, User Guide

■1, Quick Install Guide

Unpack the box and check to see that all contents are present.

The battery is shipped with a minimum charge. It is important to

charge the battery overnight to reach maximum charge before

initial use.

GETTING STARTED (CONT’D)

Inserting the Battery

The iRemote uses a nickel metal hydride rechargeable battery

that must be fully charged prior to initial use. Install the battery

and allow it to charge for 12 hours, before initial use.

Figure 2: Installing the iRemote Battery

Charging the iRemote

Your new iRemote comes equipped with a rechargeable battery,

charging base and power supply. After every use, place your

iRemote into the charging base cradle. The charging base’s front

panel light changes from light blue to bright blue when the remote

is seated correctly. When the battery is charging, the LCD dis-

play reads “Charging”, and when charging is complete the dis-

play reads “Charging Complete.” The iRemote operates approxi-

mately 8 hours on a full charge.

www.nilesaudio.com

GETTING STARTED (CONT’D)

Hooking up the Charging Base

1. Unpack the iRemote, Charger Base, battery and power supply.

2. Install battery as shown in Figure 2.

3. Plug the 12V power supply into the iRemote Charger Base and

connect to an unswitched AC outlet.

4. Set the iRemote into the Charger Base and let charge for

12 hours before initial use.

NOTE: This is for the initial charge only. The iRemote will recharge in about

4 hours under normal use.

System (CAT-5)

Connects to IntelliControl ICS Modular

MultiZone Receiver Communication &

Control Switch when used as Master

Charging Base

Power Jack

Figure 3. IntelliControl ICS iRemote Master Charging Base - Rear View

12V DC

Power Supply

MAC ID Sticker

Figure 4. MAC ID Sticker Location - iRemote Base - Bottom View

GETTING STARTED (CONT’D)

Locating the MAC ID

The Media Access Control Address (MAC ID), tells the

IntelliControl ICS Modular MultiZone Receiver which device, in

this case an iRemote, is sending commands. The IntelliControl ICS

Modular MultiZone Receiver then knows which zone to turn on

and which source to select for that zone.
