REPAIR MANUAL
Ｍ
サービス
計画課
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
Caution:
① In disassembly/(re)assembly, be sure to use conductive mat (J5033) and wrist strap (J5033-5), in
order to protect electric parts from static electricity.
② Before disassembling, be sure to remove batteries or AC power cord.
③
their types, etc.
④ .
⑤ is indicated in this manual when NK screw is used. Usually the same "NK" screw can be used
ＮＫ
Points to notice for Disassembly and Assembly
WARNING
covers.
After removing covers, besure to discharge the main
condenser according to the instructions of repair manuals.
Caution:
When "Separation of Front body from Rear body", "Disassembly of CCD/FPC unit" and
"Disassembly of Bayonet" are performed, be sure to carry out "RESETAF-DEFOCUS
COMPENSATION" of the D300 adjustment software after assembly.
・
・ For soldering work, the special solder and soldering iron are required.
・
・ Use the special soldering iron respectively for lead-free solder and lead solder.
They cannot be used in common.
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
#1647
#B60
#B447
#B63
#B61
・
#1642×2 #394
#392
IF lid
・Take out the two screws (#1642).
・Remove the IF lid (#392).
※
Disassembly
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
Bottom cover / Battery lid unit
・ upwards,,
and remove as if pulling it out.
・
screws (#1509).
・Remove the bottom cover.
#1509×2
Battery cover (#B801)
#1571×2
#25
#807
#68
#1519×4
#806
#982
#981
#983
#1550 #1550 #1556 #1556
#1550
#1556 #1556
Bottom cover
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
Rear SW FPC, Retainer plate, and other small parts
427 1632x2
423
424
1K602-799 (5)
1K010-712x2 (10)
1K602-800 (5)
1K683-264 (5)
425
1K360-399 (5)
439
1K602-803 (5)
429
1K233-246 (5)
#987
#923
#443
#923
#921
#1518×2
#442
#B423
#1628×2
#445
CF cover, sponge, other small parts
・Take out the two screws (#1518).
Rear cover unit
・Take out the two screws (#1553), two screws (#1547)
and one screw (#1551).
・Remove the rear cover slowly, and disconnect the three
FPCs from each connector.
#1551
#1547×2 #1553×2
#1020
#456
#B478 #1630
#1512×3
#422
#1625×3
#476
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
429
1K233-246 (5)
430
1K104-016 (5)
#465 #1511×2
#475
#426
#455
#962
#961
#924
#986
#985
#467 #1538×2
#469
#468
#481
#474
Selector button, Sponge, and other small parts
#431
#433
#488
#492
#487
#1627
#489#1629
#1627×2
#484
#1546×2
#491
#1571
#486
#493
#434×2
#435×2
#1057
#432
#1626×3
TFT monitor and other small parts
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
Soldering bridge
#1515
#1515
#1546×4
DG PCB shield plate
・Take out the four screws (#546) and two screws (#1515).
・Remove the two soldering bridges that joint DG-PCB and DG-PCB shield plate.
・Remove the DG-PCB shield plate.
#1510×2
I/F cover
・Take out the two screws (#1510) and remove
the I/F cover (#B28).
・Remove the conduct plate (#695).
#B28
#695
2K 5W
Discharge of Main condenser
DG-PCB shield plateshield plate
WARNING
covers.
After removing covers, besure to discharge the main
condenser according to the instructions of repair manuals.
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
Image sensor holder unit
・Take out the three screws (#1543) and remove the CF base plate (#1018).
・Unsolder the DR base plate (#1014) at four places.
・Take out the three screws (#1639) and remove the
image sensor holder unit (#B10521).
#B10521
#1639×3
#1014
DG-PCB
・Remove the harnesses (#1075, #1074, and #1073) from each connector.
・Disconnect the FPC (#1027#1027､#1040､#1041､#1039､#1038) from each connector.) from each connector.
・Take out the screw (#1546) and remove [#B1017].
#B1017 #1546
#1041
#1075
#1073
#1040
#1039
#1074
#1027
#1038
CF base plate unit
#1543×3
Orange
Gray
Red
Black
DR base plate
#1018
#1038
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
・Remove the dioptor-adjustment knob cover plate (#850), and take out the screw (#1622).
・Remove the dioptor-adjustment knob (#852), drip-proof sponge (#857) and drip-proof collar (#851).
・Raise the built-in speedlight, and take out the two screws (#1548), two screws (#1547), three screws (#1555)
and two screws (#1511).
・Remove the four solders of the DI base plate (#1029).
Top cover unit
Removal of Top cover
Connection-FPC
#1511×2
#1547×2 #1555
#1555
#1555
Raise (pop-up) here.
Dioptor adjustment knob
#851
#857
#852
#1622
#850
Brown
Yellow
Black
Blue
DI base plate
(#1029)
#1548×2
・
from the connector.
INC
- Ｄ ･ -
logo�Q0310�forGraphic
070509�Gdesign�ito
VBA20001-R.3720.A
#1014
#1541×2
#811
#690
#1502
#1537×2
#1502×2
#1541
#1541
#691
#688
#769
#439
#1027
#B687 #15337
DR base plate and other small parts
