Nikon COOLPIX 3700 Instrucciones de funcionamiento

VAA18001-R.3622.A

作成承認印配布許可印

REPAIR MANUAL

NIKON CORPORATION

Tokyo, Japan

Recycled paper

再生紙を使用しています

Printed in Japan Jan 2004

VAA18001-R.3622.A

- E3700 -

CONTENTS

SPECIFICATIONS M1-M2

DISASSEMBLING

WARNING / Front cover, Rear cover D1

Discharge Main Condenser, Battery holder unit, LCD unit D2

CP-1 PCB / TB-1 PCB D3

PW-1 / Battery holder D4

Viewnder unit, Unsolder D5

Guide tube unit, Cam tube unit / 2nd lens group D6

Cam tube, Shutter unit D7

Light-shielding plate / Coupling gear, 1st lens group / Barrier D8

Zoom motor unit / Coupling gear, 3rd lens group / Focus motor unit D9

ASSEMBLY

3rd lens group / Focus motor unit A1

Zoom motor unit, 1st lens group / Barrier unit A2

Barrier unit A3

Light-shielding plate / Coupling gea, Shutter unit A4

Cam tube, Shutter FPC A5

Cam tube unit / 2nd lens group A6

Guide tube unit, Soldering A7

Viewnder unit A8

PW-1 / Battery holder A9

Lens unit / CP-1 PCB / TB-1 PCB A10

Battery holder unit, LCD unit A11

Front cover, Rear cover A12

Ajdjustment A13-A21

ELECTRICITY

Outline of circuit description E1-E7

Overall Wiring E8

Overall Block Diagram E9

ASIC Block Diagram E10

CCD Block Diagram E11

Lens Drive Block Diagram E12

Power Block Diagram E13

System Block Diagram E14

PW1 Circuit Diagram (Strobe Circuit Diagram) E15

INSPECTION STANDARD & TOOL

Inspection Standard R1-R5

Tool List T1-T3

VAA18001-R.3622.A

- M1 ･E3700 -

Type E3500 digital camera

Effective pixels 3.2 mega-pixels

CCD 1/2.7-inch high-density CCD; total pixels: 3.34 mega-pixels

Image size (pixels) 2048×1536 (2048), 1600×1200 (1600), 1024×768 (1024), 640×480 (640)

Lens

Focal distance

Aperture range

Lens construction

3×Zoom Nikkor

f = 5.4 to 16.2mm (35 ~ 105mm by conversion with 35mm-format)

F2.8 ~ F4.9

7 elements in 6 groups

Digital zoom Max. 4.0×

Auto focus (AF) Contrast-detect through-the-lens (TTL) AF

Focus range 30 cm (1 ft.)-∞ at widest angle (W), 60 cm (2 ft.)-∞ at telephoto (T)

(Approx. 4cm (Wide position in zooming) ~ ∞ in Macro mode)

AF area Automatic 5-area multi AF; manual selection available

Finder Real image type zoom nder, eld of viewnder: Approx. 80%

Monitor 1.5-inch 134,000-dot, High transmissive advanced TFT LCD monitor with 5

level brightness adjustment

Storage

Media

File system

File format

SD (Secure Digital) memory cards

Compliant with Design rule for Camera File systems (DCF), Exif 2.2, Digital

Print-Order Format (DPOF)

Compressed: JPEG-baseline-compliant

Movies: QuickTime

Exposure

Metering

Exposure control

256-segment multi-metering, AF metering point (5 points)

Programmed auto, exposure compensation (–2.0 ~ +2.0 EV in steps of 1/3 EV)

Range

(ISO equivalent)

W: EV 1.0 to 17.1

T: EV 2.6 to 18.6

Shutter Mechanical and charge-coupled electronic shutter

Shutter Speed 4-1/3000 sec.

Aperture

Range

Electronically controlled preset aperture

Two steps (f/2.8 and f/4.7 [W])

Sensitivity Approximately equivalent to ISO50 (auto gain to ISO 200 equivalent)

Self-timer 10- or 3-second duration; sound release

Built-in Speedlight

Range

Flash control

0.4-3.0 m/ 1'4" - 9'10" (W) 0.4-1.7m / 1'4" -5'7" (T)

Sensor ash system

Specications

VAA18001-R.3622.A

- M2 ･E3700 -

Interface USB

Video output Can be selected from NTSC and PAL

I/O terminals DC input terminal, audio/video (A/V) out with digital I/O

Power sources One rechargeable Nikon EN-EL5 lithium-ion battery (supplied)

One CP1 lithium battery

EH-62A AC adapter

Approximate battery life 200 shots (EN-EL5)/250 shots (CP1)

Measured at standard temperature (20°C/68°F) with fully-charged batteries

under standard Nikon test conditions: zoom adjusted with each shot, flash

used with every other shot, image mode set to Normal.

Dimensions

(W×H×D)

95.5×50×31mm

Weight Approximately 130 g without battery and memory card

Operating environment

Temperature

Humidity

0 - 40°C (32 – 104°F)

Under 85% (no condensation)

VAA18001-R.3622.A

- D1 ･E3700 -

DISASSEMBLY　

Front cover, Rear cover

Note: ① Be sure to remove the SD memory card and batteries before disassembly.

② When disassembling, make sure to memorize the processing state of wires, screws to be xed

and their types, etc.

③ Because electrical parts are easily damaged by static electricity, make sure that you are well

earthed/grounded.

・ Take out 2 screws ( ①: M1.4×3).

・ Take out 3 screws ( ②: M1.7×4).

・ Take out 2 screws ( ③: M1.7×2.5).

・ Take out 1 screws ( ④: M1.7×3.5).

・ While pushing in the direciton of (↓), open the rear cover ( ⑤) to remove the connector ( ⑥).

・ Remove the front cover ( ⑦).

　Points to notice for Lead-free solder products

　・Lead-free solder is used for this product.

　・For soldering work, the special solder and soldering iron are required.

　・Do NOT mix up lead-free solder with traditional solder.

　・Use the special soldering iron respectively for lead-free solder and lead solder. They cannot be used in

common.

！

内部に高電圧部あり。カバーを外す時は感電に注意すること。

カバーを外した後は、修理指針の指示に従ってメインコンデン

サーの放電を必ず行うこと。

警告

①

②

④

③

⑤

⑥

③

⑦

WARNING

Due to an internal high voltage area, take extra care not to get an

electric shock when detaching the covers.

After removing the covers, be sure to discharge the main condenser

according to the instructions of the repair manuals.

VAA18001-R.3622.A

- D2 ･E3700 -

Discharge Main Condenser

Battery holder unit, LCD unit

！

内部に高電圧部あり。カバーを外す時は感電に注意すること。

カバーを外した後は、修理指針の指示に従ってメインコンデン

サーの放電を必ず行うこと。

警告

2 K Ω / 5 W

メイン

コンデンサ

・Remove 2 connectors ( ①).

・Remove LCD ( ②).

・Take out 1 screw ( ③: M1.7×2.5).

・Take out 1 screw ( ④: M1.7×4).

・Take out 1 screw ( ⑤: M1.7×3.5).

・Remove the LCD holder ( ⑥).

・Open the battery cover ( ⑦).

・Unhook the claws indicated by (↓) arrows, and remove the battery front ( ⑧).

①

②

④

③

⑤

⑥

⑦

⑧

WARNING

Due to an internal high voltage area, take extra care not to get an elec-

tric shock when detaching the covers.

After removing the covers, be sure to discharge the main condenser

according to the instructions of the repair manuals.

Main condenser

VAA18001-R.3622.A

- D3 ･E3700 -

CP-1 PCB / TB-1 PCB

・Take out 1 screw ( ①: M1.7×2.5).

・Take out 1 screw ( ②: M1.7×4).

・Remove the holder PW-1/CP-A ( ③).

・Remove the connector ( ④).

・Remove the connector ( ⑤).

・Remove 2 connectors ( ⑥).

・Take out 1 screw ( ⑦: M1.7×3.5).

・Take out 2 screws ( ⑧: M1.4×3.5).

・Remove the CP-1 PCB ( ⑨).

・Take out 1 scrw ( ⑩: M1.7×2.5).

・Remove the lens holder ( ⑪).

・Take out 1 screw ( ⑫: M1.7×3).

・Take out 1 screw ( ⑬: M1.4×3.5).

・Remove the connector ( ⑭).

・Remove the LED holder ( ⑮).

・Remove the TB1 PCB ( ⑯).

・Take out 2 screws ( ⑰: M1.7×4).

・Remove the lens unit ( ⑱).

Microphone

Speaker

①②

③

④

⑥

⑦

⑨

⑤

⑧

⑪

⑮

⑯

⑫

⑭

⑰

⑩

⑬

⑱

VAA18001-R.3622.A

- D4 ･E3700 -

PW-1 / Battery holder

・Take out 1 screw ( ①: M1.7×3).

・Take out 1 screw ( ②: M1.7×4).

・Remove the card holder ( ③).

・Remove the holder PW-1/rear cover ( ④).

・Take out 2 screws ( ⑤: M1.7×2.5).

・Take out 1 screw ( ⑥: M1.7×4).

・Take out 1 screw ( ⑦: M1.7×4.5).

・Remove the holder CP-A/CP-B ( ⑧).

・Remove the trigger cover ( ⑨).

・Remove 3 solders ( ⑩).

・Remove the battery back holder ( ⑪).

・Remove the PW-1 PCB ( ⑫).

①

②

③

④

⑦

⑨

⑧

⑪

⑩

⑫

⑥

⑤

VAA18001-R.3622.A

- D5 ･E3700 -

Viewnder unit

#194-35014×3

Viewnder unit

#194-25014×2

#CD106NA-0042A

#194-25014

Solder

Shutter FPC

Main FPC

Unsolder

VAA18001-R.3622.A

- D6 ･E3700 -

Guide tube unit

#194-35014×4

Master frame unit

Cam tube unit

2nd lens group

Cam tube unit / 2nd lens group

Shutter FPC

Guide tube
