SpoTel: SpoATA series FXO/FXS Voice Gateway

User Manual

Table of Contents

1.!Equipment Introduction!.....................................................................................!1!

1.1 Overview!.......................................................................................................!1!

1.2 Equipment appearance (back view)!.........................................................!1!

1.3 Power supply!................................................................................................!2!

1.4Network Applications!....................................................................................!2!

1.5 Functions and Features!..............................................................................!3!

1.5.1Protocol standard supported!............................................................!3!

1.5.2 Voice and Fax parameters!..............................................................!3!

1.5.3 Supplementary service!....................................................................!3!

2.!Basic Operations!.................................................................................................!4!

2.1 Phone Call!.....................................................................................................!4!

2.1.1 Phone or Extension Number!...........................................................!4!

2.1.2 Direct IP Calls (SPOATA-8S FXS gateway)!...................................!4!

2.2 Call Features!.................................................................................................!5!

2.3 Sending and Receiving Fax!........................................................................!6!

2.3.1 SpoATA-8S supports four fax modes:!...........................................!6!

2.3.2 T. 38 and Pass-Through!..................................................................!6!

3.!Local IVR Operation!............................................................................................!7!

3.1 Inquire IP address!.......................................................................................!7!

3.2 Factory Reset!...............................................................................................!7!

3.3 Configure LAN Port’s IP Address!...............................................................!7!

4.!WEB Configuration (all SpoATA series)!...........................................................!8!

4.1 WEB Login!....................................................................................................!8!

4.1.1 Login!..................................................................................................!8!

4.1.2 Login WEB!.........................................................................................!9!

4.2 Configuration menu!...................................................................................!10!

4.3 Status and Statistics!..................................................................................!11!

4.3.1 System Information!.......................................................................!11!

4.3.2 Registration Information!...............................................................!12!

4.3.3 TCP/UDP Statistics!.........................................................................!12!

4.3.4 RTP Session Statistics!....................................................................!12!

4.4 Quick Setup Wizard!...................................................................................!13!

4.5 Network Configuration!..............................................................................!13!

4.5.1 Local Network!.................................................................................!13!

4.5.2 VLAN Parameter!.............................................................................!14!

4.5.3 ARP!...................................................................................................!16!

4.6 SIP Server!...................................................................................................!16!

4.7 Port Configuration!.....................................................................................!18!

4.8 Advanced!....................................................................................................!20!

4.8.1 FXO parameters!..............................................................................!20!

4.8.2 Media Parameter!............................................................................!22!

4.8.3 SIP Parameter!.................................................................................!24!

4.8.5 Digit Map!.........................................................................................!28!

4.8.6 Feature Codec!.................................................................................!29!

4.8.7 System Parameter!..........................................................................!31!

4.9 Call & Routing!............................................................................................!33!

4.9.1 Port Group!.......................................................................................!33!

4.9.2 IP Trunk!...........................................................................................!35!

4.9.3 Routing Configuration!....................................................................!35!

4.9.4 IP-Tel Routing!.................................................................................!36!

4.9.5 Tel-IP/Tel Routing!..........................................................................!37!

4.10 Manipulation Configuration!....................................................................!38!

4.10.1 IP-Tel Caller!..................................................................................!38!

4.10.2 Tel-IP Caller!..................................................................................!39!

4.10.3 Tel-IP Caller!..................................................................................!40!

4.11 Maintenance!.............................................................................................!40!

4.11.1 syslog Parameter!..........................................................................!40!

4.11.2 Firmware Upload!..........................................................................!41!

4.11.3 Data Backup!..................................................................................!41!

4.11.4 Data Restore!.................................................................................!42!

4.11.5 Ping Test!.......................................................................................!42!

4.11.6 Tracert Test!..................................................................................!43!

4.11.7 Password Modification!.................................................................!44!

4.11.8 Factory Reset!................................................................................!44!

4.11.9 Device Restart!..............................................................................!45!

5.!Glossary!..............................................................................................................!45!

6.!Configuration Examples!...................................................................................!46!

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

1. Equipment Introduction

1.1 Overview

SpoATA FXO or FXS analog phone adapter (ATA)/gateway provides low cost, simple

operation VoIP solutions for enterprise, the family office (SOHO), remote office and branch

enterprise. ATA connects to analog telephone, fax and traditional analog PBX with

standard voice interfaces and provided high quality voice service. SPOSpoATA series VoIP

access gateway adopts standard SIP protocol and is compatible with leading IP PBX (such

as Asterisk, 3CS), soft-switch and SIP-based platform. SPOSpoATA series analog gateway

includes following model:

!SpoATA-8S (with 8x FXS ports)

!SpoATA-8O (with 8x FXO ports)

!SpoATA-4O (with 8x FXO ports)

This manual is using SptATA-8O as an example, introducing the function of devices and

parameter configuration.

1.2 Equipment appearance (back view)

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

1.3 Power supply

SPOATA-4/8O is desktop equipment and powered by an 12DC power adapter which works

between AC 110-240 V

Power adapter specs:

Input: 100-240V, 50-60Hz

Output: 12VDC

1.4Network Applications

Figure 4-1：Network Applications

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

1.5 Functions and Features

1.5.1Protocol standard supported

• SIP V2.0 (RFC 3261,3262,3264)

• SDP (RFC 2327)

• REFER (RFC 3515)

• RTP/RTCP (RFC 1889,1890)

• STUN (RFC 3489)

• ARP/RARP (RFC 826/903)

• SNTP (RFC 2030)

• DHCP/PPPoE

• TFTP/HTTP/HTTPS

• DNS/DNS SRV (RFC 1706/RFC 2782)

• VLAN 802.1P/802.1Q

• Diff Server

1.5.2 Voice and Fax parameters

• G.711A/U law, G.723.1, G.729AB

• Comfortable Noise Generation (CNG)

• Voice Activity Detection (VAD)

• Echo Cancellation (G.168)

• Adaptive Dynamic Jitter Buffer

• Voice and fax gain control

• Hook flash

• Modem

• T.38/Pass-through

• DTMF Mode: Signal/RFC2833/INBAND

1.5.3 Supplementary service

• Busy tone detection

• No current take out stitches detection

• Voice interrupted detection

• One stage dialing

• Two stage dialing

• PSTN exterior ports polling

• Polarity Reversal

• FAS（Fake billing correction ）

• DC/AC impedance config

• Calls detection (Bellcore Type 1&2, ETSI,DTMF)

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

• Voice mail

• Direct IP Call

• IP Trunk

2. Basic Operations

2.1 Phone Call

2.1.1 Phone or Extension Number

1）FXO Call Out

• One stage dialing: After receiving dialing number from softswitch/IPPBX, the

number will be called out via FXO ports that is configured under “Port select”.

• Two stage dialing: the call arrives the gateway from SIP connection: the caller

will hear 2nd dial tone and could then dial outside number.

2）Dial the number directly and press #.

• Dial outside number with FXO: when the message “please dial the extension

number” or second dial tone is played, enter the dialing number. The gateway

will then send the number to SIP server/connection, such as soft switch or

IPPBX.

• Off-hook auto-dial: (calling via FXO): the gateway will automatically connect to

the preset extension or ring group number according to the default hotline

number.

2.1.2 Direct IP Calls (SPOATA-8S FXS gateway)

SpoATA-8S allows direct call through IP address. A point-to-point call could be dialed

without registration.

Elements necessary to configure a direct IP call：

1) Both SpoATA-8S or other ATA, are on public IP addresses;

2) Both SpoATA-8S and other ATA are on the same LAN on private IP addresses;

3) Both SpoATA-8S and other ATA could be connected through a router using public or

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

private IP addresses (with necessary port forwarding or DMZ).

Operation Process

1）Pick up the analog phone then dial “ *47 ”

2）Enter the target IP address.

【Note】：No dial tone will be played between step 1 and step 2

Examples:

If the target IP address is 192.168.0.160, the dialing convention is *47, then

192*168*0*160. Followed by pressing the “#” key or waiting another 3 seconds, the

remote unit will ring.

【Note】：Th direct IP calls could not be made from one port to another port within the

same gateway since both ports are using the same IP. Only the standard SIP port 5060

could be used in the direct ip dialing.

2.2 Call Features

SpoATA-8S supports all traditional and advanced phone functions.

Table 2.2-1 Feature Codec

Feature Codec

Operation Instructions

*158#

Inquire the LAN port IP address

*159#

Inquire the WAN port IP address

*114#

Inquire port account

*150*

Set how IP address would be obtained

*157*

Set network mode

*152*

Set IP address

*153*

Set Subnet mask

*156*

Set default gateway IP address

*193#

Obtain IP address through DHCP

*160*1#

Open WAN port to access web

*166*000000#

Factory reset

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

*111#

Restart device

Call hold

*47*

IP address call

*51#

Enable call waiting

*50#

Disable call waiting

*87*

Blind transfer

*72*

Enable Unconditional Call Forward

*73#

Disable Unconditional Call Forward

*90*

Enable Busy Call Forward

*91#

Disable Busy Call Forward

*92*

Enable No Answer Call Forward

*93#

Disable No Answer Call Forward

*78#

Enable DND

*79#

Disable DND

*200#

Access Voice mail

Flash/Hook

Switch between incoming calls, If not in session, flash/hook will switch a

new channel for new call.

2.3 Sending and Receiving Fax

2.3.1 SpoATA-8S supports four fax modes:

1）T.38（FoIP）

2）Pass-Through

3）Modem

4）adaptive

2.3.2 T. 38 and Pass-Through

T.38 is the preferred method because it is more reliable and works well in most network

! ! ! SpoTel!Series!Voice!Gateway:>!User!Manual!

conditions. If the service provider supports T.38, please use this method by selecting T.38

as fax mode (default). If the service provider does not support T.38, pass-through mode

could be used. If there is problem sending or receiving Fax, toggle the Fax Tone Detection

Mode setting.

3. Local IVR Operation

3.1 Inquire IP address

After attaching an to a FXS ports, feature code could be dialed to inspect the current ip

status.

: dialing *158# to inquire LAN IP address

: dialing *159# to inquire WAN IP address.

3.2 Factory Reset

Dial *166*000000#, then hang up. The gateway will then reboot.

3.3 Configure LAN Port’s IP Address

Before configuration, please ensure:（1）The device is power on; （2）device is connected

to the network;（3）Telephone is attached to FXS port.

1) Configure dynamic IP address by DHCP：

Off-hook; Dial “*150*2#”; On-hook/hang up;

After 10 seconds, the device will reboot.

2) Configure Static IP address

Off-hook; Dial “*150*1#”; On-hook;

Then configure IP and mask as follow:

• Configure IP address：

Off-hook; input “*152*172*16*0*100# ”; On-hook

• Configure subnet mask：

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Puerta de Nicherons

Nicherons

Nicherons Series SpoLink Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
