Nexxt Solutions - NexxtGate Wireless Access Point
2
Copyright Statement
Nexxt Solutions™ is a registered trademark. Other trademarks or brand names contained
herein are the trademarks or registered brand names of their respective owners. Copyright
of the whole product as integration, including its accessories and software, belongs to Nexxt
Solutions Ltd. No individual or third party is allowed to copy, plagiarize, reproduce, or translate
it into other languages, without express consent from Nexxt Solutions, Ltd. All of the photos
and product specifications mentioned in this manual are used as reference only. Upgrades of
software and hardware may occur, and should there be any changes, Nexxt Solutions shall not
be responsible for notifying about any such modifications in advance. If you would like to know
more about our products, please visit our website at www.NexxtSolutions.com.
Nexxt Solutions - NexxtGate Wireless Access Point
3
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s authority
to operate the equipment.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be co-located or operating in conjunction
with any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only
Mobile Configurations. The antennas used for this transmitter must be installed to provide
a separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter.”
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause
undesired operation.
1.
2.
FCC STATEMENT
FCC RF Radiation Exposure Statement
•
•
•
•
Nexxt Solutions - NexxtGate Wireless Access Point
4
CONTENTS
Product overview
Features
LED definition
Rear panel layout and connectos
System requirements
Environment requirements
Connecting the device
Checking the LEDs
Initial configuration
Quick setup wizard
Login
Status
Quick setup
Operation mode
Network
LAN
WAN
MAC clone
Wireless
Basic settings
Wireless mode
Security settings
MAC filtering
Wireless statistics
Distance setting
Antenna alignment
Throughput monitor
DHCP
DHCP settings
DHCP clients list
Address reservation
Wireless settings
Forwarding
Virtual servers
Port triggering
DMZ
UPnP
Security
Firewall
IP address filtering
Domain filtering
1.1
1.2
2.1
2.2
2.3
2.4
2.5
3.1
3.2
3.3
4.1
4.2
4.3
4.4
4.5
4.5.1
4.5.2
4.5.3
4.6
4.6.1
4.6.2
4.6.3
4.6.4
4.6.5
4.6.6
4.6.7
4.6.8
4.7
4.7.1
4.7.2
4.7.3
4.8
4.9
4.9.1
4.9.2
4.9.3
4.9.4
4.10
4.10.1
4.10.2
4.10.3
Chapter 1
Introduction
Chapter 2
Device layout
Chapter 3
Quick installation guide
Chapter 4
AP Client Router & AP Router Operation Mode
Nexxt Solutions - NexxtGate Wireless Access Point
5
Package Contents
Appendix A: FAQ
Appendix B: Configuring the PC
Appendix C: Specifications
Appendix D: Glossary
4.10.4
4.10.5
4.10.6
4.11
4.12
4.12.1
4.12.2
4.13
4.13.1
4.13.2
4.13.3
4.14
4.14.1
4.14.2
4.15
4.15.1
4.15.2
4.15.3
4.15.4
4.15.5
4.15.6
4.15.7
4.15.8
4.15.9
4.15.10
MAC address filtering
Remote management
Advanced security
Static routing
IP & MAC binding
Binding setting
ARP list
Dynamic DNS
Dyndns.org DDNS
Oray.net DDNS
Comexe.cn DDNS
SNMP
Community setting
SNMP system setting
System tools
Time
Firmware
Factory defaults
Backup & restore
Ping Watch Dog
Speed test
Reboot
Password
Syslog
Statistics
Upon opening the box, make sure that the following items are included:
High Power Wireless Access Point
Power adapter
PSE module
Mounting kit
Quick installation guide
Resource CD
Note:
If any of the listed items is missing, mismatched, damaged or broken, contact your local dealer
immediately for replacement.
•
•
•
•
•
•
Nexxt Solutions - NexxtGate Wireless Access Point
6
1.2 Features
1.1 Product overview
Chapter 1
Introduction
Thank you for purchasing the AELPLDR4U1 High Power Wireless Outdoor Access Point from
Nexxt Solutions.
The 2.4 GHz High Power Wireless Outdoor Access Point is a dedicated Wireless Internet
Service Provider Customer-Premises Equipment (WISP CPE) device, providing the functions of
a Wireless Access Point (WAP), WISP Client, and a high-gain antenna in one weatherproof de-
vice designed for outdoor use. The high power design extends transmission range and delivers
a more reliable wireless connection. Equipped with a Power over Ethernet Port known as PoE,
this device can be installed in locations where AC power is not readily available. It also features
a web-based management utility for easy configuration and hassle-free network connection.
Convenient power, LAN and signal strength LED indicators allow users to monitor the status of
the network.
Three operation modes are provided in the access point to meet each user’s needs.
AP Client Router: choose this mode to enable users to share the internet as a WISP client
router.
AP Router: choose this mode to enable users to share internet via ADSL/Cable modem,
in a wireless broadband router configuration.
AP: choose this mode to enable wireless devices to access a network using, in an access
point configuration.
Complies with IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u standards.
Wireless Data transfer rates up to 54Mbps.
The access point serves as the connection point between wireless and wired networks or
as the center point of a stand-alone wireless network.
High output power for extended range and reliability
12 dBi, dual-polarized antenna easily builds up to 9.3-mile wireless.
Strong 24 dBm output power rating.
Easy to set up and manage with PPoE option. Ping Watch Dog feature automatically reboots
device when necessary
Controlled access and WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption methods ensure
data integrity and privacy.
3 year full warranty, with a 2 year extension with online registration
Supports AP Client Router, AP Router and AP operation mode.
Supports Client Router Mode for WISP CPE
Supports passive power over Ethernet.
Supports Wireless Distribution System (WDS).
Up to 50Km.
Supports Antenna Alignment.
Throughput monitor detailed information about the current wireless data throughput.
Supports Layer 2 User Isolation.
Supports Ping Watch Dog.
Supports link speed test.
Supports Remote Management
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Nexxt Solutions - NexxtGate Wireless Access Point
7
Output transmit power adjustable.
Supports PPPoE, Dynamic IP, Static IP Internet Access.
Built-in NAT and DHCP server supporting static IP address distributing.
Supports UPnP, Dynamic DNS, Static Routing, VPN Pass-through.
Supports Virtual Server, Special Application and DMZ host.
Built-in firewall supporting IP address filtering, Domain Name filtering, and MAC
address filtering.
Provides WLAN ACL (Access Control List).
Supports configuration backup/restore and firmware upgrade.
Supports Web management.
•
•
•
•
•
•
•
•
Nexxt Solutions - NexxtGate Wireless Access Point
8
2.1 LED
Chapter 2
Device layout
The AELPLDR4U1 access point features LED indicators, designed to display the connection
status and the strength of the wireless signal.
Figure 2-1 Front Panel sketch
Table 2-1
Note:
Wireless Signal Strength Indicators:
In AP or Bridge mode, all the four LEDs will light up.
In Client or Repeater mode, the corresponding LED(s) will light up when the RSSI value
(wireless signal strength value) reaches the RSSI threshold. The value of RSSI threshold
can be set on the Wireless Advanced Settings page, as shown in Figure 4-26.
For example, if the RSSI value you set is 30, while RSSI threshold of the four LEDs are 15,
25, 35, 45 respectively, then the LEDs having RSSI thresholds of 15 and 25 will light up.
Wireless Signal StrengthPower LAN
Name
Power
LAN
Status Indication
Wireless
Signal
Strength
Off No power
On Power on
Off There is no remote wireless signal Client or
Repeater mode
On Indicates the wireless signal strength
of a remote AP
Off There is no device linked to the corresponding port
There is an active device linked to the corresponding port
On
Blinking
There is a device linked to the corresponding port but
no activity is being detected
•
•
Nexxt Solutions - NexxtGate Wireless Access Point
9
2.3 System requirements
2.4 Environment requirements
2.2 Rear panel layout and connectors
Each PC in the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45
connectors
TCP/IP protocol must be installed on each PC
Web browser, such as Microsoft Internet Explorer 5.0 or later, Netscape Navigator 6.0
or later
If the device is configured in the AP client router mode, you will also need:
Wireless Internet Access Service (WISP).
If the device is configured in the AP router mode, you will also need:
Broadband Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable Modem that has an RJ45 connector (you do not need it if you connect the
router to the Ethernet)
Operating temperature: -30ºC~70ºC
Operating Humidity: 10%~90% RH, non-condensing
Figure 2-2 Rear panel sketch
Ground
RESET button: use it to reset device to its factory default values
LAN: this port is used to connect to the PoE port of the PSE (Power Sourcing Equipment)
module.
: antenna jack to connect an additional high-power external antenna. Since the unit comes
with a built in antenna, usually it is not required to connect another one outside.
•
•
•
•
•
•
•
•
•
•
•
Nexxt Solutions - NexxtGate Wireless Access Point
10
2.5 Connecting the device
Make sure you are provided with wireless Internet service by your WISP (Wireless Internet
Service Provider).
Locate an optimum location for the AP. Try to place your AP in an appropriate position where
it can well receive the signal from WISP.
Connect the AP to the desktop PC.
Adjust the direction of the AP to get the best signal.
Power on the AP before configuring the AP on the web-based page on your computer.
1.
2.
3.
4.
5.
To establish an infrastructure network in AP Client Router mode as Figure 2-3, please take the
following steps:
Figure 2-3
