Nextar X3-Elite Instrucciones de montaje

POWER SUPPLY:

Connect the supplied adaptor to the side of the unit in the slot marked “DC 5V IN”. Plug

the two-prong end of the power cord to anAC100-240V outlet. If you have difficulty

inserting the plug, turn it over and reinsert it. If the unit will not be used for a long time,

disconnect the plug from the outlet.

NOTE:

Before plugging the power cord into an AC outlet, make sure that all the connections

have been made.

CAUTION: These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so.

Refer to service manual for servicing instructions. To reduce the risk of fire or electric

shock, do not expose this apparatus to rain or moisture.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric to

ersons.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance (servicing)

instructions in the literature accom

the a

liance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.

Important

ety

Instructions

NOTES

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a damp cloth.

7) Do not block any of the ventilation openings. Install in accordance with the

manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide blade or the third prong is

provided for your safety. When the provided plug does not fit into your outlet,

consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of

time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or has

been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with

liquids, such as vases, shall be placed on the apparatus.

Important

ety

Instructions

Warning

Failure to avoid the following potentially hazardous situations may result in injury or

property damage.

The unit is designed to provide you with route suggestions. It does not reflect road

closures or road conditions, traffic congestion, weather conditions, or other factors that

may affect safety or timing while driving.

Use the unit only as a navigational aid. Do not attempt to use the unit for any purpose

requiring precise measurement of direction, distance, location, or topography. This

product should not be used to determine ground proximity for aircraft navigation.

CAUTION:

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type.

The batteries (or batteries installed) shall not be exposed to excessive heat such as

sunshine, fire or the like.

Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the

Global Positioning System (“GPS”) hardware, operating software or other aspects of this

product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s

Standard(s) for Safety [Note-Consider referencing specific UL standard].

UL Certification does not cover the performance or reliability of the GPS hardware and

GPS operating software.

UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS

RELATED FUNCTIONS OF THIS PRODUCT.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

Important

ety

Instructions

Note: This equipment has been tested and found to comply with limits for Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and the receiver. Connect the

equipment into an outlet on a circuit different from that to which the receiver is

connected.

3. Consult the dealer or an experience radio/TV technician for help.

The images in this manual are only for reference and they may appear

different from the actual items.

Important

ety

Instructions

Accessories List

ITEM NAME QTY

Instruction Manual 2

AC Adaptor 1

Car Adaptor 1

USB Cable 1

Mount Bracket 1

Mount Cradle 1

Dashboard Mount Disk 1

Stylus 1

SD Card 1

Pouch 1

NOTE

Accessories and their part number are subject to modification without prior notice due to

improvements.

Accessories

Contents

…………………………………..………..1

……………………………….…………...5

……………………………….…………...7

……………………………….……….…..8

…………………………….……….….….9

……………………………….…………..11

…………………………….……………..15

……………………………….…………..17

……………………………….…………..19

……………………………….…………..20

……………………………….…………..22

Important Safety Instructions

System Connections

Power Supply Preparation

Troubleshooting

Specifications

Accessories

iew of Main Uni

Use of the Mount Accessories

Playing Music

Photo Viewer

General Setup

1. LCD Screen

2. POWER Button

Press to enter or exit the standby

mode.

3. Card Slot

Insert the SD card into the slot.

4. Earphone Jack

5. DC 5V Input Jack

Used to connect to the supplied

adaptor.

6. USB Port

7. RESET Button

Press to reset the system.

View of Main Unit

 Always ensure that the unit and any other external device connected to the unit are

switched off and unplugged from the power supply before you attempt to connect

the unit to any external device.

Inserting SD Card

The unit is designed with SD Card slot that allows you to insert the SD card into the unit

as shown below:

Note: A SD card with map data is included in the package. Do not use the supplied SD

card for storing your own files, for any attempt to access the supplied SD card may result

in the map data missing and lost.

Connecting to Earphones

Connect the earphones to the right side of the unit for private listening.

When earphone is connected, the speakers will automatically turn off.

Note: Excessively loud volume could damage your hearing. So turn down the volume

before you connect the earphones, and then raise the volume to comfortable level.

System Connections

Using the AC Adaptor

The unit is supplied with an AC adaptor for powering it and charging the battery.

Note

 Turn unit's power off before unplugging.

 When using the adaptor, the LCD screen will be brighter than with the

rechargeable battery.

Using the Car Adaptor

The unit is supplied with a Car Adaptor for powering it while in a vehicle.

Attention

 Place the unit in a proper position for viewing.

 Disconnect the unit from the car adaptor when starting the vehicle.

Your portable GPS comes with a built-in rechargeable battery. Please see details in the

following segment.

Connect the car adaptor power plug to

the unit’s power jack and plug the other

end to the vehicle’s 5V accessory/

cigarette socket, as shown on the right

figure.

1. Connect AC adaptor to the right

side of the unit in the jack marked

DC 5V IN, as shown on the right.

2. Plug the two-prong end of the

power cord into a grounded

electrical outlet.

Power Supply

Pre

aration
