Newtons4th PPA55 Series Guía del usuario

PPA5500

and all rights are reserved. No part may be copied or

reproduced in any form without prior written consent.

Document Title: PPA55xx Start Up Guide v4.0

Document Release Date: 04th March 2021

PPA55xx Firmware version on release date: v2.185

Document Ref: D000228 issue 04

Start Up Guide

PPA55xx Quick User Guide

Page 1

CONTENTS

Contents

......................................................................

Page.1

Getting Started................................................

Page.3

1.1

Unpacking and Contents....................................

Page.3

1.2

Handle Fitment.................................................

Pages.4-5

Safety.............................................................

Page.6

2.1

Safety Instructions...........................................

Page.6

2.2

Cautions.........................................................

Page.7

2.3

Warranty.........................................................

Page.8

Front Panel Layout Diagram...............................

Page.9

3.1

Front Panel Display Key Functions......................

Pages.10-29

Rear Panel Layout Diagram................................

Page.30

Basic Key Operation..........................................

Page.31

5.1

Set up to start.................................................

Page.31

5.2

Setting the Time..............................................

Page.31

5.3

Setting the Date..............................................

Page.32

5.4

Adjusting the Screen Brightness........................

Page.32

5.5

Adjusting Keyboard Beep..................................

Page.32

5.6

Setting User Data............................................

Page.33

Quick User Guide.............................................

Page.34

6.1

Wiring............................................................

Pages.34-37

6.2

Start Up.........................................................

Page.38

6.3

6.3.1

6.4

6.4.1

Zoom Functions...............................................

Analogue Output..............................................

Speed & Smoothing..........................................

Efficiency........................................................

Pages.39-40

Pages.41-44

Pages.45-47

Page.48

6.5

Application Modes............................................

Page.49

6.5.1

PWM Motor Drive Mode.....................................

Pages.50-56

6.5.2

6.5.3

6.5.4

6.5.5

6.5.6

6.5.7

6.5.8

6.5.9

6.5.10

6.5.11

6.5.12

Lighting Ballast Mode........................................

Inrush Current Mode........................................

Transformer Mode............................................

Standby Power Mode........................................

Calibration Mode..............................................

Oscilloscope Mode / Capture (RAW Data) Mode....

Harmonics / Flicker Mode..................................

Aircraft TVF105 Mode.......................................

Extended Frequency Range 417 Harmonics……….

Interharmonic Sweeps…………………………………………

HF Current Shunts...........................................

Page.57

Pages.58-64

Pages.65-70

Pages.71-73

Page.74

Pages.75-84

Page.85

Pages.86-92

Pages.93

Pages 94-99

Pages.100-105

6.5.13

LEM6 3-6 Channel Interface………………………………….

Pages.106-109

PPA55xx Quick User Guide

Page 2

7.1

7.1.1

7.2

Remote Settings..............................................

Transferring Internal Datalogs to USB Memory Stick

Data Logging to USB Memory Stick....................

Program Store / Recall / Delete.........................

Pages.110-112

Pages.113-114

Pages.115-116

Pages.117-120

8.1

10.

Repair / Recalibration.......................................

Basic Functionality Check..................................

Specifications..................................................

PPA Comparison Table......................................

Page.121

Pages.122-138

Pages.139-142

Page.143

PPA55xx Quick User Guide

Page 3

1 Getting Started

1.1 Unpacking

Remove the instrument and accessories from the packaging and check them

against the supplied packing list. Please contact your N4L office or local sales

distributor should any items found to be missing or damaged during

transportation.

Please retain the original packaging to ensure easy and safe return of the

equipment for calibration etc.

If rack mounting brackets have been fitted to the equipment, please remove

them before packaging the equipment for return. This reduces the risk of

damage to the equipment during transportation.

PPA55xx Quick User Guide

Page 4

1.2 Fitment of the PPA series Carry/Tilt handle

PPA5/15/45/55 series power analyzers are supplied with a Carry/Tilt Handle that

is located within the accessory pack..............................................................

The handle allows a user to position the instrument upwards at one of two angles

for easier viewing when the instrument is positioned below the line of sight. The

design also allows storage under the unit without obstruction of the rubber feet

so that instruments can be stacked and is easily removed to allow the connection

of rack mounting brackets without the need to remove instrument covers.

Correct installation of the handle is important to ensure the correct operation

and long life the handle.

The following pictures illustrate correct and incorrect handle fitment:

Correct 1 Correct 2

Correct 1/2 –Correct fitting is from the top of the unit as shown here

PPA55xx Quick User Guide

Page 5

Correct 3 Correct 4

A correctly fitted handle will have the ‘N4L Newtons4th’ wording in the correct

reading plane when the handle is to the front of the instrument (Pic. 3)

Also, a correctly fitted handle will allow storage under the unit (Pic. 4)

Incorrect 1 Incorrect 2

Fitting the handle from the bottom of the unit as shown here is wrong...

(Incorrect 1)

Incorrect fitting can be seen because the handle does not fit correctly under the

unit and handle sides do not fit flush with the registration washer (Incorrect 2)

PPA55xx Quick User Guide

Page 6

2 Safety

2.1 IMPORTANT SAFETY INSTRUCTIONS

This equipment is designed to comply with BSEN 61010-1 (2001) (Safety

requirements for electrical equipment for measurement, control, and laboratory

use) –observe the following precautions:

Ensure that the supply voltage agrees with the rating of the instrument

printed on the back panel before connecting the mains cord to the supply

This appliance must be earthed. Ensure that the instrument is powered from

a properly grounded supply

The inputs are rated at 1kV rms or dc cat II; 600V rms or dc cat III. Do not

exceed the rated input

Keep the ventilation holes on the underneath and rear free from obstruction

There are no user serviceable parts inside the instrument –do not attempt to

open the instrument, refer service to the manufacturer or his appointed agent

Input Connections:

It is critical that the 4mm inputs and BNC inputs on each PPA input

channel are not connected to any external circuit at the same time.

You MUST only use EITHER the 4mm OR the BNC connection –NOT both,

this applies to both Voltage and Current inputs.

Note: Newtons4th Ltd shall not be liable for any consequential damages,

losses, costs or expenses arising from the use or misuse of this product

however caused

PPA55xx Quick User Guide

Page 7

2.2 CAUTIONS

Do not use a damaged power cord or cables

Doing so may cause an electric shock or a fire

Do not place any object on this instrument

Do not use this instrument if faulty

If you suspect the instrument to be faulty, contact your local N4L office or

representative for repair (see section 8)

PPA55xx Quick User Guide

Page 8

2.3 Warranty

This product is guaranteed to be free from defects in materials and workmanship

for a period of 36 months from the date of purchase

In the unlikely event of a problem within this guarantee period, first contact

Newtons4th Ltd or your local representative to give a description of the problem.

Please have as much relative information to hand as possible –particularly the

serial number and release number these can be found by pressing the SYSTEM

button then the “Left Arrow”

If the problem cannot be resolved directly then you will be given an RMA number

and asked to return the unit. The instrument will be repaired or replaced at the

sole discretion of Newtons4th Ltd

This guarantee is limited to the cost of the PPA55xx itself and does not extend to

any consequential damage or losses whatsoever including, but not limited to,

any loss of earnings arising from a failure of the product or software

In the event of any problem with the instrument outside of the guarantee period,

Newtons4th Ltd offers a full repair and re-calibration service. Contact your local

representative. It is recommended that the PPA55xx be re-calibrated annually

PPA55xx Quick User Guide

Page 9

3 Front Panel Layout

1. Display Screen

2. Screen Display Function Buttons

3. Power Analyzer Mode Buttons

4. Handle

5. Measurement Control Function Keys

6. Rubber Feet

7. Menu Selection and Cursor Controls

8. Measurement Settings Buttons

9. Front USB Port

10. Power On / Off Button

1 2 3

10 9 8 7 6
