New Power 8ES40 Manual de usuario
DC To AC POWER INVERTER
400W&600W 800W/1000W 1200W/1500W 2000W/2500W 3000W/3500W/4000W
User Manual
Modifed Sine Wave Power Inverter
IMPORTANT SAFETY INFORMATION, SAVE THESE INSTRUCTIONS
TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND
THIS INSTRUCTIONAL MANUAL. THIS MANUAL CONTAINS IMPORTANT
INFORMATION REGARDING THE OPERATION OF PRODUCT. PLEASE
RETAIN FOR FUTURE REFERENCE.
400W
600W
800W
1000W
1200W
1500W
2000W
2500W
3000W
3500W
4000W
List of contents
How Power Inverter Work--------------------------2
Connecting The Inverter----------------------------3
Modifed sine wave graph--------------------------5
sine wave specification-----------------7
Troubleshooting guide------------------------------8
Modifed sine wave graph--------------------------6
Modifed
220/230
220/230
220/230V
Warning!
220/230
Do not connect the output terminals of the inverter
to an incoming AC source.
Low Voltage Alarm.
9.Do NOT connect the inverter 220V output to another power source!
10.
11. Do not parallel or serie connect the output of two inverter.
The output waveform will not be in phase with another.
Wrong!
Warranty void!
3. Modifed sine wave graph
2-1. Features:
2-2 Suitable Appliances:
A.Modifed sine wave output (<2% thd).
b. input & output fully isolation design.
c. high efficiency 87%~90%.
d. high surge in motor start capacity.
e. 5-stage thermal control fan.
F. auto restart function.
a. power tools-circular saws, drills, grinders, sanders, buffers, weed and
hedge trimmers, air compressors.
b. office equipment-computer, printers, monitors, facsimile machines,
scanner.
c. kitchen appliances-microwave ovens, refrigerators and freezers,
coffee makers, blenders, ice markers, toasters.
d. industrial equipment-metal halide lamp, high-pressure sodium lamp.
e. household items-vacuum cleaners, fans, fluorescent and
incandescent lights, sewing machines.
f. home entertainment electronics-tv, vcr, video games, stereos,
musical instruments, satellite equipment.
POWER LED INDICATOR
AC OUTLETS
ON/OFF SWITCH
COOLING FAN
POWER INPUT TERMINAL
(RED)=POSITIVE
POWER INPUT TERMINAL
(BLACK)=NEGATIVE
GROUND LUG TERMINAL
400W/600W/800W
5
FUSE
CHARGER PORT
Thermal Protection.
55 C
AC OUTLETS
ON/OFF SWITCH POWER LED INDICATOR
GROUND LUG TERMINAL POWER INPUT TERMINAL
(BLACK)=NEGATIVE
POWER INPUT TERMINAL
(RED)=POSITIVE
POWER INPUT TERMINAL
(BLACK)=NEGATIVE
POWER INPUT TERMINAL
(RED)=POSITIVE
GROUND LUG TERMINAL
POWER LED INDICATOR
ON/OFF SWITCH
AC OUTLETS
1000W/1200W
3000W/3500W/4000W
COOLING FAN
COOLING FAN
6
POWER INPUT TERMINAL
(BLACK)=NEGATIVE
POWER INPUT TERMINAL
(RED)=POSITIVE
GROUND LUG TERMINAL
POWER LED INDICATOR ON/OFF SWITCH
AC OUTLETS
COOLING FAN
1500W/2000W/2500W
REMOTE PORT
Modifed sine wave spec.
Model No.
Continuous power
Max surge power
AC Output Voltage
DC input Voltage
Output wave form
Frequency
Efficiency
Temperature
protection
Input low volt
alarm
Input low volt
shut-down
Input high volt
protection
Output short
circuit protection
THD (Distortion)
Dimensions
(L*W*H)/mm
SPECIFICATIONS
~~Modifed Sine Wave~~
220V 10% RMS
11-15V
50Hz 3Hz
>80%
<65 C
10.5 0.5V
10 0.5V
>15V
Auto Shut-down
<2%
800W
400W 800W 1200W 2500W 3500W
7
600W 1000W 1500W 2000W 3000W 4000W
1200W 1600W 2000W 2400W 3000W 4000W 5000W 6000W 7000W 8000W
8DSA2
8ES40 8ES80 8ESB6 8ESC6
8ES60 8ESA0 8DSA6 8ESB0 8ESC0 8ESD0
400W
600W
800W
1000W
1200W
1500W
2000W
2500W
3000W
3500W
4000W
800W(with charger)
1500W(with charger)
2000W(with charger)
163*98*48mm
286 147 74
163*98*48mm
**mm
286*147*74mm
290*210*89mm
290*210*89mm
342*260*86mm
342*260*86mm
417*230*158mm
417*230*158mm
457*230*158mm
286*147*74mm
375*210*99mm
432*260*86mm
8
Troubleshooting guide
Problem Possible cause Solution
Low output voltage Using a voltmeter which can
not read the RMS voltage
Use a true RMS voltmeter
Low input voltage and watts
LEDturnstobered.
Poor battery condition
Overload
Improper Installation
Check the batteries and the
vehicle alternator condition
Reduce load
Check each inverter’ss
installation steps
No output voltage and volt
indicator in lower red zone
Low input voltage Recharge the battery, check
the connections and cables.
No output voltage and no
voltage indication
Inverter off
No DC power to the inverter
Reverse DC polarity
Turn the inverter on
Check the wiring
Check battery fuse and the
installation
Replace the inverter. Damage
caused by reversed polarity is
not covered by the warranty
Low battery alarm on
continuously
Poor battery condition
Poor DC wiring
Poor DC terminal
connections
Charge or change battery
Use proper cables and check
connection
Use proper tool
No output voltage and
overtemp indicator on
Thermal shutdown
Improper installation
Reduce load
Allow inverter to cool off
Improve ventilation
Install properly
No output voltage and
overload indicator
Short circuit or wiring error
Inverter overload
Improper installation
Check AC wiring
Remove or reduce load, switch
the inverter OFF at least 5
seconds and restart the inverter
Check the AC wires and
improper polarity
8
RD27032008
No output power You have connected the
inverter’s 220V output to
another power source
Warranty void!
Send back to supplier for
charged repairs
