New Air AB-850B Manual de usuario

Manual v1.2

90-Can Beverage Fridge

AB-850B

OWNER’S MANUAL

Read and save these instructions.

newair.com

READ AND SAVE THESE INSTRUCTIONS.

TABLE OF CONTENTS

Safety Information & Warnings ........................................................................... 4

Parts List............................................................................................................... 5

Assembly & Installation ....................................................................................... 6

Operating Instructions ......................................................................................... 7

Cleaning & Maintenance...................................................................................... 8

Troubleshooting................................................................................................... 9

Limited Manufacturer’s Warranty ..................................................................... 11

SPECIFICATIONS

MODEL NO.

AB-850B

VOLTAGE:

110V

CURRENT:

1.3A

REQUENCY

60Hz

POWER CONSUMPTION:

85W

BOTTLE CAPACITY:

90 cans

STORAGE CAPACITY:

2.2 cu. ft.

TEMPERATURE RANGE:

34°F - 64°F

REFRIGERANT:

R600a (1.84 oz)

Take advantage of all the benefits product registration has to offer:

Service and Support

Diagnose troubleshooting and service issues faster and more

accurately

Recall Notifications

Stay up to date for safety, system updates and recall notifications

Special Promotions

Opt-in for NewAir promotions and offers

Registering your product information online is safe & secure and takes less

than 2 minutes to complete:

Alternatively, we recommend you attach a copy of your sales receipt below and

record the following information, located on the manufacturer’s nameplate on

the rear of the unit. You will need this information if it becomes necessary to

contact the manufacturer for service inquiries.

Date of Purchase: ___________________________________________

Serial Number: ____________________________________________

Model Number: ____________________________________________

newair.com

SAFETY INFORMATION & WARNINGS

When using any electrical appliance, basic safety precautions

must be followed in order to reduce the risk of fire, electrical

shock and/or injury to persons or property. Be sure to read all

instructions before using this appliance and observe the

following safety tips:

Attention: Child Entrapment Risk!

To prevent the risk of child entrapment, do not allow children to operate,

play with, or crawl inside the unit. If the unit will not be used for an extended

period of time, remove the door and leave the shelves in place so that children

cannot crawl inside. Also remove the door when disposing of the unit.

Shock Hazard – Electrical Grounding Required

•Never attempt to repair or perform maintenance on the unit until the

electricity has been disconnected.

•Never remove the round grounding prong from the plug and never use a

two-prong grounding adaptor.

•Altering or cutting of power cord, removal of power cord, removal of power

plug, or direct wiring can cause serious injury, fire, loss of property and/or

life, and will void the warranty.

•Never use an extension cord to connect power to the unit.

•Avoid operating this beverage cooler in excessively moist or humid

environments.

Important Precautions:

•Do not lift unit by door handle.

•Never install or operate the unit behind closed doors.

•Failure to clean the condenser every six months can cause the unit to

malfunction.

•Allow unit temperature to stabilize for 24 hours before use.

•Do not block any internal fans.

•Keep the beverage cooler away from hazardous materials or

combustible/flammable substances.

•Use only genuine supplier’s replacement parts. Imitation parts can damage

the unit, affect its operation or performance, and may void the warranty.

PARTS LIST

When you receive your unit, carefully remove the exterior and interior

packaging. It is recommended that you retain the packaging for future use.

Check to make sure the following parts are included:

•3 Shelves

•1 instruction manual

PARTS DIAGRAM

1. Mechanical temperature

control panel

2. Stainless steel door

3. Beverage cooler foot

4. Door hinge

5. Interior LED light

6. Shelf

7. Lock

newair.com

ASSEMBLY & INSTALLATION

Before connecting the appliance to a power source, let it stand

upright for approximately 2 hours. This will reduce the possibility

of a malfunction in the cooling system from handling during

transportation.

This beverage cooler is a freestanding unit and should not be built in to

surrounding cabinetry. Allow for proper air clearance around the cooler. The

recommended clearances are as follows:

Sides: ¾” (19 mm)

Top: 4” (100 mm)

Back: 2” (50 mm)

Before operating your beverage cooler for the first time, follow these steps:

1. Clean the interior surface of the unit with lukewarm water and a soft

cloth.

2. Place the cooler on a level surface that will be strong enough to

support the unit when it is fully loaded. To level your cooler, adjust the

front feet located at the bottom of the unit.

3. Install the cooler away from direct sunlight and heat sources such as

stoves, heaters, or radiators. Direct sunlight may affect the unit’s

acrylic coating, and nearby heat sources can increase electrical

consumption. Extreme cold or hot ambient temperatures may also

prevent proper performance.

4. Once the cooler is plugged in, let the beverage cooler run for at least

30 minutes. Do not change the temperature or adjust any settings at

this time.

REVERSING THE DOOR SWING

1. To reverse the door swing of the unit, remove the plastic hinge cover at

top of the unit.

2. Unscrew the door hinge.

3. Flip door upside-down.

4. Attach door to opposite side of unit with screws.

5. Replace plastic door hinge cover.

OPERATING INSTRUCTIONS

TEMPERATURE ADJUSTMENT

1. Thermostat

2. Light Switch

3. Led Light

Your beverage cooler can be set to your desired temperature. The unit’s

temperature range is 34°F to 64°F (1°C to 18°C).

The temperature scale runs from 1, the warmest setting, to 7, the coldest

setting. The 0 position is an OFF setting which can be used when the beverage

cooler is standing empty.

Avoid setting the thermostat too high or the beverage cooler may be unable to

achieve satisfactory cooling temperatures.

OPTIMIZING PERFORMANCE

•To ensure maximum performance and efficiency, be sure to place your

beverage cooler in an area where there is proper air circulation. (See

installation instructions above for proper clearances.)

•For proper internal air circulation, do not overfill your beverage cooler.

When storing beverages, keep them away from the rear wall. To allow free

circulation of cold air, don’t pack beverages too tightly on the shelves.

•Do not place the unit in direct sunlight.

•Do not place heated beverages or food in your cooler.

•Do not store perishable food in your beverage cooler. The unit’s interior

temperature may not be low enough to prevent spoilage.

•Do not place heavy objects on top of the beverage cooler.

newair.com

CLEANING & MAINTENANCE

CLEANING YOUR COOLER

How to clean your cooler:

•Unplug the cooler and remove anything inside.

•Wash the inside of the unit with a solution made of warm water and neutral

detergent. Do not use abrasive cleaners.

•Use mild, soapy water to clean the unit’s door seal.

•To ensure efficient operation, also thoroughly clean the back and bottom of

the beverage cooler.

•To clean the outside of the unit, use a mild detergent and warm water.

DEFROSTING YOUR COOLER

To prevent ice buildup on the inside of the beverage cooler, it may be

necessary to defrost occasionally:

1. Turn the temperature control to #4 or #5.

2. Wait 30 to 60 minutes.

3. Turn control knob back to #1 or #2.

If you notice an excess of frost buildup inside the unit, take these steps to

remove it:

1. Unplug the beverage cooler.

2. Allow frost to melt from the inside of the cooler. If necessary, use a

plastic utensil to scrape ice from the interior surface.

3. Dry thoroughly before plugging it in again.

MOVING YOUR COOLER

To move your cooler:

•Remove anything stored inside.

•Securely tape down all loose parts located inside the unit.

•Turn the leveling feet up to the base in order to avoid damage.

•Tape the door shut.

•Be sure the cooler stays in an upright position during transportation.

TROUBLESHOOTING

Problem

Possible Causes

Solution

The beverage cooler

does not cool.

The unit may be

plugged in using a

different voltage.

Check if using the wrong

voltage.

The circuit breaker may

be tripped or there is a

blown fuse.

Reset the circuit breaker

or check for a broken

fuse

The beverage cooler

is not cold enough.

The external

environment may

require a higher setting.

Lower the temperature

of the cooler.

The cooler may be

placed too close to a

heat source.

Keep the cooler away

from direct sunlight or

other heat sources.

There is insufficient

ventilation.

Place the beverage

cooler in an area with

proper ventilation and

clearances.

The door is not

completely closed or

the door seal is not

working properly.

Close the door tightly.

Do not open the door

frequently and do not

keep the door open for

extended periods of

time. Replace the seal

on the door if necessary.

The beverage cooler

seems to make too

much noise.

The unit is not leveled.

Adjust the unit’s feet

and ensure the product

is level.

There is insufficient

ventilation. The unit is

too close to a wall or

another surface.

Allow sufficient

clearance around the

unit.

An interior red light is

flashing.

The set temperature is

too low.

Adjust the set

temperature so that it is

higher than the

beverage cooler’s

interior temperature.

newair.com

Problem

Possible Causes

Solution

Frost is building up in

the unit.

There is excess

humidity or the interior

temperature is too low.

Turn off the beverage

cooler, unplug it, and

remove the frost

buildup manually.

Reconnect the power

once the ice has

thawed.

Tabla de contenidos

Otros manuales de Refrigerador de New Air

New Air

New Air NBC096BS00 Manual de usuario

New Air

New Air Prismatic Series Manual de usuario

New Air

New Air AB-600B Manual de usuario

New Air

New Air NCR032SS00 Manual de usuario

New Air

New Air NOF090SS00 Manual de usuario

New Air

New Air NBC224SS00 Manual de usuario

New Air

New Air NOF100SS00 Manual de usuario

New Air

New Air NUR-029-SS Manual de usuario

New Air

New Air AWR-460DB Manual de usuario

New Air

New Air Beers of the World Manual de usuario

New Air

New Air NWC046SS01 Manual de usuario

New Air

New Air CC-100H Manual de usuario

New Air

New Air CC-300H Manual de usuario

New Air

New Air NPR122GA00 Manual de usuario

New Air

New Air NPR048GA00 Manual de usuario

New Air

New Air NWB076BS00 Manual de usuario

New Air

New Air NBC160SS00 Manual de usuario

New Air

New Air NBC177SS00 Manual de usuario

New Air

New Air AB-1200X Manual de usuario

New Air

New Air Prismatic Series Manual de usuario

New Air

New Air NPR-Battery15 Manual de usuario

New Air

New Air NRF031BK00 Manual de usuario

New Air

New Air NBC060SS00 Manual de usuario

New Air

New Air NBC060SS00 Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
