How to use Z815B
Soft switch
Z815B can switch its output through the button switches.
Wireless remote controller
If the Z815B device is properly paired with a remote controller, you should see the AC
outputs responds to on or off instruction wirelessly. Refer to Step 2 Device Pairing in the
previous section.
Note that device pairing is not a must feature with Z815B. You may operate it without
pairing the device to a remote controller as Z815B already has a manual switch.
Power Consumption Reporting
When the load is attached to the device, the embedded meter reads the supplied current
drawn overtime. Z815B reports the readings to a paired target device normally are an
in-home display or consumption data logger. Ensure that you go through consumption
reporting and configure reporting time interval described in ZiG-BUTLER page otherwise
Z815B will not sent consumption reading.Z815B can report the consumption reading to
Netvox’s ZiG-BUTLER or to any 3rd party in-home display.
Power drawn overtime is measured. Current (unit mA), Voltage (unit V), Power (unit W)
and Energy (unit Wh). Z815B stores a new value read and updates such value and clears
up the previous. User may want to return the reading back to zero when wish. Refer to
Return-Zero the Consumption Reading section.
Reading accuracy
If the output current is above 125mA, the reading accuracy of current, voltage and power
is ±1%. Current detection range is between 125mA to 8A per each AC output.
