Netvox R313WA Manual de usuario

Model: R313WA

Wireless Seat Occupy Sensor

R313WA

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology and is issued

in strict confidential and shall not be disclosed to others parties in whole or in parts without written permission of

NETVOX Technology.

The specifications are subjected to change without prior notice.

Wireless 2-Gang Seat Occupancy Sensor

Table of Content

1. Introduction......................................................................2

2. Appearance.......................................................................3

3. Main Features...................................................................3

4. Set up Instruction .............................................................4

5. Data Report......................................................................5

5.1 Example of ReportDataCmd......................................6

5.2 Example of ConfigureCmd........................................7

5.3 Example of Resendtime.............................................8

5.4 Example for MinTime/MaxTime logic......................9

6. Seat Occupancy Delay Configuration............................10

7. Installation......................................................................12

8. Important Maintenance Instruction................................14

1. Introduction

R313WA is a Class Awireless 2-gang seat occupancy device based on standard LoRaWAN protocol. The R313WA will report to the

gateway whenever one of the 2-gang seat occupancy sensor detects external pressure. It will also report to the gateway when the

external pressure is gone.

LoRa Wireless Technology:

LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other

communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.

Widely used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation

equipment, wireless security systems, industrial monitoring. Main features include small size, low power consumption, transmission

distance, anti-interference ability and so on.

LoRaWAN:

LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and

gateways from different manufacturers.

2. Appearance

3. Main Features

Compatible with LoRaWAN

2 sections of 3V CR2450 button battery power supply

Detectable voltage and seat occupancy status

Simple operation and setting

Protection level IP30

Compatible with LoRaWAN Class A

Frequency hopping spread spectrum technology

Available third-party platform: Actility / ThingPark, TTN, MyDevices/Cayenne

Low power consumption and long battery life

Indicator

Function Key

Seat Sensor

External Antenna

4. Set up Instruction

On/Off

Power on Insert batteries.

Note: Insert two sections of 3V CR2450 button batteries and close the battery cover.

Turn on Press any function key till green and red indicator flashes once.

Turn off (Restore to factory setting) Press and hold both function keys for 5 seconds till green indicator flashes for 20

times.

Power off Remove Batteries.

Note:

1.Remove and insert the battery; the device memorizes previous on/off state by

default.

2.On/off interval is suggested to be about 10 seconds to avoid the interference of

capacitor inductance and other energy storage components.

3.Press any function key and insert batteries at the same time; it will enter engineer

testing mode.

Network Joining

Never joined the network

Turn on the device to search the network.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Had joined the network

Turn on the device to search the previous network.

The green indicator stays on for 5 seconds: success

The green indicator remains off: fail

Fail to join the network

(when the device is on)

Suggest to check the device verification information on the gateway with your

platform server provider.

Function Key

Press and hold for 5 seconds

Restore to factory setting / Turn off

The green indicator flashes for 20 times: success

The green indicator remains off: fail

Press once The device is in the network: green indicator flashes once and sends a report

The device is not in the network: green indicator remains off

Sleeping Mode

The device is on and in the

network

Sleeping period: Min Interval.

When the r

eportchange exceeds setting value or the state changes: send a data report

according to Min Interval.

Low Voltage Warning

Low Voltage 2.4V

5. Data Report

Data report configuration and sending period are as following:

Min Interval

(Unit:second)

Max Interval

(Unit:second) Reportable Change Current Change≥

Reportable Change

Current Change

＜

Reportable Change

Any number between

1~65535

Any number between

1~65535 Can not be 0. Report

per Min Interval

Report

per Max Interval

When the device is turned on, it will immediately send a version package and attribute data.

Before any configuration is modified, the device sends data according to the default settings.

Default Setting:

Maximum time: 0x0E10 (3600s)

Minimum time: 0x0E10 (3600s)

BatteryChange: 0x01 (0.1V)

DisableTime: 0x001E (30s)// Value must be greater than DisableTime≧5s

DetectionTime: 0x0078 (120s) //Value must be greater than DetectionTime≧DisableTime

Pressure Detecting

：

When the R313WA detects changes in pressure, it will report the status.

When the seat is occupied, the status is 1.

When the seat is unoccupied, the status is 0.

Note:

The reported data is decoded by the Netvox LoRaWANApplication Command document and

http://www.netvox.com.cn:8888/cmddoc

5.1 Example of ReportDataCmd

FPort：0x06

Bytes 1 1 1 Var(Fix=8 Bytes)

Version DeviceType ReportType NetvoxPayLoadData

Version– 1 byte –0x01——the Version of NetvoxLoRaWAN Application Command Version

DeviceType– 1 byte – Device Type of Device

The devicetype is listed in Netvox LoRaWAN Application Devicetype doc

ReportType – 1 byte –the presentation of the NetvoxPayLoadData，according the devicetype

NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)

Example 1 of Uplink: 015A011D01000000000000

1st byte (01): Version

2nd byte (5A): DeviceType 0x5A－R313WA

3rd byte (01): ReportType

4th byte (1D): Battery－2.9V, 1D(Hex) = 29(Dec), 29x0.1v=2.9v

5th byte (01): Status1－on

Device Device

Type

Report

Type NetvoxPayLoadData

R313WA 0x5A

0x00

SoftwareVersion

(1Byte)

Eg.0x0A—V1.0

HardwareVersion

(1Byte)

DateCode

(4Bytes,eg

0x20170503)

Reserved

(2Bytes,fixed 0x00)

0x01 Battery

(1Byte, unit:0.1V)

Status1

(1Byte 0:off 1:on)

Status2

(1Byte 0:off 1:on)

Reserved

(5Bytes,fixed 0x00)

Tips

1. Battery Voltage:

The voltage value is bit 0 ~ bit 6, bit 7=0 is normal voltage, and bit 7=1 is low voltage.

Battery=0x98, binary=1001 1000, if bit 7= 1, it means low voltage.

The actual voltage is 0001 1000 = 0x18 = 24, 24*0.1v =2.4v

2. Version Packet:

When Report Type=0x00 is the version packet, such as 015A000A0B202005200000, the firmware version is 2020.05.20

3. Data Packet:

When Report Type=0x01 is data packet.

6th byte (00): Status2－off

7th -11th byte (0000000000): Reserved

5.2 Example of ConfigureCmd

FPort：0x07

Bytes 1 1 Var (Fix =9 Bytes)

CmdID DeviceType NetvoxPayLoadData

CmdID– 1 byte

DeviceType– 1 byte – Device Type of Device

NetvoxPayLoadData– var bytes (Max=9bytes)

(1)Configure device parameters

MinTime = 60s, MaxTime = 60s, BatteryChange = 0.1, SensorDisableTime = 30s, SensorDectionTime = 60s

Downlink: 015A003C003C01001E003C 001E(Hex) = 30(Dec), 003C(Hex) = 60(Dec)

Response:

815A000000000000000000 (Configuration success)

815A010000000000000000 (Configuration failure)

(2)Read Configuration:

Downlink: 025A000000000000000000

Response:

825A003C003C01001E003C (Current configuration)

Description Device CmdID Device

Type NetvoxPayLoadData

ConfigReport

Req

R313WA

0x01

0x5A

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte

Unit:0.1v)

Sensor

DisableTime

(2bytes Unit:s)

Sensor

DectionTime

(2bytes Unit:s)

ConfigReport

Rsp 0x81 Status

(0x00_success)

Reserved

(8Bytes,Fixed 0x00)

ReadConfig

ReportReq 0x02 Reserved

(9Bytes,Fixed 0x00)

ReadConfig

ReportRsp 0x82 MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

BatteryChange

(1byte

Unit:0.1v)

Sensor

DisableTime

(2bytes Unit:s)

Sensor

DectionTime

(2bytes Unit:s)

Note:

Disable time must≧5s

Detection time≧Disable time

5.3 Example of Resendtime

FPort：0x07

Resend the occupancy status of the seat sensor.

(1)Configure device parameters: resend time = 5s

Downlink: 1FFF050000000000000000

Response:

9FFF000000000000000000 (Configuration success)

9FFF010000000000000000 (Configuration failure)

(2)Read Configuration

Downlink: 1EFF000000000000000000

Response:

9EFF050000000000000000 (Current configuration)

Description Device Cmd

Device

Type NetvoxPayLoadData

SetLastMessage

ResendtimeReq Suitable

for use

with

contact

switch

devices.

0x1F

0xFF

Resendtime

(1Byte,Unit:1s)

Reserved

(8Bytes,Fixed 0x00)

SetLastMessage

ResendtimeRsp 0x9F Status

(0x00_success)

Reserved

(8Bytes,Fixed 0x00)

GetLastMessage

ResendtimeReq 0x1E Reserved

(9Bytes,Fixed 0x00)

GetLastMessage

ResendtimeRsp 0x9E Resendtime

(1Byte,Unit:1s)

Reserved

(8Bytes,Fixed 0x00)

Resend time range: 0x00 to 0xFF

Resend time = 0x00 or 0xFF, means no additional data will be sent

Resend time = 0x03 to 0xFE, the device will send data after triggering, and then supplement the last status data after 3-254s.

5.4 Example for MinTime/MaxTime logic

Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V

Note:

MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BtteryVoltageChange value.

Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.

1H 2H 3H

sleeping (MinTime) sleeping (MinTime)

MaxTime MaxTime

Wake up and collect data

REPORTS 2.5V

Wakes up and collect data

REPORTS 2.7V

Wakes up and collect data

REPORTS 2.8V

Wakes up and collects data

2.8V

Does not report

Wakes up and collects data

REPORTS 2.8V

Wakes up and collects data

REPORT 2.8V

sleeping

sleeping (MinTime)

MaxTime

15thM 30thM 45thM 2H

MaxTime

sleeping

30thM

2H 10thM

15thM

45thM

1H 25thM

1H 40thM

1H 55thM

1H 10thM

Wakes up and

collects data

REPORTS 2.8V

Wakes up and collects data

2.7V |2.7-2.8|=0.1

REPORTS 2.7V

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and collects data

2.7V Does not report

Wakes up and

collects data

2.7V

Does not report

Wakes up and

collects data

REPORTS 2.7V

Wakes up and

collects data

2.8V

Does not report

Users push the button,

REPORTS 2.7V.

Recalculate MaxTime.

Otros manuales para R313WA

Tabla de contenidos

Otros manuales de Sensor de seguridad de netvox

netvox

netvox R313FC Manual de usuario

netvox

netvox R311W Manual de usuario

netvox

netvox R718WAA Manual de usuario

netvox

netvox R718WB2 Manual de usuario

netvox

netvox Z801TXB Manual de usuario

netvox

netvox R313FA Manual de usuario

netvox

netvox RA08B Series Manual de usuario

netvox

netvox RA02C Manual de usuario

netvox

netvox RA0708 Manual de usuario

netvox

netvox R718WB Manual de usuario

netvox

netvox R313CB Manual de usuario

netvox

netvox R718WA Manual de usuario

netvox

netvox R313LA Manual de usuario

netvox

netvox R313CC Manual de usuario

netvox

netvox R311CB Manual de usuario

netvox

netvox R311A Manual de usuario

netvox

netvox S31501 Manual de usuario

netvox

netvox R719A Manual de usuario

netvox

netvox R313WA Manual de usuario

netvox

netvox R718B2 Manual de usuario

netvox

netvox ZB11C Manual de usuario

netvox

netvox R718WB2 Manual de usuario

netvox

netvox R718PA9 Manual de usuario

netvox

netvox R718WB2 Manual de usuario

Manuales populares de Sensor de seguridad de otras marcas

THORLABS

THORLABS PDA10JT Manual de usuario

Waeco

Waeco UV-DETECT Manual de usuario

Intermatic

Intermatic IOS-DSIMF Manual de usuario

urmet domus

urmet domus 1083 Manual de usuario

Siemens

Siemens AZL66 Series Manual de usuario

BTI

BTI Profiline Multi Finder Manual de usuario

Challenger

Challenger SL01 Manual de usuario

DMP Electronics

DMP Electronics 1122INT Manual de usuario

Rielta

Rielta Ladoga MK-RK Manual de usuario

Mirion Technologies

Mirion Technologies ACCURAD PRD Manual de usuario

Bosch

Bosch DS835 Manual de usuario

DBI SALA

DBI SALA EZ Stop Manual del operador

Lamptime

Lamptime ST05C Manual de usuario

Ubiquiti

Ubiquiti MFI-MSC Manual de usuario

Subsite

Subsite 910R Instrucciones de instalación

Satel

Satel OPAL Pro Manual de usuario

Aleph

Aleph XC-1XTEU Manual de usuario

Pima

Pima LARIS QUAD Manual de usuario
