Netvox R816B Manual de usuario

Wireless Wall-Mounted Power Socket with Consumption Monitoring,

One Gang Wireless enabled, One Gang Straight-through, US type

Model：R816B

Wireless Wall-Mounted Power Socket

with Consumption Monitoring

(US type)

R816B

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained

in strict confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX

Technology. The specifications are subject to change without prior notice.

Table of Content

1. Introduction......................................................................................................................2

2. Appearance.......................................................................................................................3

3. Main Characteristic..........................................................................................................3

4. Operation..........................................................................................................................4

5. Data Report ......................................................................................................................5

5.1 Example of ReportDataCmd......................................................................................6

5.2 Example of ConfigureCmd ........................................................................................7

5.3 Example for MinTime/MaxTime logic ......................................................................8

6. Product Installation ..........................................................................................................9

7. Important Maintenance Instruction ................................................................................10

1. Introduction

R816B is a long-distance wireless socket device for Netvox ClassC type devices based on the LoRaWAN open protocol,

compatible with the LoRaWAN protocol. The AppServer can be used to control the opening and closing of the external load of

the R816B, and the external load can also be controlled by the switch that comes with the R816B device itself. The current,

voltage, power and energy values of the current load can be viewed through the AppServer. R816B supports automatic

disconnection of load and over-current alarm.

LoRa wireless technology:

LoRa is a wireless communication technology dedicated to long-distance low-power consumption. Its spread-spectrum

modulation method greatly increases the communication distance compared with other communication methods, and can be

widely used in long-distance low-rate IoT wireless communication fields in various occasions. Such as automatic meter reading,

building automation equipment, wireless security systems, industrial monitoring and control. It has the characteristics of small

size, low power consumption, long transmission distance and strong anti-interference ability.

LoRaWAN:

LoRaWAN defines an end-to-end standard specification using LoRa technology to ensure interoperability between devices from

different vendors.

2. Appearance

Note: Socket 1 is a general socket and cannot be controlled.

3. Main Characteristic

Compatible with LoRaWAN standard

100-240VAC 50/60HZ power supply

Simple operation and setting

Compatible with LoRaWANTM Class C

Frequency hopping spread spectrum

Applicable to third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne

Over current alarm

Automatically disconnect the load due to over current

Switch Indicator

Network Indicator

Switch Button

Socket 1

Socket 2

Factory Restoring Key (inside)

4. Operation

On/Off

Power on/Turn on Socket the R816B into the power supply of the AC 100-

240V, power on the device and

all the indicators flash once.

Power off When the R816B is removed from the power supply interface, the R816B will be

powered off and stopped.

Network Joining

Never joined the network

Turn on the device to search the network to join.

The network indicator stays on: success

The network indicator remains off: fail

Had joined the network

Turn on the device to search the previous network to join.

The network indicator stays on: success

The network indicator remains off: fail

Fail to join the network

(when the device is on)

Suggest to check the device verification information on the gateway or consult your

platform server provider.

Function Key

Press and hold the factory restoring key

for

5 seconds

Restore to factory setting

The network indicator flashes for 10 times: success

The network indicator remains off: fail

Press and hold the factory restoring key

for

10 seconds

(The network indicator flashes once when

the button is pressed for 5s, and flashes

again when the button is pressed for 10s),

and then release the key

to clear the power

information)

Clear electric energy cumulative value

The network indicator flashes for 5 times

If the network indicator does not flash, the clearing of the accumulated electric energy

value fails

Press the switch button

Control the relay switch on R816B for Toggle operation

When R816B is on, the switch indicator is on;

When R816B is off, the switch indicator is off.

5. Data Report

Data report configuration and sending period are as following:

Min Interval

(Unit:second)

Max Interval

(Unit:second) Reportable Change Current Change≥

Reportable Change

Current Change＜

Reportable Change

Any number between

1~65535

Any number between

1~65535 Can not be 0. Report

per Min Interval

Report

per Max Interval

The device will immediately send a version packet report along with two uplink packets including ON/OFF status, energy, over

current alarm, voltage, current and power.

The device sends data in the default configuration before any configuration is done.

Default setting:

MaxTime: 0x0384 (900s)

MinTime: 0x0002 (2s)

// Mintime is recommended to set by default 2 seconds. Need to control to reduce frequent Report recommendations by

adjusting reportchange and Max Interval)

Current Change: 0x0064 (100mA)

Power Change: 0x0014 (20W)

Note:

1. The device reports the ON/OFF status, energy, over current alarm first, and after 10 seconds reports the voltage, current

and power.

2. When happened the over-current alarm, it will disconnect the load and the network indicator will quickly flash about 25

times.

3. Press the switch button or receive the switch command: The device will be reported immediately.

4. The uplink data reported by the device is referenced by the Netvox LoraWAN Application Command document and

http://www.netvox.com.cn:8888/page/index

5.1 Example of ReportDataCmd

FPort：0x06

Bytes 1 1 1 Var(Fix=8 Bytes)

Version DeviceType ReportType NetvoxPayLoadData

Version– 1 bytes –0x01——the Version of NetvoxLoRaWAN Application Command Version

DeviceType– 1 byte – Device Type of Device

The devicetype is listed in Netvox LoRaWAN Application Devicetype doc

ReportType – 1 byte –the presentation of the NetvoxPayLoadData，according the devicetype

NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)

PayLoadData– var bytes (Max=9bytes)

Version Device

Type

Report

Type NetvoxPayLoadData

0x01 0x73

0x01

OnOff (1Byte)

OFF_0x00

ON_0x01

Energy

(4Bytes)

unit:1wh

OverCurrentAlarm

(1Byte)

0:noalarm 1:alarm

※1DashCurrentAlarm

(1Byte)

0:noalarm 1:alarm

※2PowerOffAlarm

(1Byte)

0:noalarm 1:alarm

0x02 Vol

(2Bytes,Unit:1V)

Current

(2Bytes,Unit:1mA)

Power

(2Bytes,Unit:1W)

Reserved

(2Bytes,fixed 0x00)

※1 R816B does not support Dash Current Alarm.

※2 R816B does not support Power Off Alarm.

First uplink reports 0173010000000006000000 and after 10 seconds, the second uplink reports 01730200DB006400160000

The status of the switch is off.

The accumulated value of the energy is 6WH.

The over current does not alarm

The voltage is 219V 00DB(Hex)=219 (Dec)

The current is 100mA 0064(Hex)=100(Dec)

The power is 22W 0016(Hex)=22(Dec)

5.2 Example of ConfigureCmd

FPort：0x07

Bytes 1 1 Var(Fix =9 Bytes)

CmdID DeviceType NetvoxPayLoadData

CmdID– 1 byte

DeviceType– 1 byte – Device Type of Device

NetvoxPayLoadData– var bytes (Max=9bytes)

Description Device Cmd

Device

Type NetvoxPayLoadData

Off

R816B

0x90

0x73

Reserved

(9Bytes,Fixed 0x00)

On 0x91 Reserved

(9Bytes,Fixed 0x00)

Toggle 0x92 Reserved

(9Bytes,Fixed 0x00)

Clear

Energy 0x93 Reserved

(9Bytes,Fixed 0x00)

Read

CurrentStatus 0x94 Reserved

(9Bytes,Fixed 0x00)

Config

ReportReq 0x01 MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

CurrentChange

(2byte)

Unit:1mA

PowerChange

(2byte)

Unit:1W

Reserved

(1Byte)

Fixed 0x00)

Config

ReportRsp 0x81 Status

(0x00_success)

Reserved

(8Bytes,Fixed 0x00)

ReadConfig

ReportReq 0x02 Reserved

(9Bytes,Fixed 0x00)

ReadConfig

ReportRsp 0x82 MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

CurrentChange

(2byte)

Unit:1mA

PowerChange

(2byte)

Unit:1W

Reserved

(1Byte)

Fixed 0x00)

(1) Turn off the R816B switch button

Downlink: 9073000000000000000000

(2) Turn on the R816B switch button

Downlink: 9173000000000000000000

(3) Toggle turn on/off switch button

Downlink: 9273000000000000000000

(4) Clear the historical electrical energy data

Downlink:9373000000000000000000

(5) Setting Min Interval = 2 seconds, Max Interval = 300 seconds, Current Change = 100mA,Power Change = 20W

Downlink:01730002012C0064001400

Response: 8173000000000000000000 (successful)

(6) Read the current report interval

Downlink: 0273000000000000000000

Response:82730002012C0064001400

5.3 Example for MinTime/MaxTime logic

Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, PowerChange=2W

MaxTime MaxTime

(MinTime) (MinTime)

0H 1H 2H

Note:

MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless PowerChange value.

Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, PowerChange=2W

MaxTime

MinTime MinTime MinTime MinTime

0H 15th M 30th M 45th M 1H 2H

Collects data

REPORTS 35W

Collects data

REPORTS 39W

Collects data

REPORTS 50W

Collects data

REPORTS 10W

Collects data

REPORTS 11W

Collects data

Does not report

Collects data

10W

Does not report

Collects data

Does not report

Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, PowerChange=2W

MaxTime

MinTime MinTime MinTime MinTime MinTime MinTime

0H 15th M 30th M 45th M 1H 1H15thM 1H30thM

Remarks:

1. Compare the collected data with the last reported data. If the amount of data change is greater than ReportableChange, the

device will report based on the MinTime interval. If the data change is not greater than the last reported data, the device will

report based on the MaxTime interval.

2. For the energy consumption detection device, because the device is a constant power supply device, it is not recommended to

set the MinTime interval value too high in order to obtain the status information in real time. It is recommended to use the

default 2 seconds. If users need to control frequent report recommendations to adjust ReportableChange and MaxTime.

3. After the device sends a packet (regardless of whether the data has changed, such as pressing a button or the maximum time

is due), another MinTime / MaxTime calculation cycle is initiated.

6. Product Installation

This product does not have a waterproof function. After the screening is completed, please place it indoors.

Note:

The energy data of R816B is saved once every 10 seconds if the memory chip is AT24C02, once every 10 seconds for AT2402.

After power off, the data within 10 seconds will be gone.

Collects data

13W

REPORT ON

Collects data

Does not report

Collects data

10W

REPORTS

Collects data

12W

Does not report

Collects data

14W

Does not report

Collects data

13W

Does not report

Collects data

14W

REPORT

Power Change

over 2W

Otros manuales para R816B

Tabla de contenidos

Otros manuales de Accesorios de netvox

netvox

netvox R718CXAB Manual de usuario

netvox

netvox R718F2 Manual de usuario

netvox

netvox R718E Manual de usuario

netvox

netvox R718PA5 Manual de usuario

netvox

netvox R718N3 Manual de usuario

netvox

netvox ZigBee ZB11B Manual de usuario

netvox

netvox R311FA1 Manual de usuario

netvox

netvox RA0716 Manual de usuario

netvox

netvox R720FLT Manual de usuario

netvox

netvox R718VA Manual de usuario

netvox

netvox R313G Manual de usuario

netvox

netvox R718N1 Manual de usuario

netvox

netvox R311FA Manual de usuario

netvox

netvox RA0701 Manual de usuario

netvox

netvox R718PA5 Manual de usuario

netvox

netvox R718NL3 Series Manual de usuario

netvox

netvox R313FA1 Manual de usuario

netvox

netvox R72616A Manual de usuario

netvox

netvox R809A Manual de usuario

netvox

netvox R718B1 Series Manual de usuario

netvox

netvox R718PA8 Manual de usuario

netvox

netvox ZB11C1 Manual de usuario

netvox

netvox R311G Manual de usuario

netvox

netvox R718F2 Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario

netvox R816B Manual de usuario

Manuales populares de Accesorios de otras marcas
