NetKlass SME100 Manual de usuario

10/100 8-Port Dual-WAN VPN/Firewall Router

•i•

Table of Contents

1. Introduction..................................................................................... 1

Main features:............................................................................................................ 3

Load Balance and Backup.................................................................................................................3

Firewall Security.................................................................................................................................3

VPN Support ......................................................................................................................................3

Networking .........................................................................................................................................4

Network Management........................................................................................................................4

2. How To Install.................................................................................. 5

Hardware Features: .................................................................................................. 5

Feature List ........................................................................................................................................5

LED Status .........................................................................................................................................6

Reset Button.......................................................................................................................................6

Physical Setup of the Router:.................................................................................. 7

Set the Router on a desktop or other flat, secure surface. ................................................................7

Rack-Mounting the Router .................................................................................................................7

Wall-Mounting the Router ..................................................................................................................7

Connecting the 8-Port Dual-WAN VPN/Firewall Router to your Network:............ 8

3. How To Manage............................................................................. 10

Login........................................................................................................................ 10

Sitemap.................................................................................................................... 10

Home........................................................................................................................ 11

System Information ..........................................................................................................................11

Port Statistics ...................................................................................................................................11

Network Setting Status.....................................................................................................................12

Firewall Setting Status......................................................................................................................13

VPN Setting Status...........................................................................................................................14

Log Setting Status:...........................................................................................................................14

General Setting ....................................................................................................... 16

Configure..........................................................................................................................................16

Dual WAN.........................................................................................................................................20

Password..........................................................................................................................................22

Time..................................................................................................................................................23

Advanced Setting.................................................................................................... 25

DMZ Host.........................................................................................................................................25

10/100 8-Port Dual-WAN VPN/Firewall Router

•ii •

Forwarding .......................................................................................................................................25

UPnP................................................................................................................................................28

Routing.............................................................................................................................................29

One-to-One NAT..............................................................................................................................31

DDNS ...............................................................................................................................................33

MAC Clone.......................................................................................................................................34

DHCP........................................................................................................................ 36

Setup................................................................................................................................................36

Status ...............................................................................................................................................38

Tool .......................................................................................................................... 39

SNMP...............................................................................................................................................39

Diagnostic.........................................................................................................................................40

Restart..............................................................................................................................................42

Factory Default.................................................................................................................................43

Firmware Upgrade............................................................................................................................43

Setting Backup.................................................................................................................................44

Port Management.................................................................................................... 45

Port Setup ........................................................................................................................................45

Port Status........................................................................................................................................46

Firewall..................................................................................................................... 47

General.............................................................................................................................................47

Access Rules....................................................................................................................................48

Content Filter....................................................................................................................................53

VPN .......................................................................................................................... 55

Summary..........................................................................................................................................55

Gateway to Gateway........................................................................................................................59

Client to Gateway.............................................................................................................................71

VPN Pass Through...........................................................................................................................83

Log ........................................................................................................................... 84

System Log ......................................................................................................................................84

System Statistics..............................................................................................................................87

Logout...................................................................................................................... 88

10/100 8-Port Dual-WAN VPN/Firewall Router

•1•

1.Introduction

10/100 8-Port Dual-WAN VPN/Firewall Router contains two WAN ports and eight Ethernet

10/100 LAN ports and mainly supports small and medium size enterprise business network

with a high security VPN. The router brings high-speed network security to enterprise

businesses, remote users, service providers, and data centers. The SME router’s design

combines firewall, VPN support, NAT, and powerful traffic management with Fast Ethernet

connections to provide consistent network infrastructure security.

With the unique two WAN ports, the device can have a backup WAN interface. 8-Port

Dual-WAN VPN/Firewall Router supports Smart Link Backup and Load Balance for Dual WAN

management, and this feature enhances the robustness. The extra WAN port also can be

assigned as a DMZ port.

The product’s build-in advanced firewall features can resist various kinds of malicious attacks

and curious intruders. The product uses stateful packet inspection (SPI) to inspect all data

packets based on the established security policies. It also provides automatic protection from

Denial of service (DoS) attacks such as SYN flooding, IP Spoofing, LAND, ping of death and

all reassembly attacks. NAT functionality with firewall conceals network address avoiding the

disclosure as public information and also provides a solution for IP address depletion problem.

The product also has the reverse NAT capabilities that enable users to host various internet

services in the private IP address space, such as web servers, e-mail servers…, etc.

The VPN in this product provides the security for transferring sensitive data. It supports up to

100 VPN tunnels and 2 Group VPNs. Group VPN feature facilitates the setup and it’s not

necessary to individually configure remote VPN clients. The product implements the

Authentication Header (AH) and Encapsulating Security Payload (ESP) protocols that

provides anti-replay service for automatic key management and confidentiality, authentication

and integrity for data stream.

The VPN router’s build-in core management software tool provides a flexible, effective, and

easy to use management environment for the network users. It comes with a comprehensive

10/100 8-Port Dual-WAN VPN/Firewall Router

•2•

web based management interface for network administrator to easily control and monitor the

end users.

With WEB UI configuration, it is more flexible and easily configured by end users in different

operation systems.

10/100 8-Port Dual-WAN VPN/Firewall Router

•3•

Main features:

Load Balance and Backup

lSmart Link Backup

lIntelligent Load Balancing (auto)

Firewall Security

lStateful Packet Inspection Firewall

lIP filtering; allows you to configure IP address filters

lPort filtering; allows you to configure TCP/UDP port filters

lSupport DMZ to protect your network

lDenial of Service (DoS) prevention

VPN Support

lIPSec VPN

lSupport up to 100 VPN tunnels

lUp to 2 Group VPNs support

lFriendly VPN Tunnel Management

lIKE : Pre-Shared keys

lIPSec Encryption DES/3DES

lIPSec Authentication MD5/SHA1

lSupport PMTU

10/100 8-Port Dual-WAN VPN/Firewall Router

•4•

Networking

lDHCP Client/Server

lPPPoE

lNAT with popular ALG support

lNAT with port forwarding

lNAT with port triggers

lDNS Relay

lARP

lICMP

lFTP/TFTP

lPassword protected configuration or management sessions for web access

lLoad Balancing

lPort-based QoS

Network Management

lComprehensive web based management and policy setting

lSNMP v1/v2c

lMonitoring, Logging, and Alarms of system activities

lLocate and configure all device with the same subnet

10/100 8-Port Dual-WAN VPN/Firewall Router

•5•

2.How To Install

Hardware Features:

Feature List

WAN l2 RJ-45 10/100Base-T Ethernet Ports

LAN l8 RJ-45 10/100Base-T Ethernet ports

CPU lIntel IXP425

SDRAM l32 Mbytes SDRAM

Flash ROM l16 Mbytes Flash

Sys. Power l3.3V@3A

EMI/EMC lFCC Class B, CE Class B

Operation

Requirement

lOperating Temp.:0ºC to 40ºC (32ºF to 104ºF)

lStorage Temp.:0ºC to 70ºC (32ºF to 158ºF)

lOperating Humidity:10% to 85% Non-Condensing

lStorage Humidity:5% to 90% Non-Condensing

Dimensions l13”x 9”x 1.75”

10/100 8-Port Dual-WAN VPN/Firewall Router

•6•

LED Status

LED Color Description

Power Green lGreen On: Power On

DIAG Red

lRed On: System not ready and the Router goes

through its self-diagnostic mode

lRed Off: System ready and the Router completes the

diagnosis successfully

Link/Act Green lLight up: Ethernet Link

lFlicker: When the port is sending or receiving data

Speed Green lGreen On: 100Mbps

lGreen Off: 10Mbps

Reset Button

Action Description

Push button for 4

seconds

lWarm Reset

lDiag LED : Red Blinking slowly

Push button for 10

seconds

lFactory Default

lDiag LED : Red Blinking fastly
