NETGEAR WGR614v5 Guía del usuario

October 2009

208-10539-01

v1.0

NETGEAR, Inc.

350 E. Plumeria Drive

San Jose, CA 95134 USA

Wireless-N 150 Router

Setup Manual

Trademarks

NETGEAR and the NETGEAR logo are trademarks of NETGEAR. Inc. Microsoft, Windows, and Windows NT are

registered trademarks of Microsoft Corporation. Wi-Fi Protected Setup is a trademark of the Wi-Fi Alliance. Other

brand and product names are registered trademarks or trademarks of their respective holders.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to

make changes to the products described in this document without notice.

NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit

layout(s) described herein.

iii

Contents

Wireless-N 150 Router Setup Manual

Getting to Know Your Wireless Router................................................................................1

Unpacking Your New Router .............................................................................................1

Hardware Features ............................................................................................................2

Front Panel .................................................................................................................. 2

Back Panel ..................................................................................................................4

Side Panel ...................................................................................................................4

Router Label ................................................................................................................ 5

Positioning Your Wireless Router ......................................................................................5

Installing Your Wireless Router .........................................................................................6

Updating Your Router Firmware ........................................................................................7

Installing Your Router Using the Smart Wizard ..................................................................8

Using the Smart Wizard .....................................................................................................8

Accessing Your Router After Installation .........................................................................10

Manually Installing Your Router .........................................................................................11

Connecting Your Wireless Router ...................................................................................12

Verifying Your Connection ...............................................................................................15

Setting Up Your Router for Internet Access ....................................................................16

Configuring Your Wireless Network...................................................................................20

Setting Your SSID and Wireless Security .................................................................21

Using Push 'N' Connect (WPS) to Configure Your Wireless Network .......................22

Troubleshooting...................................................................................................................24

Basic Setup Checklist ......................................................................................................24

Checking Basic Router Functions ...................................................................................25

Troubleshooting Login Problems .....................................................................................27

Checking the Internet Service Connection ......................................................................28

Obtaining an Internet IP Address ....................................................................................28

Troubleshooting PPPoE ............................................................................................29

Troubleshooting Internet Browsing ...........................................................................30

Using the Ping Utility to Troubleshoot ............................................................................. 30

Testing the Path from Your Computer to Your Router ..............................................30

Testing the Path from a Computer to the Internet .....................................................31

Technical Specifications .....................................................................................................32

Default Configuration Settings .........................................................................................32

Restoring the Default Password and Configuration Settings ...........................................34

Related Documents .............................................................................................................35

Registration and Certifications............................................................................................36

Getting to Know Your Wireless Router 1

Getting to Know Your Wireless Router

Congratulations on your purchase of a NETGEAR® high-speed wireless router, the Wireless-N

150 Router Model WNR1000v3.

Before you begin installing your router, check the package contents (see “Unpacking Your New

Router” on page 1). Become familiar with the front and back panels of your router—especially the

status lights—and the important information on the router label (see “Hardware Features” on

page 2). Then, read the section on “Positioning Your Wireless Router” on page 5 to ensure that

you have selected the best location to install your router.

Unpacking Your New Router

Your product package should contain the following items:

• The Wireless-N 150 Router

• An AC power adapter (varies by region)

• A yellow Ethernet cable

• The Resource CD, which includes:

– The Smart Wizard Installation Assistant (Autorun.exe)

– A PDF version of this manual

– A link to the online User Manual

If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the

carton, including the original packing materials, in case you need to return the product for repair.

A link to the online User Manual is also available from the router interface,

after the router is installed. Click Documentation on the main menu.

Getting to Know Your Wireless Router 2

To prepare your router for installation:

1. Carefully peel off any protective film covering the sides of your router.

2. Place your router in a suitable area for installation (near an AC power outlet and accessible to

the Ethernet cables for your wired computers).

Hardware Features

Before you install and connect your router, take a moment to become familiar with the front and

back panels of the router—especially the status lights on the front panel.

Front Panel

The router front panel, shown in Figure 1, contains status lights. (For more information on

interpreting the status lights, see “Verifying Your Connection” on page 15 and “Checking Basic

Router Functions” on page 25.)

Figure 1

12345

Getting to Know Your Wireless Router 3

You can use the status lights to verify various conditions.

Table 1. Status Light Descriptions

Label Activity Description

1. Power

Solid Amber

Solid Green

Fast blink–Green

Slow blink–Green

Off

The router is performing the power-on self-test diagnostic.

The power is on and the router is ready.

A software update is in progress.

Firmware is corrupted. See “Checking Basic Router Functions” on

page 25 for instructions on restoring your router firmware.

Power is not being supplied to the router

2. Push 'N'

Connect

Solid Green

Blinking Green

Off

Indicates that wireless security is enabled.

WPS-capable devices can associate with the router within 2

minutes.

No WPS connection exists.

3. Internet

Solid Amber

Solid Green

Blinking Green

Off

No IP address acquired.

The wireless router has acquired an Internet address.

Data is being communicated with the Internet.

No Ethernet cable is connected to the modem.

4. Wireless

Solid Blue

Blinking Blue

Off

The wireless interface is enabled.

Data is being communicated over the wireless network.

The wireless interface is turned off.

5. LAN

(Ports 1–4)

Solid Green

Blinking Green

Solid Amber

Blinking Amber

Off

The local port is connected to a 100 Mbps device.

Data is being transmitted at 100 Mbps.

The local port is connected to a 10 Mbps device.

Data is being transmitted at 10 Mbps.

No link is detected on this port.

Getting to Know Your Wireless Router 4

Back Panel

The router back panel, shown in Figure 2, contains port connections.

Viewed from left to right, the rear panel contains the following elements:

1. AC power adapter outlet for connecting the power adapter.

2. Power on/off push-button.

3. Internet/Wide Area Network (WAN) Ethernet port for connecting the router to a cable or DSL

modem.

4. Four Local Area Network (LAN) 10/100 Mbps Ethernet ports for connecting the router to

your local computers.

5. Restore factory settings button. Press for approximately 5 seconds to reset the router to the

factory default settings.

Side Panel

The router side panel is shown in Figure 3.

Figure 2

Figure 3

1 4

32 5

Getting to Know Your Wireless Router 5

1. WPS button – Turns Push ‘N’ Connect (WPS) security on and off. When wireless security is

enabled, the Push ‘N’ Connect LED on the front of the wireless router is solid green. See

“Push 'N' Connect” on page 3.

2. Wireless On/Off button – Turns the Wireless network on and off. When the Wireless

network is enabled, the Wireless LED on the front of the router is solid green. See “Wireless”

on page 3.

Router Label

The label on the bottom of the wireless router shows the router’s MAC address, serial number,

security PIN, and factory default login information.

The ports on the router are color-coded to distinguish your Internet port from the other four ports

that connect to the wired computer(s) on your Local Area Network (LAN).

Positioning Your Wireless Router

The wireless router lets you access your network from virtually anywhere within the operating

range of your wireless network. However, the operating distance or range of your wireless

connection can vary significantly depending on the physical placement of your router. For

example, the thickness and number of walls the wireless signal must pass through might limit the

range. For best results, place your router:

Figure 4

Getting to Know Your Wireless Router 6

• Near the center of the area where your computers and other devices will operate, preferably

within line of sight to your wireless devices.

• Accessible to an AC power outlet and near Ethernet cables for wired computers.

• In an elevated location such as a high shelf, keeping the number of walls and ceilings between

the wireless router and your other devices to a minimum.

• Away from electrical devices which are potential sources of interference, such as ceiling fans,

home security systems, microwaves, or the base for a cordless phone.

• Away from any large metal surfaces, such as a solid metal door or aluminum studs. Large

expanses of other materials such as glass, insulated walls, fish tanks, mirrors, brick, and

concrete can also affect your wireless signal.

Installing Your Wireless Router

To help you set up your router and get on the Internet quickly, the Resource CD contains a Smart

Wizard™ Installation Assistant. The Installation Assistant walks you through the steps required to

connect your router, modem, and PC(s); configure your wireless settings; and enable wireless

security for your network. When you have finished, you will be Internet ready!

You can set up your wireless router using one of two methods:

•Smart Wizard Setup: The Smart Wizard Installation Assistant setup is available on your

Resource CD. See “Installing Your Router Using the Smart Wizard” on page 8 to use the

Smart Wizard Installation Assistant.

– This is the easiest option. The wizard guides you through the setup process. It automates

many of the steps and verifies that the steps have been successfully completed.

Failure to follow these guidelines can result in significant performance degradation

or an inability to wirelessly connect to the Internet.

NETGEAR does not recommend or support adding a NETGEAR router behind

another router, or replacing a gateway with a NETGEAR router.

If you have a Macintosh or Linux system, you need to use the manual installation

method (see “Manually Installing Your Router” on page 11).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador inalámbrico de NETGEAR

NETGEAR

NETGEAR Orbi NBR750 Manual de usuario

NETGEAR

NETGEAR WGR614 v5 Manual de usuario

NETGEAR

NETGEAR Nighthawk X6 AC3200 Manual de usuario

NETGEAR

NETGEAR WNDR3700 - RangeMax Dual Band Wireless-N Gigabit Router... Guía del usuario

NETGEAR

NETGEAR WNMR834 Manual de usuario

NETGEAR

NETGEAR N300 WNR2000v5 Manual de usuario

NETGEAR

NETGEAR JNR1010v2 Manual de usuario

NETGEAR

NETGEAR R6350 Manual de usuario

NETGEAR

NETGEAR WNDAP360 Manual de servicio

NETGEAR

NETGEAR ProSafe FVM318 Manual de usuario

NETGEAR

NETGEAR Nighthawk MK83 Manual de usuario

NETGEAR

NETGEAR N600 Manual de usuario

NETGEAR

NETGEAR D6300B Manual de usuario

NETGEAR

NETGEAR Nighthawk R6700 Manual de usuario

NETGEAR

NETGEAR WNDR3700v4 Manual de usuario

NETGEAR

NETGEAR Nighthawk M2 MR2100 Manual de usuario

NETGEAR

NETGEAR WNR612v2 - Wireless-N 150 Router Manual de usuario

NETGEAR

NETGEAR DGN3500 - Wireless-N Gigabit Router Guía del usuario

NETGEAR

NETGEAR DG834G Manual de usuario

NETGEAR

NETGEAR R6230 Manual de usuario

NETGEAR

NETGEAR NIGHTHAWK RAX120 Manual de usuario

NETGEAR

NETGEAR R6220 Manual de usuario

NETGEAR

NETGEAR N150 DGN1000v3 Manual de usuario

NETGEAR

NETGEAR 779S Sprint Manual de usuario

Manuales populares de Enrutador inalámbrico de otras marcas

Milesight

Milesight UG67 Manual de usuario

Airlogic

Airlogic AirSync Class 1 Manual del propietario

Samsung

Samsung WCH730B Manual de usuario

TELEFONICA

TELEFONICA USB Adapter Manual de usuario

Askey

Askey RAC2V1K Manual de usuario

Alloy

Alloy WLF2454AP-S Manual de usuario

TP-Link

TP-Link TL-WR542G Manual de usuario

Hama

Hama 53120 Manual de usuario

Intellinet

Intellinet 524582 Manual de usuario

Asus

Asus RT-N10P Manual de usuario

D-Link

D-Link DIR-506L Manual de usuario

Sapido

Sapido GR297n Manual de usuario

Asus

Asus DSL-N55U Manual de usuario

AMTC

AMTC WR7502 Manual de usuario

Compaq

Compaq CP-2W - iPAQ Connection Point Manual de usuario

SMC Networks

SMC Networks WBR14-N2 FICHE Manual de usuario

Draytek

Draytek Vigor2120 Series Manual de usuario

Sitecom

Sitecom WLR-4000 Manual de usuario
