NETGEAR R6800 Manual de usuario

Quick Start

AC1900 Smart WiFi Router

Model R6800

For the best WiFi performance, position the antennas as shown.

Package Contents

Router

Power adapter

(varies by region)

Ethernet cable

1. Position the Antennas

Unplug your modem, remove and replace the backup battery if it uses one, and then

plug the modem back in. Use the Ethernet cable to connect the modem to the yellow

Internet port on the router.

Note: If your Internet connection does not require a modem, connect your main

Ethernet cable to the yellow Internet port on the router.

Connect the router to a power source. The router’s Power LED lights amber and

then turns white when the router is ready.

Make sure that the router’s WiFi LED is lit. Look on the router’s label for the

preassigned WiFi network name (SSID) and network key (password).

Open the WiFi connection manager on your WiFi‑enabled computer or mobile device,

find the router’s SSID, and use the router’s password to connect to the router’s WiFi

network.

Launch a web browser. If the installation assistant does not display, visit www.

routerlogin.net. If a login window displays, enter admin for the admin user name and

password for the admin password.

Follow the on‑screen instructions to connect to the Internet.

The router’s Internet LED lights white when the router is connected to the

Internet.

2. Restart Your Modem and

Plug In Your Router

3. Connect to the Internet

Antennas (3)

45° 45°

All Set Up!

Router

Modem

Ethernet cable

Internet

For more information about your router, see the Do More booklet.

September 2016

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

Computer

Power

adapter

NETGEAR INTL LTD

Building 3, University Technology Centre

Curraheen Road, Cork, Ireland

Get Free Apps

Start enjoying your new router right away with free apps that make management simple.

Visit netgear.com/support to download the apps.

NETGEAR genie. Personal dashboard to monitor, control, and repair your home

network. Includes remote access to manage your network away from home.

ReadySHARE Vault. Free software for automatic backup of a Windows

computer to a USB hard drive connected to the router.

ReadyCLOUD. Enjoy personal and secure cloud access to USB storage anytime,

anywhere.

Support

Thank you for purchasing this NETGEAR product. You can visit

www.netgear.com/support to register your product, get help, access the latest

downloads and user manuals, and join our community. We recommend that you use only

official NETGEAR support resources.

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

For regulatory compliance information, visit

http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Any non‑NETGEAR trademarks are used for reference purposes only.

BETA DOCUMENT

Quick Start

AC1750 Smart WiFi Router

Model R6700v2

For the best WiFi performance, position the antennas as shown.

Package Contents

Router Power adapter

(varies by region)

Ethernet cable

1. Position the Antennas

Unplug your modem, remove and replace the backup battery if it uses one, and then

plug the modem back in. Use the Ethernet cable to connect the modem to the yellow

Internet port on the router.

Note: If your Internet connection does not require a modem, connect your main

Ethernet cable to the yellow Internet port on the router.

Connect the router to a power source. The router’s Power LED lights amber and

then turns white when the router is ready.

Make sure that the router’s WiFi LED is lit. Look on the router’s label for the

preassigned WiFi network name (SSID) and network key (password).

Open the WiFi connection manager on your WiFi‑enabled computer or mobile device,

find the router’s SSID, and use the router’s password to connect to the router’s WiFi

network.

Launch a web browser. If the installation assistant does not display, visit www.

routerlogin.net. If a login window displays, enter admin for the admin user name and

password for the admin password.

Follow the on‑screen instructions to connect to the Internet.

The router’s Internet LED lights white when the router is connected to the

Internet.

2. Restart Your Modem and

Plug In Your Router

3. Connect to the Internet

Antennas (3)

45° 45°

All Set Up!

Router

Modem

Ethernet cable

Internet

For more information about your router, see the Do More booklet.

September 2016

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

Computer

Power

adapter

NETGEAR INTL LTD

Building 3, University Technology Centre

Curraheen Road, Cork, Ireland

Get Free Apps

Start enjoying your new router right away with free apps that make management simple.

Visit netgear.com/support to download the apps.

NETGEAR genie. Personal dashboard to monitor, control, and repair your home

network. Includes remote access to manage your network away from home.

ReadySHARE Vault. Free software for automatic backup of a Windows

computer to a USB hard drive connected to the router.

ReadyCLOUD. Enjoy personal and secure cloud access to USB storage anytime,

anywhere.

Support

Thank you for purchasing this NETGEAR product. You can visit

www.netgear.com/support to register your product, get help, access the latest

downloads and user manuals, and join our community. We recommend that you use only

official NETGEAR support resources.

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

For regulatory compliance information, visit

http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Any non‑NETGEAR trademarks are used for reference purposes only.

BETA DOCUMENT

Quick Start

AC1750 Smart WiFi Router

Model R6700v2

For the best WiFi performance, position the antennas as shown.

Package Contents

Router Power adapter

(varies by region)

Ethernet cable

1. Position the Antennas

Unplug your modem, remove and replace the backup battery if it uses one, and then

plug the modem back in. Use the Ethernet cable to connect the modem to the yellow

Internet port on the router.

Note: If your Internet connection does not require a modem, connect your main

Ethernet cable to the yellow Internet port on the router.

Connect the router to a power source. The router’s Power LED lights amber and

then turns white when the router is ready.

Make sure that the router’s WiFi LED is lit. Look on the router’s label for the

preassigned WiFi network name (SSID) and network key (password).

Open the WiFi connection manager on your WiFi‑enabled computer or mobile device,

find the router’s SSID, and use the router’s password to connect to the router’s WiFi

network.

Launch a web browser. If the installation assistant does not display, visit www.

routerlogin.net. If a login window displays, enter admin for the admin user name and

password for the admin password.

Follow the on‑screen instructions to connect to the Internet.

The router’s Internet LED lights white when the router is connected to the

Internet.

2. Restart Your Modem and

Plug In Your Router

3. Connect to the Internet

Antennas (3)

45° 45°

All Set Up!

Router

Modem

Ethernet cable

Internet

For more information about your router, see the Do More booklet.

September 2016

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

Computer

Power

adapter

NETGEAR INTL LTD

Building 3, University Technology Centre

Curraheen Road, Cork, Ireland

Get Free Apps

Start enjoying your new router right away with free apps that make management simple.

Visit netgear.com/support to download the apps.

NETGEAR genie. Personal dashboard to monitor, control, and repair your home

network. Includes remote access to manage your network away from home.

ReadySHARE Vault. Free software for automatic backup of a Windows

computer to a USB hard drive connected to the router.

ReadyCLOUD. Enjoy personal and secure cloud access to USB storage anytime,

anywhere.

Support

Thank you for purchasing this NETGEAR product. You can visit

www.netgear.com/support to register your product, get help, access the latest

downloads and user manuals, and join our community. We recommend that you use only

official NETGEAR support resources.

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

For regulatory compliance information, visit

http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Any non‑NETGEAR trademarks are used for reference purposes only.

BETA DOCUMENT
