NETGEAR Nighthawk M1 Manual de usuario

QUICK START

KURZANLEITUNG

DEMARRAGE RAPIDE

GUIDA INTRODUTTIVA

INICIO RÁPIDO

КРАТКОЕ РУКОВОДСТВО

NETGEAR Nighthawk M1

4GX Gigabit LTE Mobile Router/Mobiler 4GX-Gigabit-LTE-Router

Routeur mobile 4GX Gigabit LTE/Router 4GX Gigabit LTE Mobile

Router móvil 4GX LTE Gigabit/Гигабитный мобильный роутер LTE 4GX

Package Contents

• Nighthawk M1 Mobile Router and battery

• Quick start guide

• Type-C USB cable

• AC power adapter

1. Check the SIM card and insert the battery.

a. Make sure that power to the mobile router is o.

b. Remove the cover on the bottom of the mobile router.

Place your thumbs on the arrows on the cover and press down

while sliding the cover up.

c. Check to see if a micro SIM card was inserted into the SIM card

slot.

If a micro SIM card was inserted, skip to Step e. If a micro SIM

card was not inserted, locate the micro SIM card and continue

with Step d.

To get a valid and provisioned SIM card, contact your mobile

provider.

English

d. Carefully slide the micro SIM card into the slot.

e. Align the battery connectors and insert the battery.

f. If you purchased a micro SD card, insert the card

into the micro SD slot.

g. Replace the mobile router cover.

Reset

SIM card

Micro SD slo

2. Download the NETGEAR Mobile app.

Use the NETGEAR Mobile app to change your WiFi network name

and password. You can also use it to play and share media, and enable

the travel router feature.

a. Connect your mobile device to the Internet.

b. Download the NETGEAR Mobile app from

netgear.com/mobileapps.

3. Power on your mobile router.

Press and hold the Power button on the mobile router for three

seconds.

Power button

To view the WiFi name and password, press and release the Power

button to toggle through Nighthawk M1 router LCD displays.

4. Connect your devices.

a. Check to make sure that WiFi is enabled on your computer or

mobile device and search for WiFi networks. Refer to the following

table or the manual for your WiFi-enabled device for further details

on searching for WiFi networks.

b. To view the WiFi name and password, press and release the Power

button to toggle through Nighthawk M1 router LCD displays.

Windows Click the Internet Access icon, which is usually found on

the bottom right side of your screen.

Mac Select WiFi > Network.

Mobile

devices Tap Settings > WiFi.

c. Select the WiFi name displayed on your Nighthawk M1 screen.

d. Enter the WiFi password exactly as shown on the Nighthawk M1 screen.

NOTE: Your password is case-sensitive. We strongly recommend that

you change the default admin password.

e. To use the router as an internet gateway, connect an Ethernet

device to the Nighthawk M1 router Ethernet port.

5. Set up the device.

a. Use the NETGEAR Mobile app or visit http://m1login.net or

http://192.168.1.1 from a device that is connected to the

Nighthawk M1 router.

b. Follow the on screen instructions.

Advanced Conﬁguration and Features

¾To log in to the Nighthawk M1 router home page:

1. Launch a web browser from a device that is connected to the

Nighthawk M1 router.

2. In the address ﬁeld of the web browser, enter

http://m1login.net or http://192.168.1.1.

3. In the Sign In ﬁeld, enter the default password and click the

While the password that you enter is unique to your device and is

secure, we recommend that you change it to a password that you

want to use.

Upload Media Files to the Nighthawk M1 Router

You can upload media ﬁles to either a micro SD card or a USB drive

connected to the Nighthawk M1 router. Micro SD cards and USB

drives are sold separately. To enable media and Ethernet support, you

must ﬁrst select the Charge Only option (Settings > Router Setup

> Use USB port for).

¾To upload media ﬁles to the Nighthawk M1 router with a

computer:

1. Log in to the Nighthawk M1 router home page.

2. Click the MyMedia tab.

3. Drag and drop your ﬁles onto the page.

Use the Nighthawk M1 Router to Charge Other Devices

If the battery power is low on your smartphone or other device, you

can give it a boost by connecting it to the M1’s USB port A connector.

Jump boost begins automatically once the devices are connected.

LED Status

Slow blue blink The Nighthawk M1 router is ready.

Fast blue blink The Nighthawk M1 router is transferring data.

Slow amber blink The Nighthawk M1 router is not ready.

USB (type A) USB (type C) Ethernet

TS-9

Port 1

TS-9

Por

t 2

Power

Power Button

Turn on the router. Press and hold the Power button for three

seconds.

Turn o the router. Press and hold the Power button for ﬁve seconds.

Wake the router. Press and quickly release the Power button.

Switch between screens. Press and quickly release the Power button.

Support

For additional information, visit netgear.com/support to access the full user

manual and to download ﬁrmware updates.

Compliance

For the current EU Declaration of Conformity, visit

http://kb.netgear.com/app/answers/detail/a_id/11621.

For regulatory compliance information, visit: http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.
