NETGEAR PowerLEAP WiFi 1000 Manual de usuario

Quick Start

PowerLEAP WiFi 1000

Quick Start Guide

2

Package Contents

In some regions, a resource CD is included with your product.

3

Getting Started

Powerline adapters give you an alternative way to extend your network

using your existing electrical wiring. Plug two or more Powerline adapters

into electrical outlets to create a wired network connection. Use a

Powerline WiFi Access Point to add a WiFi access point to your wired

network.

You can add up to 8 Homeplug AV-certiﬁed and AV2-certiﬁed adapters

to extend your network. For a complete list of Homeplug AV-certiﬁed

devices, visit http://www.homeplug.org/certiﬁed_products.

4

Meet Your Adapter

Before you install your adapter, familiarize yourself with its LEDs,

buttons, and port.

1

5

4

2

3

1. Power LED 4. Ethernet port 7. Wireless LED

2. Ethernet LED 5. Factory Reset button 8. On/O switch

3. Pick A Plug LED 6. Security button 9. WPS button

1

2

3

4 5 6

7

8

6

9

5

Power LED Solid green. The electrical power is on.

Solid amber. The adapter is in power saving mode (PL1000

only).

Blinking green. The adapter is in the process of setting up

security.

O. The adapter is not receiving electrical power.

Ethernet LED Solid. The Ethernet port is linked.

O. No Ethernet connection is detected.

Pick A Plug LED The Pick A Plug feature lets you pick the electrical outlet

with the strongest link performance, indicated by the color

displayed by the LED:

Red. Link rate < 50 Mbps (good).

Amber. Link rate > 50 and < 80 Mbps (better).

Green. Link rate > 80 Mbps (best).

O. The adapter did not ﬁnd any other compatible Powerline

devices using the same encryption key.

Wireless LED

Solid blue. The wireless radio is on.

O. The wireless radio is o.

6

Factory Reset

button

Press the Factory Reset button for one second, then release

it to return the Powerline adapter to its factory default

settings.

Ethernet port Connect your wired devices, including computers, WiFi

routers or game consoles, to your Powerline network.

Security button Use the Security button to create a secure Powerline

network.

On/O switch Use the On/O switch to turn the device on and o.

WPS button Use the WPS button to automatically connect your computer

or other wireless devices which support WPS, to your

Powerline network.

7

Install Your Adapters

Room 1 Room 2

8

Secure Your Network

¾To create a secure network:

1. Plug in your new adapters.

2. Wait until the Pick A Plug LEDs are lit.

3. Press the Security button for two seconds, then press the Security

button on one of the other adapters in your existing network for two

seconds. Both buttons must be pressed within two minutes.

Note: The Security button does not work in power saving mode (see

Troubleshooting Tips on page 18).

Warning: Do not press the

Security

button on the Powerline adapter

until installation is complete and the adapters are communicating with

each other (indicated by the power LED). Pressing this button too soon

can temporarily disable Powerline communication. If this occurs, use the

Factory Reset button to return the Powerline adapter to its factory

default settings.

9

Set Up WiFi Access on Your PowerLEAP

You can set up WiFi access on your PowerLEAP access point using

NETGEAR genie or using the web browser setup guide.

¾To set up WiFi access using NETGEAR genie:

1. Install NETGEAR genie (see Install NETGEAR genie on page 15).

2. Temporarily connect your computer directly to the PowerLEAP

through the Ethernet port.

10

3. Launch NETGEAR genie on your computer and click Network Map or

select it from the menu.
