NETGEAR ProSafe GS104 Manual de usuario

GS104

4-port Gigabit Ethernet Switch

10/100/1000 Mbps

Power Up Your Small Network to Gigabit Speeds

Now you can have a powerful, high-speed network on a small scale. NETGEAR's

GS104 Gigabit Ethernet Switch lets you build a system that provides a full, dedicated

1000, 100, or 10 Mbps connection so you can move even very large files across your

network instantly. The GS104 also lets you painlessly integrate 10, 100, and 1000

Mbps devices. This potent switch is packed with ease-of-use features to simplify your

workday experience. It's compact design fits neatly into small work spaces and, since

it's self-cooling without a fan, it runs silently and unobtrusively.

Moves huge files fast! Features a high-speed, auto-switching 10/100/1000 Mbps Ethernet

connection. And because Gigabit Ethernet is a full duplex standard, you can get up to 2000

Mbps on each port.

Integrates 10, 100, and 1000 Mbps devices on the same network. Every port automatically

senses the right speed and full/half duplex mode, and Auto UplinkTM technology automati-

cally adjusts for straight-through or crossover cables.

LEDs embedded in RJ-45 jacks make for easy monitoring. Space-saving dimensions are

ideal for desktop or wall mounting in home and small office environments. And it runs

quietly, self- cooling without an internal fan.

Strong, durable metal case securely protects the switch’s working parts. The GS104 is made

to last and NETGEAR backs it with a solid warranty: switch - 5 years, power supply -

2 years.

Power-Packed

Capable

Accommodating

Solid

Everybody’s Connecting.™

• Help is there when you need it!

NETGEAR provides 24x7

telephone and e-mail technical

support in English, with selected

local language support during

office hours.

FVS318 VPN Firewall

GS104 Gigabit Ethernet Switch

Internet

PCs

with GA302T

Cable/DSL modem

Server

with GA622T

4500 Great America Parkway

Santa Clara, CA 95054 USA

Phone: 1-888-NETGEAR

E-mail: [email protected]

www.NETGEAR.com

Netgear Logo, the Gear Guy, and

Everybody’s connecting are trademarks or

registered trademark of Netgear, Inc. in

the United States and/or other countries.

Microsoft, Windows, and the Windows

logo are trademarks, or registered trade-

marks of Microsoft Corporation in the

United States and/or other countries.

Other brand and product names are

trademarks or registered trademarks of

their respective holders. Information is

subject to change without notice. All

rights reserved.

D-GS104-0

•Status LEDs :

-Power, Collision/Rx/Tx, and duplex indicators for

each port

-Link and speed indicators built into each vista

RJ-45 port

•Standards Compliance:

-IEEE 802.3i 10BASE-T Ethernet

-IEEE 802.3u 100BASE-TX Fast Ethernet

-IEEE 802.3ab 1000BASE-T Gigabit Ethernet

-Windows, MacOS, Netware, TCP/IP

•Warranty:

-Switch - 5 years

-Power adapter - 2 years

•Input Voltage :

-5V and 5A

System Requirements

-UTP Category 5 or better cables

-Network card for each PC or server (e.g. GA302T)

-Network software (e.g., Windows, Linux, MacOS)

Package Contents

-GS104 4-port Gigabit Ethernet Switch

-Wall-mount kit

-AC adapter

-Installation Guide

-Warranty and registration card

-Support information card

Technical Specifications

•Network Ports:

-4 auto-speed-sensing UTP ports

•Forwarding Mode:

-Store-and-Forward

•Performance:

-Bandwidth: 8 Gbps (non-blocking)

-Forward Rate (10 Mbps port): 14,800 packets/sec

-Forward Rate (100 Mbps port): 148,000

packets/sec

-Forward Rate (1000 Mbps port): 1,488,000

packets/sec

-Latency (100 to 100 Mbps): 20 usec (max)

-Latency (1000 to 1000 Mbps): 10 usec (max)

-Queue Buffer Memory: 12Kbytes per port

-MAC address database: 8000

-Acoustic Noise: 0 DB

-Heat Dissipation: 38.8 Btu/hr

•AC Power:

-17.5W

•Dimensions:

-9.3" x 4.1" x 1.1" (235 mm 103 mm 27 mm)

-1.25 lb (0.6 kg)

•Environmental Specifications:

-Operating temperature: 0ºC to 40ºC

-Operating humidity: 10% to 90% noncondensing

•Safety Agency Approvals:

-UL (UL 1950), CUL, C-tick

•Electromagnetic Compliance:

-CE mark, commercial FCC Part 15 Class B, EN55

022 (CISPR 22), Class B VCCI, Class B C-Tick
